Issue 5.3 March 2022

40-575/576/577/578/579 User Manual

PXI 2 Amp 1-Pole Ultra High Density Matrix Modules

Page (II) 2 AMP 1-POLE UHD MATRIX MODULES 40-575/576/577/578/579

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

2 AMP 1-POLE UHD MATRIX MODULES 40-575/576/577/578/579

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) 2 AMP 1-POLE UHD MATRIX MODULES 40-575/576/577/578/579

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

2 AMP 1-POLE UHD MATRIX MODULES 40-575/576/577/578/579

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Testing Operation ..................................................................3.3

Section 4

Programming Guide....................................................................4.1

Programming Options for PXI Modules ..............................4.1

Programming The UHD Matrix .............................................4.2

Using IVI Driver, Direct I/O Driver or VISA Driver ...............4.3

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting .........................................................................6.1

Section 7

Maintenance Information............................................................7.1

Switching System Test Tools ...............................................7.1

Relay Fault Finding ...............................................................7.2

CONTENTS

Page (VI) 2 AMP 1-POLE UHD MATRIX MODULES 40-575/576/577/578/579

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

2 AMP 1-POLE UHD MATRIX MODULES 40-575/576/577/578/579

pickering

Page (VII)

2 AMP 1-POLE UHD MATRIX MODULES 40-575 / 576 / 577 / 578 / 579

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

This product is not specically designed for use in hazardous environments, for example in explosive

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the host chassis are populated with blanking plates to prevent access to user I/O

signals that may be present. Blanking panels are available to order from Pickering in a variety of

slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

Not to be used in safety critical circuits, refer to the Pickering Interfaces’ terms & conditions of sale.

This module must not be used for the switching of Mains Circuits. For the switching of voltages up

to the module’s full specication, Secondary Circuit power supplies and the Device Under Test must

be fully isolated from the Mains Circuit and the safety earth.

The host chassis must be correctly installed and be connected to mains or factory safety ground,

please refer to your chassis installation manual.

Diagram Showing Separation Between The Mains Circuit and Secondary Circuit / DUT

For the purposes of this document, a Mains Circuit is an installation classied as Overvoltage

Category II up to 300V. Separation between the Secondary Circuit and Mains Circuit is achieved

by a transformer in which the primary windings are separated from the secondary windings by

reinforced insulation, double insulation, or a screen connected to the protective conductor terminal.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in

anti-static bags.

PXI Switching

Module

Device

Under Test

Power

Supply

Power

Supply

Host Chassis

Secondary Circuit

Mains

Circuit

Mains

Circuit

Mains/Factory

Safety Ground

Page (VIII) 2 AMP 1-POLE UHD MATRIX MODULES 40-575/576/577/578/579

pickering

Page (VIII) 2 AMP 1-POLE UHD MATRIX MODULES 40-575 / 576 / 577 / 578 / 579

pickering

CAUTION - PRODUCT DOCUMENTATION SYMBOL

Suitably qualied & trained users should ensure that the accompanying documentation is fully read

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Page 1.1

2 AMP 1-POLE UHD MATRIX MODULES 40-575/576/577/578/579

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI 2 Amp 1-Pole UHD Matrix 40-575/576/577/578/579

ISSUE 5.1 MAY 2019

Supported by

eBIRST

eBIRST switching system test tools simplify switching system fault-

nding by quickly testing the system and graphically identifying the

faulty relay.

For more information go to: pickeringtest.com/ebirst

• Highest Density Single-Slot 3U PXI 2A

Matrices With up to 448 Crosspoints

• 84x4, 64x6, 50x8, 36x12 and 28x16 Options

• Maximum Current 2A Hot or Cold Switching

• Switch up to 300VDC/250VAC and up to 60W

Max Power

• Uses Gold-Plated Contact Electro-mechanical

Relays

• VISA/IVI Drivers Supplied for Windows

• Supported by PXI or LXI Chassis

• Supported by

eBIRST

™

• 3 Year Warranty

X12

X10

X11

X14

X16

X13

X15

X17

X18

X19

X24

X22

X23

X21

X20

X25

X26

X27

X32

X30

X31

X29

X28

MATRIX

CROSSPOINT

X34

X56

X60

X33

X55

X57

X58

X59

X64

X61

X62

X63

X66

X68

X65

X67

X69

X70

X74

X71

X72

X73

X78

X75

X76

X77

X80

X82

X79

X81

X83

X84

40-575-001 84x4 Matrix Switching Diagram

The 40-575 supports 4 concurrent switch paths for X to X and Y to X connections, however

connections between different Y axis lines (e.g. Y1 to Y2, Y3 or Y4) are not permitted by the driver.

X12

X10

X11

X14

X16

X13

X15

X17

X18

X19

X24

X22

X23

X21

X20

X25

X26

X27

X32

X30

X31

X29

X28

MATRIX

CROSSPOINT

X34

X36

X40

X33

X35

X37

X38

X39

X44

X41

X42

X43

X46

X48

X45

X47

X49

X50

X54

X51

X52

X53

X58

X55

X56

X57

X60

X62

X59

X61

X63

X64

40-576-001 64x6 Matrix Switching Diagram

The 40-576 supports 6 concurrent switch paths for X to X and Y to X connections, however

connections between different Y axis lines (e.g. Y1 to any of Y2 to Y6) are not permitted by the driver.

