GenericUnit

UC7BoomHeightControlSystem

InstallationManual



ReorderP/N:UC7‐BC‐GN01‐INSTRevC(GenericUnit)



NOTICE:NORACSystemsInternationalInc.reservestherighttoimproveproductsandtheirspecificationswithoutnoticeandwithouttherequirementtoupdate

productssoldpreviously.Everyefforthasbeenmadetoensuretheaccuracyoftheinformationcontainedinthismanual.Thetechnicalinformationinthismanual

wasreviewedatthetimeofapprovalforpublication.



WWW.NORAC.CA

PRECISIONDEFINED



Contents



Introduction..........................................................................................................................1



TechnicalSpecifications........................................................................................................2



PartsOverview......................................................................................................................3



Pre‐InstallationChecklist.......................................................................................................8



HydraulicInstallation.............................................................................................................9



UltrasonicSensorInstallation..............................................................................................14



ElectronicInstallation..........................................................................................................20



SoftwareSetup....................................................................................................................24



CableSchematics.................................................................................................................25





WWW.NORAC.CA

PRECISIONDEFINED





Page1

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

1Introduction

CongratulationsonyourpurchaseoftheNORACBoomHeightControlSystem.Thissystemismanufactured

withtopqualitycomponentsandisengineeredusingthelatesttechnologytoprovideoperatingreliability

unmatchedforyearstocome.

Whenproperlyusedthesystemcanprovideprotectionfromsprayerboomdamage,improvesprayerefficiency,

andensurechemicalsareappliedcorrectly.

Pleasetakethetimetoreadthismanualcompletelybeforeattemptingtoinstallthesystem.Athorough

understandingofthismanualwillensurethatyoureceivethemaximumbenefitfromthesystem.

Yourinputcanhelpmakeusbetter!Ifyoufindissuesorhavesuggestionsregardingthepartslistorthe

installationprocedure,pleasedon’thesitatetocontactus.



Everyefforthasbeenmadetoensuretheaccuracyoftheinformationcontainedinthismanual.Allparts

suppliedareselectedtospeciallyfitthesprayertofacilitateacompleteinstallation.However,NORACcannot

guaranteeallpartsfitasintendedduetothevariationsofthesprayerbythemanufacturer.

Pleasereadthismanualinitsentiretybeforeattemptinginstallation.

WWW.NORAC.CA

PRECISIONDEFINED





Page2

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

2TechnicalSpecifications

 

CANICES‐3(A)/NMB‐3(A)



ThisClassAdigitalapparatuscomplieswithCanadianICES‐003.

PursuanttoEMCDirective–Article9,thisproductisnotintendedforresidentialuse.

Table1:SystemSpecifications

SupplyVoltage(rated) 12VDC

SupplyCurrent(rated) 10A

HydraulicPressure(maximum) 3300psi

BaudRate 250kbps

OperatingTemperatureRange 0°Cto80°C





WWW.NORAC.CA

PRECISIONDEFINED





Page3

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

3PartsOverview

3.1. ElectronicInstallationOverview

ThefollowingdiagramsillustratetheGN01kitspecificpartsoftheNORACUC7™system.Interfacecables,power

cables,hosesandfittingsareshowninthismanualandmaynotbeincluded.Cablesareavailableseparately

fromNORAC.PleaserefertotheUC7CableOrderingGuide(P/N:UC7‐BC‐CABLE‐GUIDE)forcableordering

information(availableatwww.norac.ca).



Figure1:ElectronicInstallationOverview

Itemsshowningreenanddenotedwithanasterisk(*)arenotincludedandmustbeorderedseparately.

ItemsshowninBLUEareincludedinthedisplaypackageandmaynotbeexactlyasshown.

WWW.NORAC.CA

PRECISIONDEFINED





Page4

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

3.2. HydraulicPlumbingSchematic

3.2.1. SingleActing



Figure2:SingleActingHydraulicPlumbingSchematic

Itemsshowningreenanddenotedwithanasterisk(*)arenotincluded.





WWW.NORAC.CA

PRECISIONDEFINED





Page5

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

3.2.2. DoubleActing



Figure3:DoubleActingHydraulicPlumbingSchematic

Itemsshowningreenanddenotedwithanasterisk(*)arenotincluded.





WWW.NORAC.CA

PRECISIONDEFINED





Page6

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

3.3. ListofParts

ItemPartNumberNameQuantity

B0544706‐01KITCABLETIEBLACK10PCS21IN150PCS7.5IN1

B1550919MOUNTINGBRACKETMANIFOLD509W/HARDWARE1

B2044971SENSORMOUNTINGBRACKETLOWPROFILE16GA2

B2144973SENSORMOUNTINGBRACKETLOWPROFILE16GALARGEFLANGE1

C0143220‐01CABLENETWORK14AWG1M1

C0243220‐03CABLENETWORK14AWG3M1

C0543210‐20CABLENETWORK18AWG20M2

C1050130‐01CABLEVALVE4‐PINDTTO2‐PINDT2

C1150120‐01CABLETEMPERATUREPROBE1

E0150000HCM1MODULE1

E0750300ULTRASONICMAXSENSOR3

E1143765NETWORKCOUPLER8‐WAY1

E1243764NETWORKCOUPLER2‐WAY1

E2043764TNETWORKCOUPLER2‐WAYWITHTERMINATOR 2

H1044865‐34HYDRAULICSFITTINGKIT‐GN11

M02UC7‐BC‐GN01‐INSTMANUALINSTALLATIONUC7GENERIC1

M05106706MOUNTINGCLIPHCM12

P01106705NETWORK4PINCAVITYPLUG3

P03105882NETWORK6PINPLUG4

V0150902VALVEASSEM2STATIONCCPROPDT1





WWW.NORAC.CA

PRECISIONDEFINED





Page7

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

3.3.1. HydraulicFittingKitDetails(P/N:44865‐34)

ItemPartNumberNameQuantityPicture

F07103312MALEADAPTER‐6MB6MJ6



F0844928ORIFICEINSERT.047INONEWAY4



F09104369PLUG‐6MBP2



Thisfittingskitisdesignedforeithersingleactingordoubleactinghydraulics.Notallfittingsareusedfor

eachinstallation.



Donotusehighspeedpowertools/drillswheninstallinghardware.



TheuseofdielectricgreaseisnotrecommendedonanyNORACelectricalconnections.



ToensureallstainlesssteelhardwaredoesnotgallorseizeapplyalightcoatingofthesuppliedPermatex

Anti‐seizegreasetoallthreadedpartsuponinstallation.PermatexAnti‐seizelubricantispreferred,butother

similaranti‐seizeproductsmaybeused.



6 M B - 6 M OR X 90

SIZE IN

1/16TH'S

GENDER: MALE

OR FEMALE

90° ANGLE

SWIVEL

TYPE

GENDER

SIZE

TYPE:

B - ORB

J - JIC

OR - FLAT

FACE

P - PIPE

Fitting Name

Example:
