This version of the manual supports rmware 2232 and greater. Release date: Mar 05
User’s Manual
LH2 Fixed Position 2D Imager
25-ULH2R101-01 Preliminary
Statement of Agency Compliance
The LH2 can be set to use targeting lasers. If the targeting lasers are
activated, do not stare into the beams. The LH2’s targeting lasers
have been rated as Class IIa Lasers by IEC 60825-1.
The LH2 has been tested by an independent electromagnetic compat-
ibility laboratory in accordance with the applicable specications and
instructions.
The LH2 has been tested for compliance with FCC regulations and
was found to be compliant with all applicable FCC Rules and Regu-
lations.
IMPORTANT NOTE: To comply with FCC RF exposure compliance
requirements, this device must not be co-located or operate in
conjunction with any other antenna or transmitter.
CAUTION: Changes or modications not expressly approved by
the party responsible for compliance could void the user’s authority
to operate the equipment.
The LH2 has been tested for compliance to CE standards and
guidelines and was found to conform to applicable CE standards,
specically the EMC requirements EN 55024, ESD EN 61000-4-2,
Radiated RF Immunity EN 61000-4-3, ENV 50204, EFT EN 61000-
4-4, Conducted RF Immunity EN 61000-4-6, EN 55022, Class B
Radiated Emissions, and Class B Conducted Emissions.
LH2 User’s Manual
Copyright © 2004 the Opticon, Inc..
All Rights Reserved.
The software described in this manual may only be used in accordance with the terms of its license
agreement.
No part of this publication may be reproduced in any form or by any means without written permission
from the Opticon, Inc. This includes electronic or mechanical means such as photocopying or recording
in information storage and retrieval systems.
NO WARRANTY. This technical documentation is provided AS-IS. Further, the documentation does
not represent a commitment on the part of Opticon, Inc. Opticon, Inc. does not warrant that it is
accurate, complete or error free. Any use of the technical documentation is at the risk of the user.
Opticon reserves the right to make changes in specications and other information contained in this
document without prior notice, and the reader should in all cases consult Opticon to determine whether
any such changes have been made. Opticon shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential damages resulting from the furnishing,
performance, or use of this material. Opticon, Inc. does not assume any product liability arising out of or
in connection with the application or use of any product or application described herein.
NO LICENSE. No license is granted, either by implication, estoppel, or otherwise under any intellectual
property rights of The Opticon, Inc. Any use of hardware, software and/or technology of the Opticon, Inc.
is governed by its own agreement.
All other product names mentioned in this manual may be trademarks of their respective companies and
are hereby acknowledged.
The software and/or products of Opticon, Inc. include inventions that are patented or that are the subject
of patents pending.
Table of Contents
Organization of this Manual 8
Chapter 1 9
Introduction and Getting Started 9
Product Overview 9
Quick Start-Up Procedure 10
Chapter 2 13
Technical Specication 13
OPTICAL 13
ELECTRICAL 13
ENVIRONMENTAL 14
PHYSICAL 14
SYMBOLOGIES 14
PINOUTS 14
ORDERING INFORMATION 15
Chapter 3 17
Positioning the Imager for Optimal Performance 17
Achieving Optimum Performance 17
1) Distance to the Bar Code 17
Focal Distance 17
Depth-of-Field 17
LH2 Decode Zone 19
2) Avoiding Specular Reection 20
3) Quality Bar Code Labels 20
Barcode Readability Index 20
Code Readability Index Rule: 21
4) Imager Field of View & Resolution 22
Left Trigger Optimization Matrix 27
Right & Left Trigger Optimization Matrix 27
Continuous Trigger Optimization Matrix 28
Right Trigger Optimization Matrix 28
Application Notes 29
Tips for Achieving High Throughput 29
Tips for Insuring Highest Data Integrity 29
Chapter 4 31
Conguring the Imager 31
