Safety Vision SV-1000 Bedienungsanleitung

PERSONAL DIGITAL VIDEO RECORDER AND FLASHLIGHT

Important Notices

Title: SV-1000 DVR Flashlight User Guide

Safety Vision attempts to provide information contained in this manual

based on the latest product information available at the time of publication.

However, because of Safety Vision’s policy of continual product improvement,

Safety Vision reserves the right to amend the information in this document at

any time without prior notice.

This material is condential and the property of Safety Vision. It is shared with

your company for the sole purpose of helping you with the operation of the

described equipment.

Safety Vision makes no warranty of any kind with regard to this material,

including, but not limited to, the implied warranties of merchantability and

tness for a particular purpose. Safety Vision shall not be liable for errors

contained herein or for incidental or consequential damages in connection

with the furnishing, performance, or use of this material.

Safety Vision expressly disclaims all responsibility and liability for the

installation, use, performance, maintenance, and support of third-party

products. Customers are advised to make their independent evaluation of

such products.

No part of this document may be photocopied, reproduced, or translated to

another language without the prior written consent of Safety Vision.

Safety Vision® is a registered trademark of Safety Vision, LP. All other products or

name brands mentioned in this document are trademarks of their respective

owners. For more information about Safety Vision and its products, go to

www.safetyvision.com or call 800-880-8855.

Table of Contents

Features...........................................................................4

Parts Included....................................................................................4

DVR Flashlight Components............................................................5

LCD Display.........................................................................................6

Interface Panel....................................................................................7

Installing and Recharging the Batteries..........................................8

Using the Flashlight...........................................................................8

Setting the Date and Time................................................................9

Inserting the miniSD™Card..............................................................9

Taking a Snapshot............................................................................11

Capturing a Video............................................................................12

Connecting the DVR Flashlight to a PC.........................................13

Returning the Unit for Service........................................................14

FCC Compliance Statement.............................................................15

Features

High powered white LED ashlight•

Built-in camera for still images or video•

Infrared sensors for clear images in darkness•

Integrated microphone•

LCD status and clock display•

Durable aluminum housing•

Ability to use rechargable Ni-MH or standard alkaline batteries•

Internal memory•

External miniSD™ card memory•

USB interface•

Parts Included

DVR Flashlight•

USB Cable•

12V DC Adaptor Charger•

Automotive Adaptor Charger•

2 GB miniSD• ™card (with adaptor)

3 Ni-MH Rechargable Batteries•

DVR Flashlight Components

Camera Lens1.

Captures single still images or video.

Microphone

Captures audio when recording video.

Infrared LEDs

Allows for brighter images when in darkness.

Flashlight Lens

Contains the high-intensity LED and reector.

Handle (containing battery compartment)

Contains 3 “C” size Ni-MH or alkaline batteries.

End Cap

Retains the batteries in the battery compartment.

LCD Display

Displays date, time, memory status, and remaining battery capacity.

Record Button

Initiates and stops a recording.

Flashlight Button

Operates the ashlight.

Function Button

10.

Illuminates the backlight and switches it between date and time.

Snapshot Button

11.

Captures single still images.

LCD Display

Battery Indicator1.

Displays as solid when batteries are at full strength and as fractions when

they become depleted.

Storage Capacity Indicator

Displays the remaining capacity of the miniSD™ card if one is installed.

The border ashes when no miniSD™ card is inserted and the DVR

Flashlight is using internal memory.

Data Indicator

Flashes when the DVR Flashlight is accessing memory.

SD Card Indicator

Illuminates when a miniSD™ card is inserted.

Recording Indicator

Illuminates when the DVR Flashlight is ready to record and ashes when

the DVR Flashlight is recording a video.

Date and Time Display

Displays date or time.

USB Indicator

Illuminates when the DVR Flashlight is attached to a PC via USB.

Interface Panel

miniSD™ Card Slot1.

Accepts a miniSD™card.

USB Port

Accepts a mini-USB plug.

12V DC Connection

Accepts the 12V DC Charger or Automotive Adaptor Charger.

Installing and Recharging the Batteries

Gently turn the End Cap counter-clockwise to open the battery compartment

and insert three “C” size batteries, positive terminals facing towards the lens.

The DVR Flashlight accepts both non-rechargable alkaline batteries or the

included rechargable Ni-MH batteries. Once inserted, replace the End Cap by

gently turning it clockwise.

WARNING - Do NOT attempt to recharge alkaline batteries in the DVR Flash-

light. The 12V DC Adaptor and Automotive Adaptor are for charging Ni-MH

batteries ONLY.

When the rechargable Ni-MH batteries have become depleated, use the

included 12V DC Adaptor Charger or Automotive Adaptor Charger. Plug the

adaptor into a power outlet, and plug the cord into the 12V DC Connection on

the Interface Panel. “Charge” appears on the LCD Display.

Using the Flashlight

The DVR Flashlight has three levels of brightness: Low, Medium, and High.

Pressing the Flashlight Button cycles through each of these before turning o

again. The ashlight can be set at any of the three brightness levels (or o)

while recording a video or taking a snapshot.

Setting the Date and Time

Setting the date and time is important, as this information will identify saved

videos and snapshots when viewed on a PC.

Pressing the Function Button once illuminates the LCD Display’s backlight.

Pressing it again will cycle between the date and time.

To set the date or time:

Press the Function Button until the date or time is shown on the LCD

Display (“Y”, “M”, and “D” appears at the bottom for the date, “H”, “M”

and “S” appears for the time).

Hold the Function Button for two seconds until the rst value begins to

ash.

Use the Record and Snapshot Buttons to increase or decrease the value.

Press the Function Button again to advance to the next value.4.

Repeat the process for all three values.5.

After the third value is set, press the Function Button one last time to6.

nalize the date or time.

Inserting the miniSD™ Card

Insert the miniSD™ card in the Interface Panel as shown below:

The DVR Flashlight writes all snapshots and videos to the miniSD™ card if one

is inserted. A miniSD™ card of up to 2 GB capacity is supported. If a miniSD™

card is not inserted, the DVR Flashlight writes all snapshots and videos to its

internal memory. 100 MB of internal memory is available for recording.

(Left: miniSD™ card inserted; Right, miniSD™ card not inserted)

Use the included miniSD™ Card Adaptor to insert the miniSD™ card into any

device that accepts standard SD cards.
