User manual

360 BEAM

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions……………………………………………………………………………3-4

Technical Specifications…………………………………………………………………………4-5

Control Menu ……………………………………………………………………………………5-7

DMX Channels ……………………………………………………………………………………8-10

Dimension …………………………………………………………………………………………11

LUX Date ……………………………………………………………………………………………11

Trouble Shooting…………………………………………………………………………………12

Fixture Cleaning………………………………………………………… ………………………12

STATEMENT

The product has well capability and intact packing when leave factory. All of the user should

comply with warning item and manual, any misuse cause of the damages are not included in our

guarantee, and also can not be responsible for any malfunction & problem owing to ignore the

manual.

1.Safety Instructions

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that

they also receive this instruction booklet.

•Unpack and check carefully there is no transportation damage before using the unit.

•Before operating, ensure that the voltage and frequency of power supply match the power

requirements of the unit.

•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

•The unit is for indoor use only. Use only in a dry location.

•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent

surfaces. Be sure that no ventilation slots are blocked.

•Disconnect main power before replacement or servicing.

•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.

•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always

by taking its base.

•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher

than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand

during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before

replacing or serving.

•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit

by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please

contact the nearest authorized technical assistance center. Always use the same type spare parts.

•DO NOT touch any wire during operation as high voltage might be causing electric shock.

Warning:

•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Caution:

•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any

repairs yourself. In the unlikely event your unit may require service, please contact your nearest

dealer.

Installation:

•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly

fixed to avoid vibration and slipping while operating. And make sure that the structure to which you

are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also

always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.

•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the

touch of people.

2.Technical Specifications

Input voltage range: 90-240V~ 50/60Hz

Machine power: 365 W

Input power: 550W

Light source: PHILIPS MSD Silver 300 LL (3000 hours)

Diameter of light-emitting lens: 145mm

Color temperature: 7800K

When the beam angle is 2°, the illuminance at 10 meters can reach 400,000 lux

Fixed gobo: 1 fixed gobo, 16 gobos plus 1 white circle

Color wheel: 1 color wheel, 14 fixed colors plus white, two-way rainbow effect

Equipped with 1 8 prism, and 8+16+24 honeycomb prism, the two prisms can be stacked and

rotated in both directions

Beam angle: 2°

Control mode: DMX512, self-propelled, master-slave, RDM

Channel: 18CH

With fog and colorful effects

Electric focusing system

Outstanding strobe effect with variable speed

0-100% smooth dimming

Control panel: LCD display, touch panel

X-axis rotation angle: 540°

Y-axis rotation angle: 270°

XY axis magnetic coding positioning is more accurate

Power Outlet: Power Connector Input/Output

Signal input/output: three-pin XLR head socket

Overheating self-energy protection bulbs, extending lamp life

Lamp size: 338x256x512mm

Net weight: 14KG

3.Control Menu

1—Displays the current DMX address in large font

2—Logo display area

3—DMX signal frame rate (FPS)

4—Current channel mode, the displayed number indicates the current channel number

5—Fan speed display (select whether to display according to the lighting conditions)

6—Current Mode (Master, Slave)

7—Current running mode (DMX512, Auto, User)

8—Error message. If a red band "x" is displayed, the self-test found an error. (Press down to view

specific error message)

9 - temperature display or other content (depending on lamp configuration)

10 —SN term display

menu operation:

1. DMX address: set the DMX address

2. Channel mode: Set the channel mode, the number of the menu option indicates the number of

channels.

3. Reset operation: reset the motor

Motor power off：

Select "On", all motors are powered off; select "Off", all motors are powered on

and reset. Using this menu, it is possible to plug and unplug the motor and power-on reset without

turning off the main switch.

XY Axis: Reset Pan and Tilt Motors

.......

4.Run: Set the run mode

The description of each menu option is as follows (Note: "Automatic" mode options may

vary according to different product models):

DMX: controlled and run by DMX512 console.

Self-propelled (factory test): run the program set by the manufacturer, this program is mainly

used for factory test.