Programming Menus & Commands 31
Default Settings 31
RS-232 Interface Setting Defaults 31
Symbology Defaults: 32
Control Setting Defaults: 32
Chapter 5 33
Application Engineering Support 33
Technical Assistance and Support 33
Common Causes of Poor Performance 33
Modied and/or Customized Imagers 34
Chapter 6 35
Imager Servicing and Maintenance 35
How to use the Appendix? 37
Appendix A 37
Programming Menus & Commands 37
Programming Bar Codes 38
CRB Files 39
Example: test1.crb 40
General Options 41
Reset to Factory Defaults 41
Save Settings 42
Clear All CodeXML Rules 43
Reader ID & Firmware Version 44
Example: test2.crb 45
Barcode Readability Index 46
Software Trigger 48
Read Near and Far Field 48
Read Near Field only 48
Read Far Field only 48
Symbology Options 49
Aztec Symbology 49
Codabar Symbology 50
Codablock F Symbology 51
Code 128 Symbology 52
Code 93 Symbology 53
Code 39 Symbology 54
Composite Symbologies 56
Data Matrix Symbology 57
Interleaved 2 of 5 Symbology 58
Maxicode Symbology 60
Micro PDF 417 Symbology 61
MSI Plessy Symbology 62
PDF 417 Symbology 63
Postal Symbologies 64
QR Code Symbology 66
RSS Symbology 68
UPC / EAN / JAN Symbologies 70
Communication Parameters 72
Baud Rate 72
Data Bits 74
Stop Bits 75
Parity 76
Hardware Settings 77
Beep Volume 77
Laser Targeting 78
Laser Brightness 79
Left Key Programming 80
Right Key Programming 81
Continuous Scan 82
Continuous Scan 82
Continuous Scan - Trigger Delays 84
Duplicate Scan Delay 85
Advance Settings 86
Decode Time & LED’s for Non Standard Inks 86
Targeting Zone Tolerance 88
Windowing 90
VGA & SXGA Mode 92
Prex & Sufx Settings 93
Prex Settings 93
Sufx Settings 95
Optimization Matrix 97
SET 1 - Serial Commands for a Single Trigger 99
SET 1 - Barcodes for a Single Trigger 99
SET 2 - Barcodes for Continuous Trigger 100
SET 2 - Serial Commands for Continuous Trigger 100
Appendix B 101
Mechanical Layout 101
Chapter
9
Organization of this Manual
This manual provides the necessary instructions for installing and using an Opticon LH2 Fixed Position
Imager. The manual is organized as follows:
Chapter 1 Introduction and Getting Started
Describes the general operation of a LH2 Fixed Position Imager. Also provides a Quick
Start-Up Procedure that allows you to begin using the imager immediately.
Chapter 2 Technical Specications
Provides complete specications, including mechanical details, optical performance,
RS232 communications and other technical data.
Chapter 3 Positioning the Imager for Optimal Performance
Provides detailed instructions and tips for mounting and positioning the imager to
obtain the best scanning performance. Application Notes describe guidelines for
maximizing specic characteristics.
Chapter 4 Conguring the Imager
Describes how various parameters can be programmed to customize the imager for
your specic application.
Chapter 5 Application Engineering Support
Discusses the most common questions and concerns when adapting a LH2 Fixed
Position Imager in your application.
Chapter 6 Imager Servicing and Maintenance
Discusses the LH2 Fixed Position Imager warranty, maintenance and cleaning
procedures.
Appendices Detailed Supporting Information
Provides detailed information in specic areas such as the programming commands for
conguring various parameters of the LH2 Fixed Position Imager.
Chapter
9
Chapter 1
Introduction and Getting Started
Product Overview
The LH2 xed position imager is truly a revolutionary new 2D imager. The omnidirectional
decoding allows the reading of linear, stacked linear and matrix bar codes in any
orientation.
These state-of-the-art imagers with superior 32-Bit, 400 mHz microprocessors provide a
one piece solution combining illumination, imaging and decoding in an extremely small
package.
Dual optics used by the 1.3 million pixel SXGA (1280 x 1024) CMOS sensor provide
exceptional depth of eld. The near and far eld cameras can be programmed to be
switched ON and OFF in different combinations to tailor the reading capabilities of the
LH2 to t your applications.