The 40-575/576/577/578/579 are a range of high density matrix

modules able to switch up to 2 Amps or 300VDC/250VAC. They are

constructed using high quality electro-mechanical relays for high

switching condence. The range is as follows:

• 40-575-001 84x4, 1-Pole Matrix

• 40-576-001 64x6, 1-Pole Matrix

• 40-577-001 50x8, 1-Pole Matrix

• 40-578-001 36x12, 1-Pole Matrix

• 40-579-001 28x16, 1-Pole Matrix

The modules are designed for switching medium voltage and

power signals. The user signal connection is via a robust 160-pin

DIN 41612, 78-pin D-type or 50-pin D-Type connector that is fully

supported by the wide range of Pickering Interfaces cable and

connector accessories.

Page 1.2 2 AMP 1-POLE UHD MATRIX MODULES 40-575/576/577/578/579

pickering

SECTION 1 - TECHNICAL SPECIFICATION

2 Amp 1-Pole UHD Matrix – 40-575/6/7/8/9

pickeringtest.com

Overview

X12

X10

X11

X14

X16

X13

X15

Y10

Y11

Y12

Y13

Y14

Y15

Y16

MATRIX

CROSSPOINT

X18

X20

X24

X17

X19

X21

X22

X23

X28

X25

X26

X27

40-579-001 28x16 Matrix Switching Diagram

The 40-579 supports 14 concurrent switch paths

for X to X or 16 concurrent Y to X connections,

however connections between different Y axis lines

(e.g. Y1 to any of Y2 to Y16) are not permitted by

the driver.

X12

X10

X11

X14

X16

X13

X15

Y10

Y11

Y12

MATRIX

CROSSPOINT

X18

X20

X24

X17

X19

X21

X22

X23

X28

X25

X26

X27

X32

X29

X30

X31

X36

X33

X36

X35

40-578-001 36x12 Matrix Switching Diagram

The 40-578 supports 12 concurrent switch paths for X to X and Y to X connections, however

connections between different Y axis lines (e.g. Y1 to any of Y2 to Y12) are not permitted by the driver.

X12

X10

X11

X14

X16

X13

X15

X17

X18

X19

X24

X22

X23

X21

X20

X25

X26

X27

X32

X30

X31

X29

X28

MATRIX

CROSSPOINT

X34

X36

X40

X33

X35

X37

X38

X39

X44

X41

X42

X43

X46

X48

X45

X47

X49

X50

40-577-001 50x8 Matrix Switching Diagram

The 40-577 supports 8 concurrent switch paths for X to X and Y to X connections, however

connections between different Y axis lines (e.g. Y1 to any of Y2 to Y8) are not permitted by the driver.

Matrix Functionality

The 40-579 permits 14 concurrent X to X paths or 16

concurrent Y to X paths, the 40-575, 40-576, 40-577

and 40-578 permit 4, 6, 8 and 12 concurrent X to X

or X to Y paths respectively. As shown in the gure

below, X to Y connections (e.g. X15 to Y7) and X to X

connections (e.g. X18 to X27) are permitted, also any

number of X connections can be connected to to the Y

axis (e.g. X2, X8, X9 & X12 to Y5). However, the driver

prevents the connection of Y axis connections together

(e.g. Y10 to Y15).

X12

X10

X11

X14

X16

X13

X15

Y10

Y11

Y12

Y13

Y14

Y15

Y16

X18

X20

X24

X17

X19

X21

X22

X23

X28

X25

X26

X27

✔✔

✘

✔

Allowable Signal Paths For The 40-579 Matrix

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Pickering Steuereinheit Handbücher

Pickering

Pickering 40-521 Bedienungsanleitung

Pickering

Pickering Module Bedienungsanleitung

Pickering

Pickering PXI 30 A Bedienungsanleitung

Pickering

Pickering 40-252 Bedienungsanleitung

Pickering

Pickering 40-534 Bedienungsanleitung

Pickering

Pickering PXI 40-787 Bedienungsanleitung

Pickering

Pickering PXI 40-795-001 Bedienungsanleitung

Pickering

Pickering PXI 40-597 Bedienungsanleitung

Pickering

Pickering 40-567A Bedienungsanleitung

Pickering

Pickering BRIC Series Bedienungsanleitung

Pickering

Pickering 40-727 Bedienungsanleitung

Pickering

Pickering 40-540 Bedienungsanleitung

Pickering

Pickering PXI BRIC 40-560A Bedienungsanleitung

Pickering

Pickering 40-519B Bedienungsanleitung

Pickering

Pickering 40-670A Bedienungsanleitung

Pickering

Pickering PXI 40-145 Bedienungsanleitung

Pickering

Pickering 40-880 Bedienungsanleitung

Pickering

Pickering PXI 40-664A Bedienungsanleitung

Pickering

Pickering 41-180 Bedienungsanleitung

Pickering

Pickering PXI 40-710 Bedienungsanleitung

Pickering

Pickering 40-500 Bedienungsanleitung

Pickering

Pickering 40-884A Bedienungsanleitung

Pickering

Pickering 40-528A Bedienungsanleitung

Pickering

Pickering 45-541 Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
