Pride Mobility VICTORY 10 Bedienungsanleitung

VICTORY 10

PrideMobilityProductsCorp.

INFMANU3629/RevC/April2008

SAFETY GUIDELINES

NOTE: This owner’s manual is compiled from the latest specifications and product information avail-

able at the time of publication. We reserve the right to make changes as they become necessary. Any

changes to our products may cause slight variations between the illustrations and explanations in this

manual and the product you have purchased. The latest/current version of this manual is available on

our website.

Pride Provider:_____________________________________________________________________

Address:__________________________________________________________________________

PhoneNumber:__________________________

Purchase Date:__________________________ Serial Number:______________________________

WARNING! An authorized Pride Provider or qualified technician must perform the initial

setup of this scooter and must perform all of the procedures in this manual.

Thesymbolsbelowareusedthroughoutthisowner'smanualandonthescootertoidentifywarningsandimportant

information.It isveryimportantforyoutoread themandunderstandthemcompletely.

WARNING! Indicates a potentially hazardous condition/situation. Failure to follow

designated procedures can cause either personal injury, component damage, or

malfunction. On the product, this icon is represented as a black symbol on a yellow triangle

with a black border.

MANDATORY! These actions should be performed as specified. Failure to perform

mandatory actions can cause personal injury and/or equipment damage. On the product,

this icon is represented as a white symbol on a blue dot with a white border.

PROHIBITED! These actions are prohibited. These actions should not be performed at any

time or in any circumstances. Performing a prohibited action can cause personal injury

and/or equipment damage. On the product, this icon is represented as a black symbol with

a red circle and a red slash.

Pleasefilloutthefollowinginformationforquickreference:

088 609 661

Victory 10 www.pridemobility.com

CONTENTS

I. INTRODUCTION......................................................................................................................... 4

II. SAFETY......................................................................................................................................... 5

III. YOUR SCOOTER...................................................................................................................... 19

IV. BATTERIES AND CHARGING ............................................................................................ 24

V. OPERATION............................................................................................................................... 31

VI. COMFORT ADJUSTMENTS................................................................................................ 33

VII. DISASSEMBLY AND ASSEMBLY..................................................................................... 36

VIII.BASIC TROUBLESHOOTING ............................................................................................. 38

IX. CARE AND MAINTENANCE ................................................................................................ 40

X. WARRANTY................................................................................................................................43

APPENDIX I - SPECIFICATIONS ............................................................................................... 45

4www.pridemobility.com Victory 10

I. INTRODUCTION

SAFETY

WelcometoPride Mobility Products Corporation(Pride). The product you havepurchased combinesstate-of

the-artcomponentswithsafety,comfort,andstylinginmind.Weareconfidentthedesignfeatureswillprovideyou

withtheconveniences you expectduringyourdailyactivities. Understanding howto safelyoperateandcarefor

thisproductshould bring youyearsoftroublefree operation andservice.

Readandfollowallinstructions,warnings,andnotesinthismanualandall otheraccompanyingliterature before

attemptingtooperate this product for thefirst time. Inaddition, your safetydepends upon you,as well asyour

provider,caretaker,or healthcareprofessionalinusing goodjudgement.

Ifthereis anyinformationinthismanual which youdonotunderstand, or ifyourequireadditional assistance for

setupor operation, pleasecontactyourauthorized PrideProvider. Failuretofollowtheinstructions,warnings,

andnotesinthismanualandthoselocatedonyourPrideproductcanresultinpersonalinjuryorproduct

damageandwillvoidPride’sproductwarranty.

PURCHASER’S AGREEMENT

Byacceptingdeliveryofthisproduct,youpromisethatyouwillnotchange,alter,ormodifythisproductorremove

orrenderinoperableor unsafeanyguards,shields,or othersafetyfeaturesofthisproduct;fail,refuse,orneglectto

installanyretrofit kits from time totimeprovidedbyPridetoenhance or preserve thesafeuseofthisproduct.