User program: run user self-programming program. The editing scene can be set in the [Run

Settings] - [Self-Programming] menu.

5.lamp：Switch the light bulb. After changing the value, it takes about 3 seconds to work, you can

switch the value back within 3 seconds to cancel the operation. After turning off the light

bulb, you must wait 1~2 minutes before turning it on again. If you operate the menu to turn

on the light bulb within two minutes, the light bulb will not be lit. After the waiting time is up,

it will light up by itself.

If this menu item is "on", the system will first try to light the bulb when powered on, and wait

for the light board to return.

6.Manual: Manually set the value of the channel

7.Operation settings: Operation parameter settings.

XY axis general settings:

X-axis reverse: Select "Yes" to reverse the rotation direction of the Pan motor, select "No",

and follow the rotation direction at the factory.

Y-axis reverse: select "Yes" to reverse the rotation direction of the Pan motor, select "No",

and follow the rotation direction at the factory.

DMX512

When no signal: select the operation mode if no DMX512 signal is detected

When powering on: Only when powering on, if no DMX signal is detected,

the above operation mode will be executed,

Otherwise, the last DMX action will be held

Centered: Except for Pan and Tilt, all other channels are cleared to zero.

Self-propelled (factory test/pattern/color): Run the program set by the factory.

User program: run user self-programming program.

Runtime: At any time, as long as the DMX signal is lost, the action performed

Hold: Hold the DMX value of the last frame.

Shut off: close the shutter

Turn on the light bulb: Select "No", the light will not light after the power-on reset is

completed, select "Yes", the light bulb will be automatically turned on after the power-on reset is

completed.

8. Advanced settings:

Fine-tuning: Factory debugging function, which requires password authentication to enter.

Display: Menu screen flip setting

Language: Set the system language

Ignore errors: Some error reports may not affect the final use effect, or for the general

purpose of the product, you can choose to turn off some meaningless error reports

Trim Recovery: After replacing the display board, use this menu to restore the trim data

saved by the motor board to the display board.

9. Information:

DMX value: Display the current received DMX signal value

Channel: Displays the DMX value of the selected channel that needs to be observed

Error: Display error message (if any item in this menu is wrong, an exclamation mark will be

displayed in the upper right corner of the menu cover)

Storage: Indicates whether the storage is functioning normally. If the memory is

abnormal, the menu information cannot be recorded or read, and the lamp time record and

self-programming data may also be lost.

RAM Error: Chip memory allocation failed, if this error occurs, please contact the

manufacturer.

Bus communication: If there is an error, the motors of various functions will not

operate normally. If this error occurs, please check whether the communication cables between the

boards are in poor contact.

Bulb: The communication between the bulb and the lighting board. If the

communication is wrong, the main control chip cannot correctly judge whether the light bulb is

normally turned off or on, which may cause some functions to not work properly.

Lighting board: Communication with the light bulb lighting board.

X-axis reset: X-axis reset failed, check whether the magnetic code or motor is normal.

Y-axis reset: Y-axis reset failed, check whether the magnetic coding or motor is normal.

Color reset: Color wheel reset failed

Fixed pattern reset: Fixed pattern disk reset failed

Fan stop: The blower stops rotating, and the light bulb will be automatically turned off

after a certain time.

Bulb: Displays the usage time of the bulb

Usage time: Displays the total time the lamp has been on since the lamp time was reset

to zero

Time reset: The total time the bulb is on is reset to 0.

Test Mode: For product testing and temporary use only.

Product Code: The internal code of the product is only for reference in product production and

maintenance.

