Opticon OPR 3101 Referenzhandbuch

OPTICON - 1

BRIEF SETUP

OPR 3101 CONFIGURATION

INSTRUCTIONS

The reader is configured to default factory settings

and is supplied with information that gives you a

quick understanding of the product. More product

details, additional support, or configuration options

to your own preferences (by Universal menu book)

will be updated at www.opticon.com

To enable the reader to communicate to another

device, different steps can be taken, depending on

the situation.

Overview of situations

• The address of the device must be configured in

the reader. Possibly the address of the device

needs to be retrieved first.

• To connect an Opticon reader to an USB-HID

cradle, the reader must be configured.

• To connect an Opticon reader to a third party

dongle, the reader must be configured.

• In case a third party dongle is used, the address

and pin code need to be configured manually.

Consult your dongle’s manual how to obtain the

address and configure the pin code. You need

this information to configure the bar code reader.

The dongle's driver installs a serial port on the

computer, which is used by the bar code reader

to transmit the data.

• The reader can connect by scanning the other

device’s address label.

• To stop the connection manually use the special

disconnection label.

The necessary steps and instructions are

explained on the next pages:

Version1 - printedJuly, 2007

CAUTION: This information is subject to

change without prior notice.

This manual may not, in whole or in part, be

copied, photocopied, reproduced, translated or

converted to any electronic or machine

readable form without prior written consent of

Opticon Sensors Europe.

THE GENERAL USE AND FUNCTIONING OF

THE BAR CODE SCANNER IS DESCRIBED

IN THIS DOCUMENT. ALSO GENERAL

SETUP INSTRUCTIONS TO GET STARTED

ARE DESCRIBED IN THIS DOCUMENT. FOR

FURTHER INSTRUCTIONS CONSULT

OPTICON OR YOUR LOCAL DEALER.

2 - OPTICON

Overview of steps

Depending on the type of device to be connected,

take the steps as further described. To configure

the required options:

• scan the SET label

• scan the required option(s)

• scan the END label

After scanning the END label, the new settings are

stored in non volatile memory.

Reader to Cradle

• when using USB-HID interface: connect to USB-

HID cradle (step 2 B)

• for all interfaces: connect by scanning (step 3)

Reader to PC / Other device

• retrieve device address (step 1)

• connect to PC (step 2 A)

• security options (step 2 Optional)

• connect by scanning (step 3)

To disconnect the current reader:

• scan the disconnect label (step disconnect)

To return to default settings:

• scan the reset label (step reset)

---------------------------------------------------------------

[STEP 1]

– RETRIEVE ADDRESS

The address is mostly displayed on the product

label as a hexadecimal code (example: 00-11-F6-

03-39-69). Otherwise consult the documentation of

the device how to retrieve the device address code.

To enable the reader to communicate to the other

device, the reader must be configured with this

code. The easiest way to do this is to create a

barcode label of the hexadecimal code as

described below.

– CREATE LABEL

Opticon provides a simple on-line application on

http://opticonfigure.opticon.com/bluetooth.asp

• Type in the digits of the hexadecimal code in

numbers and capital characters without dashes,

dots and spaces (example: 0011F6033969).

• Submit the code into a barcode (example:

0011F6033969). You have to print the screen

to have it available for scanning.

---------------------------------------------------------------

[STEP 2 A]

CONNECT TO PC

[STEP 2 B]

CONNECT TO USB-HID

CRADLE

---------------------------------------------------------------

SET _ZZ_ ZZ

Connect to

PC _cnpc_ CNPC

END _ZZ_ ZZ

SET _ZZ_ ZZ

Connect to

Cradle

(USB-HID)

_cnC2_ CNC2

END _ZZ_ ZZ

OPTICON - 3

[STEP 2 OPTIONAL]

SECURITY OPTIONS

The third party dongle usually allows

authentication, which means a PIN-code can be

used to establish a secure connection. Note that

the PIN-code is case sensitive, e.g. there is a

difference between lower case und upper case

(example: difference between ‘a’ and ‘A’).

Set PIN-code table

---------------------------------------------------------------

SET _ZZ_ ZZ

Set PIN-code

label _PINS_ PINS

Scan PIN-

code input

see input tables

End PIN-code

label _PINE_ PINE

END _ZZ_ ZZ

a_$A_ $A

b_$B_ $B

c_$C_ $C

d_$D_ $D

e_$E_ $E

f_$F_ $F

0_Q0_ Q0

1_Q1_ Q1

2_Q2_ Q2

3_Q3_ Q3

4_Q4_ Q4

5_Q5_ Q5

6_Q6_ Q6

7_Q7_ Q7

8_Q8_ Q8

9_Q9_ Q9

A_0A_ 0A

B_0B_ 0B

C_0C_ 0C

D_0D_ 0D

E_0E_ 0E

F_0F_ 0F

4 - OPTICON

[STEP 3]

CONNECT BY SCANNING

– CRADLE

• Scan the device address barcode on the bottom

of the cradle.

–OTHER DEVICE

• Scan the address barcode that you just created in

the on-line Opticon application (step 1).

---------------------------------------------------------------

[STEP DISCONNECT]

(SET + END label not required):

---------------------------------------------------------------

[STEP RESET]

---------------------------------------------------------------

Manually disconnect

_+-DISC-+_ +-DISC-+

SET _ZZ_ ZZ

Reset _SO_ SO

END _ZZ_ ZZ
