OPERATING

INSTRUCTIONS

UNDERFLOOR

HEATING

CONTROLLER

UFPT24 (24 hour)

UFPT7 (7 day)

Programa

S TAT

1 2 3 4

PROGRAMCHANGE

HEATING ON

PROGRAM

ON OFF AUTO

1010

2020

3030

°C

24 hour digital

clock display

Chan e Button

sets days, hours, and minutes

and self cancelling override

Pro ramme Button

selects clock and ON/OFF times

and review

Indicator showing when the

Programa TAT is in either

continuous ON mode or in a

timed ON period in Auto

mode.

Thermostat Dial

sets the floor temperature

Temperature Marker/Heatin

Demand Indicator

UFPT Pro ramaSTAT

with cover hin ed open

Mode Selector Switch

(continuously ON,

continuously OFF, or AUTO

(timed) operation)

Contents

1 Programa TAT UFPT24 (24 hour) or UFPT7 (7 day)

2 Temperature Probe

3 3.5mm fixing screws

General

The Programa TAT combines the elements of timeswitch, floor thermostat and frostat in a single compact,

economical and stylish unit. A hinged cover hides the programme controls, but leaves access to the

thermostat dial and the button giving ON/OFF override of timer control. The Frostat protection works in

both programmed OFF periods and when set to permanent OFF for holidays. Rechargeable battery back

up is provided to retain clock and programme information in the event of a power failure.

Siting

The Programa TAT should not be installed in a wet area. Further siting instructions are given in the

Thermolay cable and mat instruction leaflet.

The Programa TAT provides a total control package for electric underfloor heating up to 16A.

Terminals are provided for connection of a temperature probe and heating mat or cable. These are

connected as shown in figure 1.

Typical Application

Installation

The UFPT24/7 underfloor heating controllers are designed to fit onto either a B 4662 recessed

single box or a B 5733 surface mount single box. The minimum box depth required is 16mm. The ideal

mounting height is at eye level for the shortest person who is likely to need to programme the unit. For details

of the installation of the temperature probe and heating cable or mat see the Thermolay instruction leaflet.

witch OFF the mains to the controller. Cut the cable tails

of the temperature probe and heating mat or cables to

length and strip sleeving and insulation as required.

Identify the wires and locate according to figure 2.

Supply cable with a minimum of 2.5mm2conductor size

must be used. Tighten the screw terminals onto the

wires and form the cables. Offer the unit up to the wall

box forming the cables as required finally locating and

tightening up the fixing screws supplied.

1 3 4 2

1342

Connections

1 - Neutral, 2 - Live,

3 & 4 - Volta e Free NO (normally open) contacts

5 & 6 - Non polarised external temperature probe.

figure 2

Non polarity

conscious external

temperature probe

Heatin

load

Lin

Link

Basic Circuit Connection

Fi ure 1 - Back View

witch ON the mains to the heating circuit, slide the mode selector to continuously ON, and turn the thermostat dial

fully anticlockwise to maximum temperature. Both the heating ON indicator and the heating demand indicator will

come ON (assuming the floor temperature is not above 30°C). If the thermostat dial is now gradually turned clockwise

the heating demand indicator will turn OFF. Turning the dial approximately 2.0°C anticlockwise will bring the heating

demand indicator ON again.

Remember to use the lowest setting of the thermostat dial consistent with comfort as significant savings on heating bills

can be made by a reduction of 1°C. The unit should now be programmed using either the UFPT24 or UFPT7

programming instructions.

Commissioning

1 2 3 4

PROGRAMCHANGE

HEATING ON

PROGRAM

ON OFF AUTO

1010

°C

24 hour digital

clock display

Chan e Button

sets days, hours, and minutes

and self cancelling override

Pro ram Button

selects clock and ON/OFF

times and review

Output status showing if

unit is ON or OFF

UFPT24 Programming Instructions

Indicator showing when timed

output is ON or unit is

continuosly ON.

Battery

This product has a factory fitted rechargeable battery. If the Programa TAT is left with its mains

power switched off for more than 1 month the display may go blank. In this case, switch mains on,

wait 4 hours, and apply reset - see 1 before programming.

