Rimage 480i Bedienungs- und Sicherheitshinweise

110762-000 Rev. B Page 1

Connecting the Power Cord

Installing the Ink Cartidges

Rimage 480i Setup and Installation

Power on the printer.

Lift the access door.

Remove the side cover. Connect the power cord

to the AC power adapter.

Connect the AC power adapter

to the printer.

Connect the AC power adapter

to the printer.

Connect the power cord to an outlet.

AC Power

Adapter Power Cord

After the printer has stopped

moving, lift both cartridge latches.

Slide the matching ink cartridge into

the cradle as shown.

Close each cartridge latch.

Close the access door.

Cradle

Important! Connect the USB cable only when

the software prompts you to connect it!

110762-000, Rev. B Page 2

When prompted to select a setup type,

select Rimage 480i Printer as shown below. In Windows XP, this window prompt opens.

Select Continue Anyway to install the required Rimage driver.

Power the PC on. Insert the CD Designer

software disc

in the PC.

If the software

installation does not

start automatically,

select Start|Run and

Browse and select

the Setup file from

the disc.

Installing the CD Designer Software

110762-000, Rev. B Page 3

If you have an additional printer, connect the

USB cable to the PC. Otherwise, go to step F.

Connect the USB from the printer to the PC as directed in

Step 1 of the Plug-n-Play window.

Windows 2000 automatically installs the printer driver. After it

finishes, go to step F.

Windows XP detects the new hardware and the Found New

Hardware Wizard appears.

Answer all of the dialogs before

continuing to step 3 from the Plug-n-Play window.

Windows 2000 automatically installs the printer driver for the

second printer. After it finishes, go to step F.

For Windows XP, answer all of the Found New Hardware Wizard

dialogs before continuing to step 5 (F).

When the printer driver installation is complete, select the

Next button on the Plug-n-Play window.

When the Plug-n-Play window appears, complete each of the steps in this

window before selecting the Next button. Steps 1 - 5 correspond

to B - F on this page.

Installing the Printer

BIOS Note: Change the PC BIOS so it does not boot from a USB device!

Refer to your PC documentation to see how to change the PC BIOS.

Dell™ computers - Set the USB Controller parameter to:

On without BIOS support.

Reattach the side cover so the cables come out the opening.

USB Cable

NOTE: Adobe Acrobat Reader 6.0 may automatically install.

110762-000 Rev. B Page 4

Aligning the Ink Cartridges

For Windows XP, select

Start|Settings|Printers and Faxes

For Windows 2000, select

Start|Settings|Printers

Right-click on

Disc Color 480i

and select

Printing Preferences.

Follow steps 1 - 5 from this window.

Press the button on front of the printer to open

the printer tray.

Select OK.

Select the

Align Cartridges

button.

Press the button to close the printer tray.

Close all Printing Preferences windows.

Remove the disc from the printer tray.

If you have a second printer, repeat step 5

for the second printer.

Select the Service tab.

110762-000 Rev. B Page 5

Printing a CD or DVD

Press the button on the front of the

printer to open the printer tray.

Press the button to close the printer tray.

The CD or DVD prints.

Navigate: Start > Programs > CD Designer

CD Designer opens.

From the File menu, select Open.

Navigate: Local Disk (C:) > Program Files >

Rimage > CD Designer > SAMPLE.btw

Place a CD or DVD on the printer tray.

Select Open.

The file opens in CD Designer.

From the File menu, select Print.

Press the button to close

the printer tray.

To print additional disks, repeat steps E - H.

When the CD or DVD has printed, remove it from the

printer tray.