The laser beam facilitates targeting. The adjustable targeting zone allows precise selection
of specic bar codes in the eld of view. The LH2 can be customized with advanced logic
through the internal embedded application engine. The embedded engine may be utilized
to intelligently process or manipulate scanned data before it is sent to an application.
Advanced functions such as Barcode Readability Index provide quantitative measures
for optimizing imager settings to realize maximum performance. The LH2 is rugged and
built to last. These 100% solid state imagers use proven CMOS technology, assuring
continuing performance and high reliability. It is designed for rough handling in tough
environments and has a small footprint to t into tight spaces.
The LH2 is available in standard RS232 interface. Custom mounting options, cable
lengths, connector types and pinouts are available.
1
Chapter 1
10
Chapter 1
11
Quick Start-Up Procedure
This section is for those who wish to start using the imager before reading the complete
manual. In only a few steps the imager will be operable.
Follow the appropriate steps depending upon whether your LH2 is congured to operate
with a RS232 interface.
Turn off the power to your PC and connect the imager to the RS232 communications port
depending on your cable conguration.
Note: You must provide +5 Volt DC power to the imager. This can be accomplished using
the power supply available from Opticon. If the power supply is obtained from another
source verify that it is identied with the CE mark. Turn on the power to the PC.
1) If you are operating in a Microsoft Windows 95/98/ 2000/ XP environment, you can set
the communication parameters using Hyper Terminal as follows:
• Open Hyper Terminal.
This can be done from Start>Programs>Accessories> Communications
• Select Hypertrm.exe to create a New Connection
• In the Connection Description dialog screen enter a name for the new le. If
desired, select an Icon. Click OK
• In the Connect To (Phone Number) dialog screen, in the box entitled: Connect
using. Select the communication port, for example, “Direct to Com 1” Click OK
• In the Com 1 Properties screen, enter the appropriate Port Settings:
Bits per second = 57600
Data bits = 8
Parity = None
Stop Character = 1
Handshaking = None
Click OK
• The hyper-terminal folder you just created will open. From the File pull-down
menu, select Properties then click on the Setting Tab
• In the Properties Settings dialog screen, Select Terminal keys for the Function,
arrow and control key; then Select ANSI for Emulation; the Back scroll buffer line
can remain at the default 500
Inhaltsverzeichnis
Andere Opticon Barcode-Lesegerät Handbücher
Opticon
Opticon OPN2002 Gebrauchsanweisung
Opticon
Opticon NFT 2100 Bedienungsanleitung
Opticon
Opticon OPH 1004 Bedienungsanleitung
Opticon
Opticon OPI 2002 Bedienungsanleitung
Opticon
Opticon LPN 1736 Bedienungsanleitung
Opticon
Opticon OPR 3101 Bedienungsanleitung
Opticon
Opticon OPL 2724 ZAPPER Bedienungsanleitung
Opticon
Opticon OPN2002 Benutzerhandbuch
Opticon
Opticon 25-USBQSTART-01 Bedienungsanleitung
Opticon
Opticon OPR 2001 Bedienungsanleitung
Opticon
Opticon OPN2002 Bedienungsanleitung
Opticon
Opticon Code Reader 2.0 Bedienungsanleitung
Opticon
Opticon OPL 972 Series Bedienungsanleitung
Opticon
Opticon OPL 7836 Bedienungsanleitung
Opticon
Opticon OPL 9712 Bedienungsanleitung
Opticon
Opticon PX-25 Bedienungsanleitung
Opticon
Opticon PX-35 Bedienungsanleitung
Opticon
Opticon NFT 1125 Series Bedienungsanleitung
Opticon
Opticon OPR 2001 Bedienungsanleitung
Opticon
Opticon OPR 2001 Bedienungsanleitung
Beliebte Barcode-Lesegerät Handbücher anderer Marken
POSMicro
POSMicro Datalogic PowerScan D7100 Bedienungsanleitung
Marson
Marson MT780 Kurzanleitung zur Einrichtung
NCR
NCR RealPOS Bedienungsanleitung
Motorola
Motorola SE3300 Kurzanleitung zur Einrichtung
Element
Element P130BT Bedienungsanleitung
Motorola
Motorola Symbol LS3008 Installations- und Betriebshandbuch