SHIPPING AND DELIVERY

Beforeusingyourscooter,makesureyourdeliveryiscompleteassome components may be individuallypack-

aged.Ifyoudonotreceiveacompletedelivery,pleasecontactyourauthorizedPrideProviderimmediately.Where

damagehasoccurredduring transport, either to the packaging or content,please contact the delivery company

responsible.

INFORMATION EXCHANGE

Wewant to hearyourquestions,comments, and suggestionsaboutthismanual.Wewould also liketohearabout

the safety and reliability of your new scooter, and about the service you received from your authorized Pride

Provider. Please notifyusofanychange of address,sowecan keep youapprisedofimportantinformation about

safety,newproducts,and newoptionsthat canincreaseyour abilitytouseandenjoyyourscooter.Pleasefeelfree

tocontact us at the addressbelow:

USA: Canada:

PrideMobility ProductsCorporation PrideMobilityProducts Company

Attn.:Customer Care Department 380VansickleRoad Unit 350

182SusquehannaAvenue St. Catharines, OntarioL2R 6P7

Exeter, PA18643-2694 1-888-570-1113

customercare@pridemobility.com

1-800-424-8205

NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact

us and we will be glad to send you a new one immediately.

Victory 10 www.pridemobility.com

II. SAFETY

PRODUCT SAFETY SYMBOLS

Thesymbolsbelow are used on thescootertoidentifywarnings,mandatory actions, and prohibitedactions.Itis

veryimportantfor youtoreadand understand themcompletely.

Pinch/Crush points created during assembly.

Corrosive chemicals contained in battery.

EMI-RFI- This product has been tested and passed at an immunity level of 20 V/m.

Do not lift the mobility vehicle while seated in it.

Explosive conditions exist!

Read and follow the information in the owner’s manual.

6www.pridemobility.com Victory 10

II. SAFETY

Maximum seating weight.

Place unit on level ground and stand to one side when changing from drive mode

to freewheel mode or freewheel mode to drive mode.

Locked and in drive mode.

Unlocked and in freewheel mode.

Do not remove anti-tip wheels.

Wear safety goggles.

Use only AGM or Gel-Cell batteries to reduce the risk of leakage or explosive

conditions.

Do not raise or lower the power seat while the scooter is in motion.

Do not place the scooter in freewheel mode on a decline or incline.

Victory 10 www.pridemobility.com

II. SAFETY

Do not use a cell phone, walkie/talkie, laptop, or other radio transmitter while

operating.

Avoid exposure to rain, snow, ice, salt, or standing water whenever possible.

Maintain and store in a clean and dry condition.

Removal of grounding prong can create electrical hazard. If necessary, properly

install an approved 3-pronged adapter to an electrical outlet having 2-pronged plug

access.

Do not connect an extension cord to the AC/DC converter or the battery charger.

Contact with tools can cause electrical shock.

Do not allow unsupervised children to play near the scooter while the batteries are

charging.

Do not use batteries with different amp-hour (Ah) capacities. Do not mix old and

new batteries. Always replace both batteries at the same time.

8www.pridemobility.com Victory 10

II. SAFETY

Battery charger for indoor use only.

Disposal and recycling - Contact your authorized Pride Provider for information on

proper disposal and recycling of your Pride product and its packaging.

Contains Lead.

Keep your hands away from the tires when driving. Be aware that loose fitting

clothing can become caught in drive tires.

Victory 10 www.pridemobility.com

II. SAFETY

GENERAL

MANDATORY! Do not operate your new scooter for the first time without completely reading

and understanding this owner’s manual.

Your scooter is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides an

extensive variety of products to best fit the individual needs of the scooter user. Please be aware that the final

selection and purchasing decision regarding the type of scooter to be used is the responsibility of the scooter

user,whoiscapableofmakingsuchadecision,andhis/herhealthcareprofessional(i.e.,medicaldoctor,physi-

caltherapist, etc.).

