Supereyes N005 Bedienungsanleitung
- 1 -
Handheld USB Digital Microscope
Model N005
User Guide
- 2 -
Contents
Safety Precautions .......................................................................................................... 2
Introduction ........................................................................................................................ 2
Computer System Requirement ......................................................................................... 3
Technical Specifications ...................................................................................................... 3
Package Information........................................................................................................... 3
Installation and use............................................................................................................. 3
Trouble Shooting................................................................................................................. 4
Technical Support ............................................................................................................... 5
Disclaimer............................................................................................................................ 6
Certifications....................................................................................................................... 7
Safety Precautions
1. To avoid electrostatic damage, do not touch the lens with finger.
2. Do not attempt to disassemble this product by yourself. Opening the covers may
expose you to dangerous voltage points or other risks.
3. When hands are wet, do not plug in or remove the adaptor or other connectors.
4. Do not clean the products with ethyl alcohol or other organic solvent.
5. Please use a lens brush or soft cloth to wipe clean.
6. Avoid touching lens with your fingers.
7. Temperature: 0°C ~ 40°C; Humidity: 45% ~ 85%.
8. If liquid entered, immediately turn off power. Please send to service center for
repair. Do not use blow dry.
Introduction
- 3 -
Thank you for purchasing Supereyes Digital Borescope. With this device you will be
able to see a hidden world. Prior to the first use, we recommend reading this manual
to get the best out of this device.
Computer System Requirement
Windows XP SP2 or above, Mac OS X 10.5 or above, Linux
CPU: Pentium 233MHz and above
Memory: 256MB
Interface: USB 2.0
HDD storage space: 600MB and above
Technical Specifications
Image sensor
0.3 Mega Pixels (interpolated to 2MP)
Magnification factor
10X
Focus range
45 ~ 50mm
Focus type
Fixed
Photo capture resolution
640 × 480, 320 × 240
Photo format
JPGE, BMP
Video capture resolution
640 ×480
Video format
High compression WMV, maximum 11 hours long
Display speed
Max 30f/s
Light Sources
LED illumination (adjustable by control wheel)
Interface
USB 2.0
Power source
5V DC from USB port
Operating System
Windows XP SP2 or above, Mac OS × 10.5 or above, Linux
OSD language
English, Chinese, Japanese
Software Bundle
Supereyes’ software with measurement and calibration
function
Max Size
Ø 7mm × 500 mm (tube length)
Package Information
1. The body of digital borescope.
2. CD for Supereyes Software and driver.
Installation and use
- 4 -
1. Plug the USB cable into PC or Mac.
For Mac OS 10.5 or above, please use Photo Booth or Facetime to open the
microscope;
For Windows XP SP1 or below, please install driver first.
For Windows XP SP2 or above, no driver is needed.
2. Install the Supereyes’ software.
Put Supereyes CD into CD-ROM (if you have any problems with CD, please go to
www.supereyes.cc to download software).
Click Supereyes Vx.x.Setup.exe in the CD to install software.
Note: this unit is plug and play. Other web camera software, such as MSN or
Google online chat, could open it.
3. Start Microscope in Supereyes software (suggested). Please refer to the
Supereyes Software User Manual.
4. If need, please fix the body of microscope into the clip of the tripod (for more
accurate operation, please choose professional microscope adjustable stand),
adjust the lens to the object inspected.
5. Choose a suitable distance between the microscope and the objects, and then
adjust the focus.
6. Adjust the LED light by touch button (not for all models) or control wheel.
Trouble Shooting
Trouble vision
Possible Reason
Solution
1
Blank screen
LED is closed;
Preview is closed;
No suitable devices;
Incorrect connection with PC.
Open LED;
Open preview;
Choose suitable
devices;
Connect USB again.
- 5 -
2
Vague picture,
discoloration,
slow speed
Dirty lens;
Incorrect focus;
Incorrect connection with PC;
The Configuration of PC is
too low;
Clean by Lens paper;
Adjust focus;
Connect USB again;
Choose new PC;
3
distortion
Incorrect connection with PC;
Trouble inside of microscope.
Connect USB again;
Contact to repair.
4
Flicker picture
(Wireless
model)
Bad frequency
Choose the suitable
frequency.
5
Cannot
recognized
Incorrect connection with PC;
Trouble inside of microscope.
Connect USB again;
Contact to repair.
Technical Support
Visit Supereyes website www.supereyes.cc to find solutions to common problems
and video tutorials. You can download drivers and documents under Technical
Support. Please email help@supereyes.cc if you need help.
- 6 -
Disclaimer
The manufacturer and distributor of this product shall not take the responsibilities
on the damages caused by the improper using of this product or other artificially
damages.
The content of this User Guide is based on the current specification of this product.
The manufacturer D&F Corp shall not take the responsibility of any inconsistent of
the specification to the product for the purpose of improvements and other reasons.
Meanwhile, D&F Corp do not have the obligation for updating the content and any
information of this manual momentarily.
Follow us
Facebook: http://www.facebook.com/pages/Supereyes/127271414107804
Twitter: https://twitter.com/SupereyesWorld
- 7 -
Certifications
