StarTech.com PEX867WAC22 Bedienungsanleitung

Manual Revision: 05/16/2014

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

PEX867WAC22

PCI Express to AC1200 Wireless-AC

Network Card

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void the user’s

authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any interference,

including interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio

exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit

accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en

compromettre le fonctionnement.

Instruction Manual

IC Radiation Exposure Statement:

This equipment complies with IC RSS-102 radiation exposure limit set forth for an

uncontrolled environment. This equipment should be installed and operated with

minimum distance 20cm between the radiator and your body.

Déclaration d’exposition à la radiation:

Cet équipement respecte les limites d’exposition aux rayonnements IC dénies pour un

environnement non contrôlé. Cet équipement doit être installé et mis en marche à une

distance minimale de 20 cm qui sépare l’élément rayonnant de votre corps.

L’émetteur ne doit ni être utilisé avec une autre antenne ou un autre émetteur ni se

trouver à leur proximité.

FCC ID:VYTLP-9094

IC:11232A-PEX867WAC22

Use of Trademarks, Registered Trademarks, and other Protected Names and

Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do

not represent an endorsement of a product or service by StarTech.com, or an endorsement

of the product(s) to which this manual applies by the third-party company in question.

Regardless of any direct acknowledgement elsewhere in the body of this document,

StarTech.com hereby acknowledges that all trademarks, registered trademarks, service

marks, and other protected names and/or symbols contained in this manual and related

documents are the property of their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Product Overview ..................................................................................1

LED Indicator .............................................................................................................................................. 1

Installation ..............................................................................................2

Hardware Installation .............................................................................................................................. 2

Software Installation................................................................................................................................ 3

Verifying Installation................................................................................................................................ 3

Operation ................................................................................................4

Specications..........................................................................................5

Technical Support ..................................................................................6

Warranty Information............................................................................6

Instruction Manual

Introduction

Packaging Contents

• 1 x PCI Express Wireless-AC Card

• 2 x 5 dBi Dual Band Antennas

• 1 x Antenna Stand

• 1 x Low Prole Bracket

• 1 x Driver CD

• 1 x Instruction Manual

System Requirements

• Available PCI Express slot

• Windows® 8 / 8.1 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64), Windows Server®

2012, 2008 R2, 2003(32/64)

Product Overview

LED Indicator

Blinking – Activity on 2.4 or 5GHz connection

Instruction Manual

Installation

Hardware Installation

WARNING! PCI Express cards, like all computer equipment, can be severely damaged

by static electricity. Be sure that you are properly grounded before opening your

computer case or touching your card. StarTech.com recommends that you wear an

anti-static strap when installing any computer component. If an anti-static strap is

unavailable, discharge yourself of any static electricity build-up by touching a large

grounded metal surface (such as the computer case) for several seconds. Also be

careful to handle the card by its edges and not the gold connectors.

1. Turn your computer o and any peripherals connected to the computer (i.e. Printers,

external hard drives, etc.). Unplug the power cable from the rear of the power

supply on the back of the computer and disconnect all peripheral devices.

2. Remove the cover from the computer case. See documentation for your computer

system for details.

3. Locate an open PCI Express slot and remove the metal cover plate on the rear of the

computer case (Refer to documentation for your computer system for details.). Note

that this card will work in PCI Express slots of additional lanes (i.e. x4, x8 or x16 slots).

4. Insert the card into the open PCI Express slot and fasten the bracket to the rear of

the case.

NOTE: If installing the card into a low prole desktop system, replacing the

preinstalled standard prole bracket with the included low prole (half height)

installation bracket may be necessary.

5. Place the cover back onto the computer case.

6. Attach the included antennas:

a. Attach the antennas to the included antenna stand, then attach the antenna cable

to the connectors on the card.

b. Attach the antennas directly to the connectors on the card.

7. Insert the power cable into the socket on the power supply and reconnect all other

connectors removed in Step 1.

Instruction Manual

Software Installation

1. Insert the provided CD into your DVD/CD-ROM drive.

2. Select Autorun.exe from the Autoplay menu. If Autoplay is disabled on your system,

browse to your CD/DVD drive and run the application.

3. Select the Driver Installation option.

4. Follow the on-screen instructions to complete the installation.

NOTE: You may be prompted to restart once the install completes.

Verifying Installation

1. Open the Device Manager by right-clicking on Computer, and then select Manage.

In the new Computer Management window, select Device Manager from the

left

window panel (For Windows 8, open the Control Panel and select Device Manager).

Instruction Manual

2. Expand the “Network adapters” section. On a successful install, you should see the

following device in the list with no exclamation points or question marks.

Operation

Connecting to a wireless network is done through either the Windows wireless

conguration utilities, or through the Realtek utility. You must know the name of

the wireless network (SSID), the type of security it is using (if any) and its associated

password to connect to a wireless network. Consult the documentation for your

wireless access point (AP) or contact your network administrator for details.