Programming

Only two setting buttons are required, <Change> and <Program>. In normal use the <Change>

button is used to switch ON or OFF, overriding the timeswitch until the next programmed OFF or

ON time. During programming the <Change> button is used to set the hours and minutes. The

<Program> button is used to select the clock time or the 4 programmed ON/OFF times and to

review them once they have been set. Each time the <Program> button is pressed the display will

flash either the hours or minutes in turn, starting with the clock then the first ON time, first OFF

time, second ON time etc. Wherever the hours or minutes are flashing they may be set using the

<Change> button. Once set the <Program> button is pressed again to proceed to the next stage.

Normal Operating Mo e

In normal operation the unit will display the correct time with the colon flashing. The output

status will be shown by either ON or OFF on the display.

OFF

1 2 3 4

1 To Reset Before Programming

(To alter clock time or modify pro rammes - see section 5)

To clear programmes from memory and reset the

UFPT24 press and hold down both buttons until the

display goes blank. Release buttons and display will fill

with its complete range of characters and then clear to

show clock and hour digit flashing. This procedure is

essential on installation and recommended if major

reprogramming is required subsequently.

You are now in the clock setting mo e

at the beginning of the programme sequence

1 2 3 4

Programming sequence

Note: Pauses between button presses greater than 1 minute during programming will

result in automatic return to the operating mode.

2 Setting Clock (after reset)

i Hour Settin - Press the <Change> button to advance the

hour setting. For rapid hour selections press and hold

down <Change> button.

etting clock

Programme 1 ON

Programme 1 OFF

Programme 2 ON

Programme 2 OFF

Programme 3 ON

Programme 3 OFF

Programme 4 ON

Programme 4 OFF

Operating Mode

......

....➔

1 2 3 4

ii Minute Settin - Press the <Program> button briefly to select

the minutes - display shows clock symbol and minute digits

flashing. Press the <Change> button to advance the minutes

setting. For rapid minute selection press and hold down

<Change> button. (Note: 16 hours shown as example of hours set)

iii

Press <Program> button briefly - clock is now set and display

shows ready for the first programme ON time with ON and

hours

digits flashing.

1 2 3 4

3. To Set Programme ON/OFF Times (after clock setting)

iPress <Change> button to advance the hour setting for the first programme ON

time.

ii Press <Program> button briefly to select minutes - display

shows minute digits and ON flashing. Press <Change>

button to advance minutes setting. (Note: 16 hours shown as

example of hours set).

iii Press <Program> button briefly - the first ON time is now

set and display shows ready for the first OFF programme

time.

iv Now set the hours and minutes as before.

vRepeat steps i to iv to set the remainder of the 3 programme ON/OFF times as

required. Note: Any unused ON/OFF programmes must be left blank and should be

bypassed by pressing the <Program> button until the display shows normal

operating mode. Do not programme ‘0’s into unused programmes.

IMPORTANT After setting a clock time which falls within a programmed ON

period, the unit will not switch ON. Press the <Change> button to switch the UFPT24

ON. After this the unit will operate normally to the programmes set.

1 2 3 4

OFF

1 2 3 4

4. Programme Review

To fast review the set programmes or for quick exit to normal operating mode - press

and hold down the <Program> button.

Normal review can be carried out by pressing the <Program> button briefly which reviews

the clock time with the whole display flashing. Further brief pressing of this button reviews

the programme ON and OFF times in sequence again with the whole display flashing.

5. Initiating Programme Mo e

This is required when making changes to the clock time or programme times and

can be initiated any time during the normal operating mode. Press the <Program>

button briefly and the clock symbol, hours and minutes symbols on the display will

flash - this is review mode. Further brief pressing of the <Program> button will

display the ON and OFF programmes in sequence. Having reached the clock or

programme time requiring change, press the <Change> button briefly to initiate

programme mode and then follow steps 2 and 3 as required. Having completed the

change press and hold down the <Program> button until normal operating mode

is reached and then release.

6. Cancelling Programmes

Any ON/OFF programme can be cancelled by clearing its ON and OFF time.

Follow step 5 and when into the ON or OFF programme to

be cancelled press the <Change> button until the hour

digits show - -: then press the <Program> button briefly to

clear the programme. The display will show the hour and

minute dashes and ON or OFF flashing. (ON and OFF

programmes have to be cancelled separately.)

7. Self Cancelling Overri e

To change the output status from ON to OFF or vice versa during normal

operation press the <Change> button. The output status will change and indicate

override is in operation by flashing either the ON or OFF symbol on the display.

