StarTech.com InfoSafe S252U2ERR Bedienungsanleitung

Manual Revision: 08/25/2011

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

For the most up-to-date information, please visit: www.startech.com

S252U2ERR

eSATA/USB to Dual Removable 2.5in SATA

HDD Enclosure with RAID

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit dierent from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected

names and/or symbols of third-party companies not related in any way to StarTech.com.

Where they occur these references are for illustrative purposes only and do not represent an

endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to

which this manual applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges

that all trademarks, registered trademarks, service marks, and other protected names and/or

symbols contained in this manual and related documents are the property of their respective

holders.

Instruction Manual i

Table of Contents

Introduction........................................................................................................................................................1

Packaging Contents ................................................................................................................................1

System Requirements ............................................................................................................................1

Front View......................................................................................................................................................2

Rear View........................................................................................................................................................2

Installation............................................................................................................................................................3

Hardware Installation..............................................................................................................................3

Driver Installation......................................................................................................................................3

How to Congure............................................................................................................................................4

Operating Modes......................................................................................................................................4

Using the Storage Device...........................................................................................................................5

Specications.....................................................................................................................................................7

Technical Support ...........................................................................................................................................8

Warranty Information....................................................................................................................................8

Instruction Manual 1

Introduction

The StarTech.com S252U2ERR Dual Removable 2.5” SATA External Hard Drive Enclosure provides

a complete, hardware-based external RAID storage solution for laptop or desktop computers.

Accommodating two 2.5” SATA 1.5/3.0 Gbps hard drives, this compact HDD enclosure supports

RAID congurations including JBOD (Single), Spanning (BIG/Concatenated), RAID 0 (Fast) and

RAID 1 (Safe).

Packaging Contents

• 1 x SATA Hard Drive Enclosure

• 1 x eSATA cable

• 1 x USB cable

• 1 x Universal Power Adapter with NA/UK/EU plugs

• 1 x Set of keys

• 1 x Stand

• 1 x Instruction Manual

System Requirements

• eSATA and/or USB enabled computer system

NOTE: eSATA host controller should support Port Multiplier technology if using JBOD

mode

• Windows 2000/ XP(32/64bit)/ Server 2003(32/64bit)/ Vista(32/64bit)/ 7(32/64bit)/

Server 2008 R2, Linux, and Mac OS 9.0 and up

Instruction Manual 2

Front View

Rear View

Door Twist Lock

Door Latch

Power/Activity LED

Reset switch

RAID Mode

switch

eSATA

connector

USB

connector

Power

connector

ON/OFF

switch

Instruction Manual 3

Installation

WARNING: Hard drives require careful handling, especially when being transported. If you are

not careful with your hard disk, lost data may result. Always handle your hard drive and storage

device with caution.

Hardware Installation

1. Make sure the power switch on the enclosure is set to OFF and the power adapter is

unplugged from the enclosure.

2. Unlock the drive bay doors by turning the twist lock clockwise with the provided keys.

3. Open the drive bay doors by pulling on the metal door latch forward.

4. Slide a bare 2.5”SATA hard drive into the drive bay and close the door behind it, making sure

it latches properly.

5. Lock the drive bay doors by turning the twist lock counter-clockwise with the provided keys.

6. Set the enclosure to the proper RAID mode via the selection switch on the rear.

7. Connect the power adapter from an electrical outlet to the enclosure.

8. Power on the enclosure by setting the power switch to ON.

9. Press the “Reset” button on the rear of the enclosure to ensure the proper RAID mode

becomes set.

10. Connect the enclosure to the computer via eSATA or USB, not both.

11. To remove drives from the enclosure, rst make sure that the disk volume is unmounted

within the operating system (see documentation for your operating system or host

controller) or the computer is o.

12. Turn the enclosure o by switch the power switch to OFF.

13. Unlock the drive bay door with the provided keys and open by pulling the metal latch

forward.

Driver Installation

No driver installation is required for these operating systems, as this enclosure is natively

supported, so the drivers are already installed.

Instruction Manual 4

How to Congure

Operating Modes

Mode Description

RAID 0

(Striping)

Striping combines multiple disks into a single large disk array.

The data is split evenly across each disk simultaneously. Read/

write performance is increased as a result, but failure of any one

disk will make the entire array unusable.

RAID 1

(Mirror)

Mirroring writes the same data across multiple disks, creating

exact mirror copies. This provides redundancy in case one drive

fails.

JBOD

(Single)

JBOD enables each hard drive to be seen as separate

independent drives. If only a single hard drive is installed,

ensure this mode is enabled.

NOTE: When using eSATA, this mode should only be used if the

eSATA host controller provides Port Multiplier (PM) support. If a

host is not PM-aware, only a single drive will be visible. No such

limitation exists if using the USB connection.

BIG

(Concat)

BIG concatenates multiple hard drives into a single large disk.

Provides no performance or redundancy benets.

Instruction Manual 5

Using the Storage Device

Windows 2000/XP/Vista/7

If you are using a brand new hard drive that does not contain any data, then you will rst

need to prepare the hard drive for use. From the main desktop, right-click on “My Computer”

(“Computer” in Vista/7), then select Manage. In the new Computer Management window, select

Disk Management from the left window panel.

Locate the Disk that says it is “Unallocated” (check hard drive capacity to conrm it’s the correct

hard drive) and then right-click in the section that says “Unallocated” and select “New Partition”.

Instruction Manual 6

The New Partition Wizard will appear. Follow the instructions in the wizard to complete setting

up the drive. Once complete, the Disk should show up as “Healthy” with a drive letter assigned

(i.e. E:). This drive letter should now appear within My Computer.

If you are installing a hard drive that already has data on it, then after plugging it in, the drive

should automatically show up with a drive letter assigned within My Computer.

Instruction Manual 7

Specications

Number of Hard Drives 2

Host Interface USB 2.0

SATA 3.0 Gbps

Chipset ID Silicon Image SiI5744

Connectors

1 x eSATA*

1 x USB mini-B

1 x DC Power

LEDs 2 x Power/Activity

Compatible Hard Drives 2.5” SATA 1.5/3.0 Gbps compatible,

height up to 9.5mm

Maximum Data Transfer Rate

eSATA: 3.0 Gbps

USB2.0: 480 Mbps

RAID Modes 0, 1, JBOD (single), BIG (concat)

Power Adapter 5VDC, 2A, center positive

Operating Temperature 5°C ~ 70°C (41°F ~ 158°F)

Storage Temperature -40°C ~ 80°C (-40°F ~ 176°F)

Humidity 8 ~ 90% RH

Dimensions 150.0mm x 101.0mm x 25.0mm

Weight 224g

Compatible Operating Systems Windows 2000/XP/Vista/7 (32/64-bit),

Mac OS 10.2 or later, Linux

* eSATA host controller must support Port Multiplier (PM) technology for use with JBOD