Depending on your version of Windows, you can display the list of available networks

using one of the following methods:

Windows 8 Move the cursor to the upper right corner to open the Charms

Bar, select Settings and then select Wi

Windows 7 Click the network adapter tray icon

Windows Vista Click Start, then Connect To

Windows XP Right-click the wireless adapter tray icon and select View

Available Wireless Networks

For full operating instructions, please visit www.startech.com/PEX867WAC22

Instruction Manual

Specications

Host Interface PCI Express

Chipset Realtek - RTL8812AE

External Connectors 2 x RP-SMA (Coax; Reverse Polarity

SubMiniature A) Female

Supported Standards IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE

802.11n, IEEE 802.11ac

Antenna Conguration 2x2:2 (TxR:S)

Wireless Frequencies 2.400GHz ~ 2.484GHz

5.180GHz ~ 5.850GHz

Supported Security Schemes 64/128 bit WEP, WPA, WPA2 (TKIP/AES)

Operating Temperature 0°C ~ 60°C (32°F ~ 140°F)

Storage Temperature 0°C ~ 70°C (32°F ~ 158°F)

Humidity 10% ~ 90% RH

Dimensions 83 x 18 x 120mm

Weight 70g

Compatible Operating Systems

Windows® 8 / 8.1 (32/64bit), 7 (32/64),

Vista(32/64), XP(32/64)

Windows Server® 2012, 2008 R2, 2003(32/64)

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Andere Handbücher für PEX867WAC22

Inhaltsverzeichnis

Andere StarTech.com PCI-Karte Handbücher

StarTech.com

StarTech.com PEX2S952PW Bedienungsanleitung

StarTech.com

StarTech.com PEX16S952LP Bedienungsanleitung

StarTech.com

StarTech.com PEX2IDE Bedienungsanleitung

StarTech.com

StarTech.com 21050-PC-SERIAL-CARD Bedienungsanleitung

StarTech.com

StarTech.com PEXUSB3S2EI Bedienungsanleitung

StarTech.com

StarTech.com PEXSAT34 Systemhandbuch

StarTech.com

StarTech.com PEXSATA22I Systemhandbuch

StarTech.com

StarTech.com PEXUSB7LP Bedienungsanleitung

StarTech.com

StarTech.com PCI220USB Bedienungsanleitung

StarTech.com

StarTech.com ECHDCAP Bedienungsanleitung

StarTech.com

StarTech.com PCI2USB Bedienungsanleitung

StarTech.com

StarTech.com PEXUSB311AC3 Bedienungsanleitung

StarTech.com

StarTech.com PEXUSB314A2V Bedienungsanleitung

StarTech.com

StarTech.com 8STPEX1S953LP Bedienungsanleitung

StarTech.com

StarTech.com PEXSAT34SFF Bedienungsanleitung

StarTech.com

StarTech.com PCI2S485LP Bedienungsanleitung

StarTech.com

StarTech.com PEX8M2E2 Bedienungsanleitung

StarTech.com

StarTech.com 8STPEX1394B3LP Bedienungsanleitung

StarTech.com

StarTech.com PEX100S Bedienungsanleitung

StarTech.com

StarTech.com PEXUS313AC2V Bedienungsanleitung

StarTech.com

StarTech.com USB2HDCAPS Bedienungsanleitung

StarTech.com

StarTech.com 8STPEXUSB3S25 Bedienungsanleitung

StarTech.com

StarTech.com CB2S950 Bedienungsanleitung

StarTech.com

StarTech.com ST1000SPEXD3 Bedienungsanleitung

Beliebte PCI-Karte Handbücher anderer Marken

ERMA

ERMA SSI 1417 Bedienungsanleitung

SIIG

SIIG CyberSerial Dual PCI Montageanleitung

Moxa Technologies

Moxa Technologies CP-102E Bedienungsanleitung

I-Bus

I-Bus IBC2602 Bedienungsanleitung

Exsys

Exsys EX-60102 Bedienungsanleitung

Chelsio Communications

Chelsio Communications T5 Series Bedienungsanleitung

Conrad Electronic

Conrad Electronic 97 46 71 Bedienungsanleitung

Micro Innovations

Micro Innovations USB650A Bedienungsanleitung

KTI Networks

KTI Networks KF-310 Bedienungsanleitung

Asus

Asus SpaceLink WL230 Bedienungsanleitung

SIIG

SIIG SC2475 Bedienungsanleitung

TRENDnet

TRENDnet TEW-703PI Bedienungsanleitung

Belkin

Belkin F5D7000F Bedienungsanleitung

Pericom

Pericom PI7C7100 Bedienungsanleitung

ADLINK Technology

ADLINK Technology cPCI-3548 Bedienungsanleitung

Digium

Digium TE200 Series Bedienungsanleitung

Allo.com

Allo.com 2nd Gen E1/T1/J1 Bedienungsanleitung

Western Digital

Western Digital FireWire PCI Adapter Bedienungsanleitung
