Unitech MS910 Bedienungsanleitung

MS910 Wireless

Barcode Scanner

Quick Guide

Full user’s manual is available on

the enclosed CD.

Version 1.2

400947G

because we care

- 1- - 2-

Mini Wireless

Barcode Reader

Quick Guide

Hand Strap

SPECIFICATIONS

Light source 625nm visible red LED

Scan rate 240 scans/sec

Sensor Linear CMOS sensor

Resolution 5mil/ 0.127mm

PCS 30%

Housing Plastic(ABS)

Profile SPP, HID

Working Hours 8 hours (1 scan/ 5 sec)

Charge Time 2 hours (fully charged)

Coverage 10M/33ft. (line of sight)

Operating Temp 0 to 50˚C (32˚F to 122˚F)

Symbologies All major 1D barcodes incl. GS1 Databar

USB Charger Cable

MS910 Wireless

Barcode Reader

Quick Guide

Quick Connection Card

NUMERIC BARCODES

*1*

*2*

*3*

*4*

*5*

INTRODUCTIONOUT OF THE BOX

because we care

LED Indicator

1. Mini USB port 4.

Exit Window

Trigger

(for charging only)

5. Hard

Reset Button

(insert pin into the hole)

- 3-

CHARGING THE BATTERY

To scan a barcode, make sure the aiming beam crosses

every bar and space of the barcode.

1. Flip open the mini USB port on the scanner.

2. Insert the mini USB connector into the port on the

scanner and USB A connector into a USB port on

the host PC.





BEEPER INDICATION

LED INDICATION

Single long beep Power up

Single beep Good read

Single short beep The scanner reads a Code39 of

ASCII in configuration procedure

Two beeps Wireless connection

Two short beeps The scanner successfully reads

a configuration barcode

Five beeps Low power

Three beeps Wireless disconnection

Three short beeps i. The scanner reads a barcodes

while disconnected.

ii. The scanner reads an unexpected

barcode during configuration

procedure. (scan [RESET] to abort

and start over)

Several short beeps The scanner switches from one

communication mode to another

Off

Flashing Green

Green for 2 sec

Flashing Red

Solid Red

Standby or Power off

Disconnected or Discoverable

Good Read

Low power

Charging

- 4-

Scanner

Mini USB

USB A

Host

GETTING STARTED

- 5-

GETTING CONNECTED PINCODE SETUP

1. Press the trigger for 1 second to activate the scanner.

2. Scan [DISCONNECT]

3. Scan [SPP]; the scanner will emit several short beeps.

4. Select “Wireless Scanner” from discovered device list.

The default pincode is “1234”.

5. Open serial communication software with com port

(see Device Manager) properly set up.

6. The scanner will beep twice to verify the connection.

There are two modes of wireless communication:

- 6-

. E042$

SPP Pincode Start

*.E042$*

. E032$

*.E032$*

. E033$

*.E033$*

. E043$

HID

*.E043$*

Disconnect

. E031$

*.E031$*

*$TX*

$TX

1. Press the trigger for 1 second to activate the scanner.

2. Scan [DISCONNECT]

3. Scan [HID]; the scanner will emit several short beeps.

4. Select “Wireless Scanner” from discovered device list.

5. The wireless application may prompt you to scan

a pincode(see PINCODE SETUP section) it generated.

6. The scanner will beep twice to verify the connection.

Scan numeric barcodes (see NUMERIC BARCODES section

on the next pages) based on the pincode generated

by the wireless application.

STEP 1

Pincode Stop

Enter

STEP 4

STEP 3

STEP 2

NUMERIC BARCODES

- 7--8-

*1*

*2*

*3*

*4*

*5*

*6*

*7*

*8*

*9*

*0*

- 9--10 -

SMARTPHONE CONNECTION - iOS (Apple) SMARTPHONE CONNECTION - Android

Getting Connected

Getting Connected without Pincode

Touch Keyboard

Please pair with the scanner via [BT mode - HID]. (page 5)

1. After enabling iOS Hotkey(disabled by default), you may simply

double-click the trigger to toggle the iPhone/iPad Touch Keyboard.

2. The function is supported by firmware 1.04 or higher.

Secure Simple Pairing (SSP), supported by Bluetooth 2.1 or

above, allows you to pair with iOS without pincode.

Please scan [Enable SSP] above before entering the pairing

procedure of [BT mode - HID]. (page 5)

Keyboard Wedge Software (BluetoothConnect)

1. Pair with the scanner via [BT mode - SPP]. (page 5)

2. Enable unknown resources in Android Authority.

3. Install BluetoothConnect.apk, which is available on CD,

and enter the program.

4. Enable BluetoothConnect in the Language & Keyboard

setting window and choose BluetoothConnect as Current

Input Method.

5. Click [Connect to Barcode Reader] on the menu and select

the paired wireless scanner.

6. The scanner will beep twice to verify a successful connection.

*Note: Please contact with your sales representative for detailed

information on BluetoothConnect.

BluetoothConnect is a free keyboard wedge software that

can convert SPP data into virtual key-strokes on any Android

applications. Please follow below steps:

To get connected to Android, please follow the instruction

in [BT mode - SPP] (page 5)

*Note:

1. Android 3.0 or higher version may also support

Bluetooth HID profile.

2. If you operate in SPP mode but your application

does not support direct external device connections,

please refer to below section.

. E049$

ENABLE SSP

. E047$

ENABLE iOS HOTKEY

. E048$

DISABLE iOS HOTKEY

- 11 --12 -

POWER OFF TIMEOUT

The timeout before automatic power-off to save power.

*.B017$*

. B017$

1 MIN

*.B019$*

. B019$

5 MIN

*.B020$*

. B020$

10 MIN

*.B021$*

. B021$

DISABLE

(NO POWER-OFF)

3 MIN

*.B018$*

. B018$

Link Quality (enabled by default) ensures a more secure data

transmission from the scanner to the cradle/host. To make the

transmission range wider, you may disable Link Quality, but the

data transmission security will become less reliable.

LINK QUALITY

. E035$

. E036$

ENABLE

DISABLE

GENERAL SETTINGS

BEEPER

. P023$

. A007$

. F012$

RESET

CHECK

VERSION

BEEP OFF

. F018$

- 13 -

READING MODE

. F002$

TRIGGER

TOGGLE

FLASH

CONTINUOUS

AUTO OFF

. F003$

. F001$

. F005$

. F006$

- 14 -

. A001$

DEFAULT

BEEP ON

KEYBOARD LAYOUT

. C010$

ENGLISH

(USA)

. C018$

ENGLISH

(UK)

. C011$

GERMAN

. C012$

FRENCH

. C013$

SPANISH

- 15 -

. C014$

ITALIAN

. C009$

JAPAN

(106 key)

- 16 -

CANADIAN

(TRADITIONAL)

. C034$

NORWEGIAN

. C029$

SWEDISH

. C026$

PORTUGUESE

. C031$

CANADIAN

(FRENCH)

. C025$

HUNGARIAN

(101 KEY)

BRAZILIAN

(PORTUGUESE)

SLOVAK

SWISS

(FRENCH)

DUTCH

DANISH

BELGIAN

(AZERTY)

. C016$

SWISS

(GERMAN)

KEYBOARD LAYOUT

. C017$

CZECH

(QWERTY)

. C022$

CZECH

(QWERTZ)

HUNGARIAN

(QWERTZ)

. C021$

. C015$

ALT CODE

- 17 --18 -

. C024$

. C023$

. C033$

. C032$

. C027$

. C028$

. C030$
