The Dual WAN VPN Firewall Router (TW100-BRV324) provides network

load balancing, a network fail-safe backup and secure Virtual Private

Network (VPN) access for up to 70 remote users. Smooth network

loading, ensure no network downtime and allow employees to securely

access your network from the Internet—all with a single router.

Access local area network resources remotely using 70 IPSec or 10

Microsoft-VPN supported connections. Advanced SPI, NAT and NAT

Traversal firewall encryption protects against Internet attacks. Improves

peak-network-loading performance and eliminate network downtime with

the use of two WAN ports. Remotely access a network and share the

Internet with ease knowing your network resources are well protected

TW100-BRV324

Dual WAN Advanced VPN Router

TW100-BRV324

rev:10.19.2009

• Dual WAN ports (10/100Mbps) provide load balancing during peak Internet usage periods

• Supports up to 70 VPN connections using IPSec technology

• Supports up to 10 VPN connections using PPTP (Microsoft VPN) technology

• Install the additional WAN port to ensure zero downtime

• Supports 100 sessions of VPN pass-through for PPTP, IPSec and L2TP

• Hosts up to 253 clients

• 4-port Auto-Sensing switch automatically determines Ethernet speed

• Supports high speed cable modem, xDSL modem (Dynamic/Static IP, PPPoE, PPTP) and fiber to the home (FTTH )

• Works with Windows 95/98/ME/NT/2000/XP/Vista, Unix and Mac operating systems

• Manage your network with Network Address Translation (NAT), Network Address Port Translation (NAPT) and NAT Traversal Support

• Stateful Packet Inspection (SPI) firewall protects against Denial of Service attacks

• Schedule email alerts and manage event logs

• Manage Access Control from defined addresses, URLs and content filtering lists

• Supports manual key, IKE, PKI, DES (56bit) 3DES (168bit) and AES encryption

• SHA-1, MD5, PKI certificate, authentication and Online Certificate Status Protocol (OCSP)

• Virtual Private Network Consortium (VPNC) certification

• Support for Dead Peer Detection (DPD) in IPSec traffic

• Protocol support for PPPoE, PPTP client for DSL connection, Big Pond cable, SingTel RAS and Network Time Protocol (NTP)

• Additional security authentication with Password Authentication Protocol (PAP and Challenge Handshake Authentication Protocol (CHAP) for

PPPoE

• Easy configuration using Web Browser

• Flash memory enables firmware upgrades and a save/restore router configuration

• Supports DMZ, Multi-DMZ and 40 virtual servers(port forwarding)

• Quality of Service (QoS) technology prioritizes bandwidth for select applications such as Voice of IP and streaming video.

• Supports Static Routing, RIP 1 RIP 2, and Dynamic DNS Service

• Set up the router in minutes with Universal Plug and Play (UPnP) support

• 5-year limited warranty

FEATURES

router

Protocols

Firewall

Security

Local Port

Internet Port

LEDs

Power

Humidity

Temperature

Certifications

• IEEE 802.3 and 802.3u

• NAT, PPPoE, HTTP, DHCP, TCP/IP, UDP, PAP, CHAP, RIP1and DDNS

• 235 x 148 x 33 mm (9.25x 5.82 x 1.29 inches)

• NAT, NAPT, NAT T, Stateful Packet Inspection, Attack Alert Emails and Log and Denial of Service

• Access Control, IP Addressing, URL and Content Filtering

• 4 x Auto-MDIX 10/100Mbps Fast Ethernet LAN Ports

• DC 5v3.0A External Power Adapter

• Operating: 0° to 40° C (32° to 104° F); Storage: -10° to 70° C (14° to 158° F)

• Operating: 0 % ~ 80 % (non-condensing) Storage: 0% ~ 95% (non-condensing

• CE, FCC

• 2 x Auto-MDIX 10/100Mbps Fast Ethernet WAN Ports

• Power, Status, WAN1, Link/Act, 10 ,100, LAN and WAN2

• 363g (12.8 oz.)

Dimensions (LxWxH)

Weight

Standards

Hardware

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

Dual WAN Advanced VPN Router

TW100-BRV324

RELATED PRODUCTS

TW100-BRV304

TW100-BRF114

TW100-BRV204 Cable/DSL 4-Port VPN Firewall Router

Cable/DSL 4-Port Advanced VPN Firewall Router

Cable/DSL 4-Port Firewall Router

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

NETWORKING SOLUTIONS

SPECIFICATIONS

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

PACKAGE CONTENTS

• CD-ROM (user’s guide)

• TW100-BRV324

• Quick installation guide

• Power adapter

Reset Button • Reset to Factory Default Settings

10/100Mbps

Notebooks with

10/100Mbps PC Cards

(TE100-PCBUSR)

Cable/DSL Advanced

VPN Firewall Router

(TW100-BRV304)

Home

Office

Corporate

Office

Workstations with

PCI Adapter

Dual WAN Advanced

VPN Router

(TW100-BRV324)

INTERNET

Virtual Private Network

Workstation with

10/100Mbps PCI Adapter

(TE100-PCIWN)

Wireless AP

10/100Mbps Switch

Cable/DSL

Modem

Internet Internet

Notebook with

10/100Mbps PC Card

(TE100-PCBUSR)

Cable/DSL VPN

Firewall Router

(TW100-BRV204)

Security

VPN (IPSec)

VPN Tunnels

Pass-Through

• NAT Firewall, SPI Firewall

• URL Filter, Access Control, Password Protection, Email Alert and Logs

• MD5-HMAC/SHA1-HMAC Authentication, DES-CBC, 3DES-CBC Encryption, Internet Key Exchange, Manual Key Negotiation

• 70 (IPSec), 10 (PPTP)

• IPSec, PPTP, L2TP (100 Sessions)

Firewall

Router
