NetApp FAS8300 Bedienungsanleitung

FAS8300 and FAS8700 systems

ONTAP Systems

NetApp

November 23, 2021

This PDF was generated from https://docs.netapp.com/us-en/ontap-systems/fas8300/install-setup.html

on November 23, 2021. Always check docs.netapp.com for the latest.

Table of Contents

FAS8300 and FAS8700 System Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê1

Install and setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê1

Maintain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê10

FAS8300 and FAS8700 System Documentation

Install and setup

Start here: Choose your installation and setup experience

For most configurations, you can choose from different content formats.

•Quick steps

A printable PDF of step-by-step instructions with live links to additional content.

•Video steps

Video step-by-step instructions.

•Detailed steps

Online step-by-step instructions with live links to additional content.

For MetroCluster configurations, see either:

•Install MetroCluster IP configuration

•Install MetroCluster Fabric-Attached configuration

Quick guide - FAS8300 and FAS8700

This guide gives graphic instructions for a typical installation of your system from racking

and cabling, through initial system bring-up. Use this guide if you are familiar with

installing NetApp systems.

Access the Installation and Setup Instructions PDF poster:

FAS8300 and FAS8700 Installation and Setup Instructions

Videos - FAS8300 and FAS8700

There are two videos; one showing how to rack and cable your system and one showing

an example of using the System Manager Guided Setup to perform initial system

configuration.

Video one of two: Hardware installation and cabling

The following video shows how to install and cable your new system.

FAS8300 and FAS8700 Installation and setup instructions

Video two of two: Performing end-to-end software configuration

The following video shows end-to-end software configuration for systems running ONTAP 9.2 and later.

NetApp video: Software configuration for vSphere NAS datastores for FAS/AFF systems running ONTAP 9.2

Detailed guide - FAS8300 and FAS8700

This guide gives detailed step-by-step instructions for installing a typical NetApp system.

Use this guide if you want more detailed installation instructions.

Step 1: Prepare for installation

To install your system, you need to create an account, register the system, and get

license keys. You also need to inventory the appropriate number and type of cables for

your system and collect specific network information.

You need to have access to the Hardware Universe for information about site requirements as well as

additional information on your configured system. You might also want to have access to the Release Notes for

your version of ONTAP for more information about this system.

NetApp Hardware Universe

Find the Release Notes for your version of ONTAP 9

You need to provide the following at your site:

•Rack space for the storage system

•Phillips #2 screwdriver

•Additional networking cables to connect your system to your network switch and laptop or console with a

Web browser

Steps

1. Unpack the contents of all boxes.

2. Record the system serial number from the controllers.

3. Inventory and make a note of the number and types of cables you received.

The following table identifies the types of cables you might receive. If you receive a cable not listed in the

table, see the Hardware Universe to locate the cable and identify its use.

NetApp Hardware Universe

Type of cable… Part number and length Connector type For…

100 GbE cable

(QSF(28)

X66211A-05 (112-00595), 0.5m

X66211A-1 (112-00573), 1m

X66211A-2 (112-00574), 2m

X66211A-5 (112-00574), 5m

Storage, cluster interconnect/HA,

and Ethernet data (order-

dependent)

Type of cable… Part number and length Connector type For…

25 GbE cable

(SFP28s)

X66240-2 (112-00598), 2m

X66240-5 (112-00639), 5m

GbE network connection (order-

dependent)

32 Gb FC

(SFP+ Op)

X66250-2 (112-00342), 2m

X66250-5 (112-00344), 5m

X66250-15 (112-00346), 15m

FC network connection

Storage Cables X66030A (112-00435), .5m

X66031A (112-00436), 1m

X66032A (112-00437), 2m

X66033A (112-00438), 3m

mini-SAS HD to mini-SAS HD

cables (order-dependent)

Optical cables X66250-2-N-C (112-00342) 16 Gb FC or 25GbE cables for

mezzanine cards (order-

dependent)

RJ-45 (order

dependent)

X6585-R6 (112-00291), 3m

X6562-R6 (112-00196), 5m

Management network

Micro-USB

console cable

Not applicable Console connection used during

software setup if laptop or console

does not support network

discovery.

