RX1211/RX1211RP User’s Guide

For Synology RackStation

RS2211+/RS2211RP+

RX121120120507

Table of Contents

TOC



5 Chapter 1: Get Started with RX1211/RX1211RP

5 PackageContents

6 HardwareSpecications

6 OperatingRequirements

6 Appearance

8 LEDBehavior

9 SafetyInstructions

11 Chapter 2: Set Up RX1211/RX1211RP

11 ToolsandPartsforHardDiskInstallation

11 InstallHardDisks

13 ConnectwithRS2211+/RS2211RP+

15 WorkwithRS2211+/RS2211RP+

16 LearnMore

CongratulationsonyourpurchaseofSynologyRX1211/RX1211RP.This

productisspeciallydesignedforthestorageexpansionofSynologyRackStation

RS2211+/RS2211RP+.Thisuser’sguidewillguideyouthroughtheinstallation.

PackageContents

Beforeinstallation,pleasecheckthepackagecontentstoverifythatyou

havereceivedtheitemsbelow.

Main Unit x 1 AC Power Cord

(RX1211: x1; RX1211RP: x2)

User’s Guide x 1

Screws for 3.5”

Hard Drives x 56

Screws for 2.5”

Hard Drives x 56

Expansion Cable

(Inniband x 1)

Get Started with

RX1211/RX1211RP

6 Chapter1:GetStartedwithRX1211/RX1211RP

HardwareSpecications

Internal HDD 12XSATA(II)

EXPANSION Port # 1XInniband

Max Capacity (Internal HDD) 12X3TB

Hot Swappable HDD Yes

Size (HxWxD) (mm) 88x445x570mm

Weight RX1211:11.9kg;RX1211RP:14.0kg

System Fan RX1211:4X(80x80mm);RX1211RP:4X(80X80MM)

Power Fan RX1211:1X(80x80mm);RX1211RP:4X(80X80MM)

Power Recovery Syncwithserver

AC Input Power Voltage 100Vto240VAC

Power Frequency 50/60Hz,SinglePhase

Operating Temperature 5°C~35°C(40°F~95°F)

Storage Temperature -10°C~70°C(15°F~155°F)

Relative Humidity 5%to95%RH

Maximum Operating Altitude 10,000feet

Certication FCCClassA,CEClassA

OperatingRequirements

Synology RackStation RS2211+/RS2211RP+withSynologyDSM3.1

andonwards

Appearance

Front View

Chapter1:GetStartedwithRX1211/RX1211RP 7

Back View

3 1 4 5 1 6

RX1211

RX1211RP

3910

10 11 1

7 8

1 4 5 1 6

Article Name Description

1LED

Indicators

TheLEDindicatorsareusedtodisplaythestatusofthesystem.

Forcompletedetails,pleaserefertothenexttable:LED

Behavior.

2Hard Drive

Trays

Theharddrivetraysaredesignedforloadingtheharddrives

withRX1211/RX1211RP.

3POWER

Button

ThePOWERbuttonisusedtoturnRX1211/RX1211RPon

oroff.Pressandholdthebuttonfor7secondstoshutdown

RX1211/RX1211RP.

Note: ThePOWERbuttononlyworkswhenyouslidetheAUTO/

MANUALswitch(No.5)toMANUAL.

4RESET

Button

TheRESETbuttonisusedtorestorethesettingstothefactory

default.

AUTO/

MANUAL

Switch

TheAUTO/MANUALswitchisusedtoenableordisable

automaticpoweron/off.IfitissettoAUTO,RX1211/RX1211RP

willbeturnedonoroffautomaticallywhentheconnectedSynology

RS2211+/RS2211RP+powersonoroff.

6EXPANSION

Port

TheEXPANSIONportisusedtoconnectRX1211/RX1211RPto

RackStation.

7 Fan

Thepowerfansarebuilttoexhaustwasteheatoutofthepower

supply.

Thesystemfans(insideRX1211/RX1211RP)arebuiltto

exhaustwasteheatoutofRX1211/RX1211RP.Ifthefanisnot

working,RX1211/RX1211RPwill“beep”everyfewseconds.

8 Chapter1:GetStartedwithRX1211/RX1211RP

Article Name Description

8Power Supply

On/Off Switch

Thepowersupplyon/offswitchisusedtoturnon/offthepower

supply.