The override will end at the next programmed change, or sooner if the <Change>

button is pressed again.

1 2 3 4

1 2 3 4 5 6 7

PROGRAMCHANGE

HEATING ON

DAY

ON OFF AUTO

°C

24 hour digital

clock display

Chan e Button

sets days, hours, and minutes

and self cancelling override Pro ramme Button

used to select the clock

time and day and the 6

ON/OFF programme

times and days and to

review them once set

Indicator showing when timed

output is ON or unit is

continuosly ON

UPFT7 Programming Instructions

Output status showing if

unit is ON or OFF

Battery

This product has a factory fitted rechargeable battery. If the Programa TAT is left with its mains

power switched off for more than 1 month the display may go blank. In this case switch mains

on, wait 4 hours, and apply reset - see 1 before programming.

Programming

This is a seven day (weekly) timeswitch which has six programmes, each of which can be block

programmed to work on all of the five weekdays, both weekend days, or all 7 days (24 hour

operation). Programmes can also be designated to operate on individual days. Only two setting

buttons are required, <Change> and <Program>. In normal use the <Change> button is used to

switch ON or OFF, overriding the timeswitch until the next programmed OFF or ON time.

During programming the <Change> button is used to set the hours, minutes and days. The

<Program> button is used to select the clock time and day or the 6 programmed ON/OFF times

and days and to review them once they have been set. Each time the <Program> button is pressed

the display will flash either the days, hours or minutes in turn, starting with the clock time and

day then the first ON time and day(s), first OFF time, second ON time and day(s) etc. Wherever

the days, hours or minutes are flashing they may be set using the <Change> button. Once set the

<Program> button is pressed again to proceed to the next stage.

Normal Operating Mo e

In normal operation the UPFT7 will display the correct day and its time with the colon

flashing. The output status will be shown by either ON or OFF on the display.

1 To Reset Before Programming

(To alter clock time or modify pro rammes - see section 5)

To clear programmes from memory and reset the UPFT7

press and hold down both buttons until the display goes

blank. Release buttons and display will fill with its

complete range of characters and then clear to show clock

and day 1 symbol flashing. This procedure is essential on

installation and is recommended if major reprogramming

is required subsequently.

You are now in the clock setting mo e at the beginning

of the programme sequence

OFF

1 2 3 4 5 6 7

etting clock

Programme 1 ON

Programme 1 OFF

Programme 2 ON

Programme 2 OFF

Programme 3 ON

Programme 3 OFF

Programme 4 ON

Programme 4 OFF

Programme 5 ON

Programme 5 OFF

Programme 6 ON

Programme 6 OFF

Operation Mode

......

....➔

Programming sequence

Note: Pauses between button presses greater than 1 minute during

programming will result in automatic return to the operating mode.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Timeguard Controller Handbücher

Timeguard

Timeguard RTS113 Programmierhandbuch

Timeguard

Timeguard TLRX05 Handbuch

Timeguard

Timeguard NSLDD1000 Handbuch

Timeguard

Timeguard TS900N Montageanleitung

Timeguard

Timeguard TRT039N Handbuch

Timeguard

Timeguard RTS113Q Programmierhandbuch

Timeguard

Timeguard PDFMMINIL Handbuch

Timeguard

Timeguard LEDPRORFKB Handbuch

Timeguard

Timeguard SLB2300RF Handbuch

Timeguard

Timeguard TS900B Bedienungsanleitung

Timeguard

Timeguard PDFM1500 Handbuch

Timeguard

Timeguard SLDD1000 Handbuch

Timeguard

Timeguard SLW360L Handbuch

Timeguard

Timeguard MLB3000 Handbuch

Timeguard

Timeguard SLFM360L Handbuch

Timeguard

Timeguard ELU56 Handbuch

Timeguard

Timeguard SureTime STLW1000 Handbuch

Timeguard

Timeguard SLB2300RF Handbuch

Timeguard

Timeguard PDSM1500 Handbuch

Timeguard

Timeguard SLW360N Handbuch

Timeguard

Timeguard PDRS1500N Montageanleitung

Timeguard

Timeguard SLFM360N Handbuch

Timeguard

Timeguard MLSA360N Handbuch

Timeguard

Timeguard E269H-Synchronous Handbuch

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