Power cables Not applicable Powering up the system

4. Review the NetApp ONTAP Confiuration Guide and collect the required information listed in that guide.

ONTAP Configuration Guide

Step 2: Install the hardware

You need to install your system in a 4-post rack or NetApp system cabinet, as applicable.

Steps

1. Install the rail kits, as needed.

2. Install and secure your system using the instructions included with the rail kit.

You need to be aware of the safety concerns associated with the weight of the system.

3. Attach cable management devices (as shown).

4. Place the bezel on the front of the system.

Step 3: Cable controllers to your network

You can cable the controllers to your network by using the two-node switchless cluster

method or by using the cluster interconnect network.

Option 1: Cable a two-node switchless cluster

The optional data ports, optional NIC cards, and management ports on the controller

modules are connected to switches. The cluster interconnect and HA ports are cabled on

both controller modules.

You must have contacted your network administrator for information about connecting the system to the

switches.

Be sure to check the direction of the cable pull-tabs when inserting the cables in the ports. Cable pull-tabs are

up for all onboard ports and down for expansion (NIC) cards.

As you insert the connector, you should feel it click into place; if you do not feel it click, remove

it, turn it around and try again.

Steps

1. Use the animation or illustration to complete the cabling between the controllers and to the switches:

Two-node switchless cluster cabling

2. Go to Step 4: Cable controllers to drive shelves for drive shelf cabling instructions.

Option 2: Cable a switched cluster

The optional data ports, optional NIC cards, mezzanine cards, and management ports on

the controller modules are connected to switches. The cluster interconnect and HA ports

are cabled on to the cluster/HA switch.

You must have contacted your network administrator for information about connecting the system to the

switches.

Be sure to check the direction of the cable pull-tabs when inserting the cables in the ports. Cable pull-tabs are

up for all onboard ports and down for expansion (NIC) cards.

As you insert the connector, you should feel it click into place; if you do not feel it click, remove

it, turn it around and try again.

Steps

1. Use the animation or illustration to complete the cabling between the controllers and to the switches:

Switched cluster cabling

2. Go to Step 4: Cable controllers to drive shelves for drive shelf cabling instructions.

Step 4: Cable controllers to drive shelves

Option 1: Cable the controllers to SAS drive shelves

You must cable each controller to the IOM modules on both SAS drive shelves.

Be sure to check the illustration arrow for the proper cable connector pull-tab orientation. The cable pull-tab for

the DS224-C are down.

As you insert the connector, you should feel it click into place; if you do not feel it click, remove

it, turn it around and try again.

Steps

1. Use the following animation or illustration to cable your controllers to two drive shelves.

Cabling the controllers to SAS drive shelves

2. Go to Step 5: Complete system setup and configuration to complete system setup and configuration.

Step 5: Complete system setup and configuration

You can complete the system setup and configuration using cluster discovery with only a

connection to the switch and laptop, or by connecting directly to a controller in the system

and then connecting to the management switch.

Option 1: Completing system setup and configuration if network discovery is enabled

If you have network discovery enabled on your laptop, you can complete system setup

and configuration using automatic cluster discovery.

Steps

1. Use the following animation to set one or more drive shelf IDs:

Setting drive shelf IDs

2. Plug the power cords into the controller power supplies, and then connect them to power sources on

different circuits.

3. Make sure that your laptop has network discovery enabled.

See your laptop’s online help for more information.

4. Use the following animation to connect your laptop to the Management switch.

Connecting your laptop to the Management switch

5. Select an ONTAP icon listed to discover:

a. Open File Explorer.

b. Click network in the left pane.

c. Right click and select refresh.

d. Double-click either ONTAP icon and accept any certificates displayed on your screen.

XXXXX is the system serial number for the target node.

System Manager opens.

6. Use System Manager guided setup to configure your system using the data you collected in the NetApp

ONTAP Configuration Guide.

ONTAP Configuration Guide