9 Power Port Thepowerportiswhereyouconnectthepowercordto

RX1211/RX1211RP.

10 Power Supply

Safety Latch*

Thepowersupplysafetylatchisusedtosecurethepower

supplyinplace.

11 Beep Off

Button*

Thebeepoffbuttonisusedtoturnoffthebeepingsoundthat

warnsofpowerfailure.

* RX1211RPonly.

LEDBehavior

LED Behavior Description

POWER

(Back)

Solid Green Powerison

Off Powerisoff

LINK Solid Green SynologyRS2211+/RS2211RP+isconnected

Off SynologyRS2211+/RS2211RP+isdisconnected

ALERT Flashing Orange Systemfanisnotworking

Off Systemfanisfunctioning

STATUS

Solid Green RAIDisready

Flashing Green RAIDisdegraded

Off RAIDisnotreadyorcrashed

Activity

(On Tray) Flashing Green Diskisbeingaccessed

Hard Disk

Status

(On Tray)

Solid Green Diskisreadyandidle

Solid Orange Read/writeorothererrorsareencountered

Off Nointernaldiskisfound

Chapter1:GetStartedwithRX1211/RX1211RP 9

SafetyInstructions

TouseyourSynologyproductsafely,pleasefollowtheseinstructionsand

warningsatalltime.

Keepawayfromdirectsunlightandawayfromchemicals.Makesure

theenvironmentdoesnotexperienceabruptchangesintemperatureor

humidity.

DonotplacetheSynologyproductclosetoanyliquid.

Beforecleaning,unplugthepowercordrst.WipeSynologyproduct

withdamppapertowels.Donotusechemicaloraerosolcleanersto

cleanit.

DonotplacetheSynologyproductonacart,table,ordesk,whichisnot

stabletoavoidtheproductfromfallingover.

Thepowercordmustplugintotherightsupplyvoltage.Makesurethat

thesuppliedACvoltageiscorrectandstable.

Toremoveallelectricalcurrentfromthedevice,ensurethatallpower

cordsaredisconnectedfromthepowersource.

ToolsandPartsforHardDiskInstallation

• Ascrewdriver

• Atleastone3.5”or2.5”SATAharddisk

(Pleasevisitwww.synology.comforcompatibleharddiskmodels.)

Warning:Ifyouinstallaharddiskthatcontainsdata,systemwillformatthehard

diskanderasealldata.Ifyouneedthedatainthefuture,pleasebackitupbefore

installation.

InstallHardDisks

1 Pulltheclipinthedirectionasindicatedbelowtoremovetheharddrivetray.

2 Loadtheharddiskintheharddrivetray.

• For 3.5” Hard Disk: Placetheharddiskintheharddrivetray,andthen

tightenthescrewstosecuretheharddisk.

Set Up RX1211/RX1211RP

12 Chapter2:SetUpRX1211/RX1211RP

• For 2.5” Hard Disk: Placetheharddiskintheharddrivetray,turnthetray

upsidedown,andthentightenthescrewstosecuretheharddisk.

3 Inserttheloadedharddrivetrayintotheemptyharddrivebay.

Important:Makesurethetrayispushedinalltheway.Otherwise,theharddisk

mightnotbeabletofunctionproperly.

4 Pushthecliptoxtheharddisktray.

5 Repeatthestepsabovetoassembleallharddisksyouhaveprepared.

Note:IfyouwanttosetupaRAIDset,itisrecommendedthatallinstalledhard

disksareofthesamesizetomakethebestuseofharddiskcapacity.

Chapter2:SetUpRX1211/RX1211RP 13

ConnectwithSynologyRS2211+/RS2211RP+

1 Connectoneendofthepowercord(s)tothepowerportof

RX1211/RX1211RP,andtheothertothepoweroutlet(s).

2 ConnectoneendoftheexpansioncabletoRX1211/RX1211RP,andthe

othertoRS2211+/RS2211RP+.

RX1211 or RX1211RP

RS1211+ or RS1211RP+

3 TurnonRX1211/RX1211RP:

• If the AUTO/MANUAL switch is set to AUTO, RX1211/RX1211RPwillbe

turnedonoroffautomaticallywhentheconnectedRackStationpowersonoroff.
