DE50x Headset Microphone

Owner’s Manual

Congratulations on your purchase of the Samson DE50x Headset Microphone. The DE50x is

a low profile, micro-miniature condenser headset microphone with a 2.5mm capsule. With its

omnidirectional pick up pattern, the DE50x delivers linear off-axis frequency response, resulting

in a clear and articulate sound perfect for house-of-worship, presentation, theater and fitness

applications. The microphone has been specially treated with a water resistant coating providing

extra protection from sweat and other moisture. In addition, there is a moisture guard drip-ring to

further protect the capsule and ensure reliable performance.

The DE50x Headset Microphone is well-suited for use with Samson wireless systems and with four

included adapter cables, the microphone can be used with most popular wireless systems. Other

accessories included in the kit are a clothing collar clip, four windscreens and a carry case that

holds the DE50x and all the accessories.

In the box, you’ll find a registration card enclosed, don’t forget to follow the instructions so that you

can receive online technical support and so we can send you updated information about this and

other Samson products in the future. We recommend you keep the following records for reference,

as well as a copy of your sales receipt.

Serial number: __________________________ Date of purchase: ___________________________

If you have any questions or comments regarding the DE50x Headset Microphone or any other

products from Samson, do no hesitate to contact us at [email protected].

With proper care and maintenance, your DE50x Headset Microphone will operate trouble-free for many

years. Should your DE50x Headset Microphone ever require servicing, a Return Authorization (RA) number

must be obtained before shipping your unit to Samson. Without this number, the unit will not be accepted.

Please visit www.samsontech.com/ra for an RA number prior to shipping your unit. Please retain the original

packing materials and, if possible, return the unit in its original carton. If your DE50x Headset Microphone

was purchased outside of the United States, contact your local distributor for warranty details and service

information.

Introduction

3DE50x Headset Microphone

The headset can be re-sized by sliding the ear

hooks to fit snug around your head. If the DE50x

is loose and will not stay in place, slide the ear

hook wires back for a tighter fit.

Adjust the microphone position by holding the left

ear hook wire and slide the boom forward or back.

For optimum performance the microphone should

be close to the skin and towards the corner of the

mouth, approximately a half inch away.

Position the moisture guard ring as close to the

capsule as possible.

For outdoor use and to help reduce p-popping,

install one of the included windscreens.

Fitting the DE50x Microphone

The DE50x includes four cables with connectors to use with the most popular wireless body pack

systems. To connect the cable to the headset:

1. Choose the right cable and connector that

works with your wireless system.

2. Line the cable up to the threaded terminal

on the back of the DE50x and screw the

cable into the headset. Do not over tighten

the cable.

3. Attach the included collar clip on the back

of your shirt collar and run the mic wire

from the DE50x headset to the wireless

body pack. Leave enough cable to allow you

to turn your head from side to side.

Connector Cables

5DE50x Headset Microphone

Mic Positioning

Position the DE50x microphone element about

0.25” –1” behind the corner of your mouth.

Since the DE50x is an omnidirectional capsule,

the end of the microphone does not need to be

facing your mouth. To avoid breadth noise and

p-pops, do not place the microphone directly in

front of your mouth.

If the microphone is too far away from your

mouth you will need to increase the gain and

reduce isolation.

To minimize additional noise, do not locate the

microphone tight against your cheek.

Specifications

Element Back electret condenser

Polar pattern Omnidirectional

Frequency Response 20Hz-20KHz

Sensitivity -35 ±3dB 1V/Pa/at1kHz

Output impedance 2kΩ ±30%

SPL max 130 dB

Operating voltage 1.5–12V DC

Cable: ø1.4mm*1.2m

Weight: 13g

Dimension: ø2.5mm

Included Adapter Cables 1/8” (3.5mm), Hirose®4-Pin, Switchcraft® TA3F,

Switchcraft®TA4F

Accessories: (4) Windscreens, Clothing Collar Clip, Carry Case

At Samson, we are continually improving our products, therefore specifications and images are

subject to change without notice.

Other trademarks and trade names are those of their respective owners.

7DE50x Headset Microphone

Specifications

Polar Pattern

Frequency Response

0°

180°

-5

-10

-15

-20

-25

45°

90°90°

135°

45°

135°

20 50 100 200 500

Frequency in Hz

1000 2000 5000 10000 20000 Hz

-20

-10

Samson Technologies Corp.

278-B Duffy Ave

Hicksville, New York 11801

Phone: 1-800-3-SAMSON (1-800-372-6766)

www.samsontech.com