The contents of this manual are based on the expectation that a mobility device expert has properly fitted the

scooterto theuserand hasassistedthe prescribinghealthcareprofessional and/ortheauthorizedPrideProviderin

theinstructionprocessforthe use of the product.

There are certain situations, including some medical conditions, where the scooter user will need to practice

operatingthe scooterinthe presenceofa trainedattendant.Atrainedattendantcan bedefinedas afamilymember

orcareprofessionalspecially trainedinassistingascooteruserin variousdailylivingactivities.

Asyoubegin usingyourscooterduring daily activities,youwillprobably encountersituationsinwhichyou will

needsomepractice. Simply take your timeand you willsoon be infull and confidentcontrol as youmaneuver

throughdoorways,onandoffelevators,upanddownramps,andovermoderateterrain.

Below are some precautions, tips, and other safety considerations that will help you become accustomed to

operatingthescooter safely.

MODIFICATIONS

Pridehas designed and engineered yourscooter toprovide maximummobility andutility.However,under no

circumstancesshouldyou modify,add,remove,ordisable any feature, part,orfunctionofyourscooter.

WARNING! Do not modify your scooter in any way not authorized by Pride. Do not use

accessories if they have not been tested or approved for Pride products.

REMOVABLE PARTS

WARNING! Do not attempt to lift or move your scooter by any of its removable parts,

including the armrests, seat, or shroud.

PRE-RIDE SAFETY CHECK

Gettoknowthefeelofyourscooteranditscapabilities.Priderecommendsthatyouperformasafetycheckbefore

eachusetomakesureyourscooteroperatessmoothlyand safely.

10 www.pridemobility.com Victory 10

II. SAFETY

Performthefollowinginspectionspriorto using yourscooter:

!Checkfor proper tire inflation. Maintainbut donot exceedthe psi/bar/kPa airpressure ratingindicated on

eachtire ifequippedwithpneumatictires.

!Checkallelectricalconnections.Makesure they are tight and not corroded.

!Checkallharnessconnections.Makesuretheyaresecuredproperly.

!Check the brakes.

!Checkbatterycharge.

Ifyoudiscover a problem, contact yourauthorizedPrideProviderforassistance.

TIRE INFLATION

If your scooter is equipped with pneumatic tires, you should check or have the air pressure checked at least

onceaweek.Proper inflation pressures will prolong the life ofyour tires and help ensurethe smooth operation

of your scooter.

WARNING! It is critically important that the psi/bar/kPa air pressure rating indicated on

the tire be maintained in pneumatic tires at all times. Do not underinflate or overinflate

your tires. Low pressure may result in loss of control, and overinflated tires may burst.

Failure to maintain the psi/bar/kPa air pressure rating indicted on the pneumatic tires at

all times may result in tire and/or wheel failure.

WARNING! Inflate your scooter tires from a regulated air source with an available pressure

gauge. Inflating your tires from an unregulated air source could overinflate them, resulting

in a burst tire.

WEIGHT LIMITATIONS

Yourscooteris ratedforamaximum weightcapacity.Referto thespecificationstable forinformation.

MANDATORY! Stay within the specified weight capacity for your scooter. Exceeding the

weight capacity voids your warranty. Pride will not be held responsible for injuries and/or

property damage resulting from failure to observe weight limitations.

WARNING! Do not carry passengers on your scooter. Carrying passengers on your scooter

may affect the center of gravity, resulting in a tip or a fall.

NOTE: If the tire on your scooter lists the psi rating only, use the following conversion formulas to find

the bar or kPa rating: bar = psi x 0.06895; kPa = psi x 6.89476.

INCLINE INFORMATION

Moreand more buildings have rampswith specifieddegrees of inclination,designed foreasy andsafe access.

Somerampsmay have turning switchbacks(180-degreeturns)thatrequireyou to have goodcorneringskillson

yourscooter.

