TRENDnet TE100-S50g Bedienungsanleitung

TE100-S50g

TE100-S80g

H/W: V1

Quick Installation Guide

Table of Contents

Version 04.01.2009

English ......................................................................................................

Technical Specifications .............................................................................

Troubleshooting ..........................................................................................

1. Before You Start

2. Hardware Installation .........................................................................

3. LEDs ..................................................................................................

.................................................................................

Installation Requirements

?A computer with a network adapter installed

?CAT-5, CAT-5e or CAT-6 Network Cable

The surface must support at least 1.5 Kg for the Switch

The power outlet should be within 1.82 meters (6 feet) of the switch

Visually inspect the DC power jack to make sure that it is securely

connected to the power adapter

Make sure that there is proper heat dissipation from and adequate

ventilation around the switch

Do not place heavy objects on the switch

Package Contents

1. Before You Start

English

?TE100-S50g/TE100-S80g

?Multi-Language Quick

Installation Guide

AC Power Adapter (7.5V DC, 1A)

Rubber Feet

English

Application TE100-S50g

TE100-S80g

60m

Full Power

60m

Delivers less power

to unused ports

100m

on on

less power

20m

Regular

Switch

GREENnet

Switch

20m

Delivers less power

when devices are off

Delivers less power

with shorter

cable lengths

on on

off less power

*Max power savings compared with standard TRENDnet switches.

60m

Full Power

60m

100m

20m

Regular

Switch

GREENnet

Switch

20m

Delivers less power

with shorter

cable lengths

Delivers less power

to unused ports

on on

less power

Delivers less power

when devices are off

on on

off less power

*Max power savings compared with standard TRENDnet switches.

2. Hardware Installation

English

1. Connect the AC Power Adapter to

the TE100-S50g/TE100-S80g and

then to a power outlet.

2. Connect a CAT-5, CAT-5e or CAT-6

RJ-45 network cable from the

computer to an available Ethernet

port on the TE100-S50g/

TE100-S80g.

3. LEDs

English

Link/ACT

Green(Solid): Link to another

device.

Green(Blinking): Activity is

occurring from the link.

Not Illuminated: Nothing is

detected on the port.

Power

Green: Power is on.

Not Illuminated: Power is off.

Your configuration is now complete.

To ensure the highest level of customer service and support, please take a moment to

Thank you for choosing TRENDnet

100Mbps

Green: Connection for the port is

100 (Full/Half)

Not Illuminated: Connection for

the port is 10(Full/Half) or

nothing is detected on the port.

IEEE 802.3 10BASE-T

IEEE 802.3u 100BASE-TX

IEEE 802.3x Flow Control

Network Media

Standards

Ethernet: 2-Pair UTP/STP CAT-3, -4, -5

Fast Ethernet: 2-Pair UTP/STP CAT-5, -5e , -6

Data Transfer Rates

Ethernet: 10Mbps (half-duplex), 20Mbps (full-duplex)

Fast Ethernet: 100Mbps (half-duplex), 200Mbps

(full-duplex)

TE100-S50g: 5 x 10/100/1000 Auto-MDIX RJ-45 ports

TE100-S80g: 8 x 10/100/1000 Auto-MDIX RJ-45 ports

Data RAM Buffer TE100-S50g: 384Kbytes per device

TE100-S80g: 768Kbytes per device

Hardware

Packet Filtering/

Forwarding Rate

10Mbps Ethernet: 14,880pps (packet per second)

100Mbps Fast Ethernet: 148,800pps

Technical Specifications

Protocol/Topology

Interface

CSMA/CD / Star

Filtering Table

MAC Address Learning

Switch Fabric

Power Consumption

Automatic Update

1K entries per device

TE100-S50g: 1Gbps Forwarding Capacity

TE100-S80g: 1.6Gbps Forwarding Capacity

TE100-S50g: 2.1W (max)

TE100-S80g: 2.5W (max)

Power, Link/ACT, 100Mbps

Diagnostic LEDs

Power Adapter 7.5V DC, 1A External Power Adapter

TE100-S50g: 116 x 25 x 70 mm (4.57 x .98 x 2.76 in.)

TE100-S80g: 136 x 25 x 70 mm (5.35 x .98 x 2.76 in.)

TE100-S50g: 225g

TE100-S80g: 265g

Dimensions

Weight

Temperature Operating: 0° ~ 40° C (32° ~ 104° F)

Storage: -10° ~ 70° C (14° ~ 158° F)

Certification CE, FCC

Hardware

Humidity Operating: 10% ~ 90%

Storage: 5% ~ 90%

Troubleshooting

Q1:

A1:

Q2:

A2:

Q3:

A3:

Q4:

A4:

Q5:

A5:

After connecting the switch to a power outlet, the LEDs do not turn on.

Check the connection of the external power adapter to the TE100-S50g/

TE100-S80g and the power outlet. Also check that the power outlet is

receiving power.

When I connect a computer to the switch's port, the LINK/ACT LED turns on,

but the 100Mbps LED remains off.

When the 100Mbps LED is off, the computer's connection speed is 10Mbps.

After I connect my PCs to the switch, I am unable to share files.

First, check the LEDs on the switch. Make sure the Link/ACT LED is on.

Second, check the network cable. The minimum length of the cable is 1.5 meters

and the maximum length of the cable is 100 meters. Third, disable any software

firewall program. Fourth, verify that you have file sharing enabled. Please contact

your Operating System support for more information.

After I connect my PCs to the switch, I can only get onto the Internet from one

computer.

The switch was not designed to share Internet between multiple computers.

You need to get an Internet router such as the TW100-S4W1CA.

Where is the uplink port located on the switch?

Since all the ports on the switch are Auto-MDIX, any of the ports can be used

as an uplink port.

If you still encounter problems or have any questions regarding the TE100-S50g/

TE100-S80g please contact Trendnet's Technical Support Department.

Limited Warranty

5-Year Limited Warranty

TRENDnet warrants its products against defects in material and workmanship, under

normal use and service, for the following lengths of time from the date of purchase.

TE100-S50g/TE100-S80g

If a product does not operate as warranted above during the applicable warranty period,

TRENDnet shall, at its option and expense, repair the defective product or deliver to

customer an equivalent product to replace the defective item. All products that are

replaced will become the property of TRENDnet. Replacement products may be new or

reconditioned.

TRENDnet shall not be responsible for any software, firmware, information, or memory

data of customer contained in, stored on, or integrated with any products returned to

TRENDnet pursuant to any warranty.

There are no user serviceable parts inside the product. Do not remove or attempt to

service the product through any unauthorized service center. This warranty is voided if

(i) the product has been modified or repaired by any unauthorized service center, (ii) the

product was subject to accident, abuse, or improper use (iii) the product was subject to

conditions more severe than those specified in the manual.

Warranty service may be obtained by contacting TRENDnet office within the applicable

warranty period for a Return Material Authorization (RMA) number, accompanied by a

copy of the dated proof of the purchase. Products returned to TRENDnet must be pre-

authorized by TRENDnet with RMA number marked on the outside of the package, and

sent prepaid, insured and packaged appropriately for safe shipment.