!Proceedwithextremecautionasyouapproachthedowngrade of a ramp or other incline.

!Takewide swings with your scooteraround anytight corners. Ifyou dothat, the scooter’s rear wheels will

followawidearc,not cut the corner short, and not bump intoorgethunguponanyrailingcorners.

!Whendrivingdownaramp,keepthescooter’s speed adjustment set to the slowest speed setting to ensure a

safelycontrolleddescent.

!Avoidsudden stopsand starts.

Inhaltsverzeichnis

Andere Pride Mobility Roller Handbücher

Pride Mobility

Pride Mobility Go-Go Ultra X Bedienungsanleitung

Pride Mobility

Pride Mobility Sonic Bedienungsanleitung

Pride Mobility

Pride Mobility VICTORY SPORT Bedienungsanleitung

Pride Mobility

Pride Mobility Victory XL-8 Bedienungsanleitung

Pride Mobility

Pride Mobility go-go ES2 Bedienungsanleitung

Pride Mobility

Pride Mobility Legend 3-Wheel Scooter Bedienungsanleitung

Pride Mobility

Pride Mobility SPORTRIDER SR-XL3 Bedienungsanleitung

Pride Mobility

Pride Mobility Sonic Bedienungsanleitung

Pride Mobility

Pride Mobility Legend XL Bedienungsanleitung

Pride Mobility

Pride Mobility Legend SC3000 Bedienungsanleitung

Pride Mobility

Pride Mobility GO-GO ELITE TRAVELLER Plus Bedienungsanleitung

Pride Mobility

Pride Mobility Ultimate 3 Bedienungsanleitung

Pride Mobility

Pride Mobility Dash Bedienungsanleitung

Pride Mobility

Pride Mobility Legend XL Bedienungsanleitung

Pride Mobility

Pride Mobility Path rider Bedienungsanleitung

Pride Mobility

Pride Mobility Jazzy 600 ES Bedienungsanleitung

Pride Mobility

Pride Mobility Go-Go Elite Traveller SC40LR Bedienungsanleitung

Pride Mobility

Pride Mobility Victory ES9 Bedienungsanleitung

Pride Mobility

Pride Mobility Maxima Scooter SC940 Bedienungsanleitung

Pride Mobility

Pride Mobility Elite Traveller Series INFINFB2039 Leitfaden

Pride Mobility

Pride Mobility The Ultimate In Style & Performance Bedienungsanleitung

Pride Mobility

Pride Mobility Celebirty The Ultimate In Style &... Bedienungsanleitung

Pride Mobility

Pride Mobility scooter Bedienungsanleitung

Pride Mobility

Pride Mobility REVO Bedienungsanleitung

Beliebte Roller Handbücher anderer Marken

TEKTRO

TEKTRO CHEETAH Bedienungsanleitung

Douglas

Douglas Vespa Sprint Installationsanleitung

PLAYTIVE

PLAYTIVE AS-2448 Bedienungsanleitung

Ebinger

Ebinger DONKEY XL Bedienungsanleitung

Flyer

Flyer Mountain Benutzerhandbuch

BackCountry eBikes

BackCountry eBikes Storm Bedienungsanleitung

equipmed

equipmed FreeRoam II Bedienungsanleitung

Yoto

Yoto Lion Bedienungsanleitung

WESTHILL BIKES

WESTHILL BIKES LINK Bedienungsanleitung

BAnff

BAnff eProdigy series Bedienungsanleitung

Winther

Winther 475 Bedienungsanleitung

Jetson

Jetson JBZL17 Bedienungsanleitung

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Bedienungsanleitung

Carrera

Carrera impel Bedienungsanleitung

Afikim

Afikim Superlight SL-3 Bedienungsanleitung

CareCo

CareCo ZOOM Bedienungsanleitung

Douglas

Douglas Vespa G.S. Bedienungsanleitung

Gazelle

Gazelle with BOSCH System Bedienungsanleitung