4.DMX Channels

Model - CH18

Channel

DMX Value

Description

0-255

Pan

0-255

Pan fine

0-255

Tilt

0-255

Tilt fine

Pan/Tilt speed

Maximum speed

in speed mode

1-255

speed from fast to slow

in time mode

1-255

Time from 0.1s to 25.5s

0-255

dimmer

strobe

0-3

closure

4-103

Strobe from slow to fast

104-107

Open

108-207

Fast off and slow on, from fast to slow

208-212

Open

213-251

Random strobe, from slow to fast

252-255

Open

color wheel

0-4

Color 1 (white light)

5-8

color 1+color 2

9-12

color 2

13-17

color 2+color 3

18-21

color 3

22-25

color 3+color 4

26-29

color 4

30-34

color 4+color 5

35-38

color 5

39-42

color 5+color 6

43-46

color 6

47-51

color 6+color 7

52-55

color 7

56-59

color 7+color 8

60-63

color 8

64-68

color 8+color 9

69-72

color 9

73-76

color 9+color 10

77-81

color 10

82-85

Color 10 + Color 11

86-89

color 11

90-93

Color 11+Color 12

94-98

color 12

99-102

Color 12+Color 13

103-106

color 13

107-110

Color 13+Color 14

111-115

color 14

116-119

Color 14+Color 15

120-123

color 15

124-127

Color 15+Color 1

128-190

Rainbow effect from fast to slow

191-192

rainbow effect stopped

193-255

Rainbow effect from slow to fast

Gobo

0-3

Open (white light hole)

4-6

Gobo 1

7-9

Gobo 2

10-12

Gobo 3

13-15

Gobo 4

16-18

Gobo 5

19-21

Gobo 6

22-24

Gobo 7

25-27

Gobo 8

28-30

Gobo 9

31-33

Gobo 10

34-36

Gobo 11

37-39

Gobo 12

40-42

Gobo 13

43-45

Gobo 14

46-48

Gobo 15

49-54

Gobo 16

55-62

Pattern 1 shaking from slow to fast

63-70

Pattern 2 shaking from slow to fast

71-78

Pattern 3 shaking from slow to fast

79-86

Pattern 4 shaking from slow to fast

87-94

Pattern 5shaking from slow to fast

95-102

Pattern 6shaking from slow to fast

103-110

Pattern 7shaking from slow to fast

111-118

Pattern 8 shaking from slow to fast

119-126

Pattern 9shaking from slow to fast

137-134

Pattern 10 shaking from slow to fast

135-142

Pattern 11 shaking from slow to fast

143-150

Pattern 12 shaking from slow to fast

151-159

Pattern 13 shaking from slow to fast

159-166

Pattern 14 shaking from slow to fast

167-174

Pattern 15 shaking from slow to fast

175-190

Pattern 16 shaking from slow to fast

191-201

Open

202-227

The gobo is scrolling forward, from fast to slow

228-229

stop scrolling

230-255

gobo scrolls in reverse, from slow to fast

Atomization and colorful

0-19

null

20-137

atomization

138-255

colorful

Prism1

0-127

no prism

128-255

Prism 1 Insert

Prism 1 Positioning and Rotation

0-127

Prism 1 Positioning and Rotation

128-190

Prism 1 rotates in reverse, from fast to slow

191-192

Prism 1 stops rotating

193-255

Prism 1 rotates forward, from slow to fast

Prism2

0-127

no prism

128-255

Prism 2 Insert

0-255

focus

no function

reset

To achieve the following effects, push the DMX value to the corresponding

position and stand still for at least 4 seconds

0-25

null

26-76

effect reset

77-127

Pan/Tilt reset

128-255

reset all

reset

Lamp

To achieve the following effects, push the DMX value to the corresponding

position and stand still for at least 4 seconds

0-25

no effect

26-100

Lamp Off

101-255

Lamp ON

Inhaltsverzeichnis

Andere Uplus Lighting Beleuchtungsausrüstung Handbücher

Uplus Lighting

Uplus Lighting 230 BEAM Bedienungsanleitung

Uplus Lighting

Uplus Lighting W1925 Bedienungsanleitung

Uplus Lighting

Uplus Lighting IR 1210 PAR Bedienungsanleitung

Uplus Lighting

Uplus Lighting 400 BLINDER Bedienungsanleitung

Uplus Lighting

Uplus Lighting 200 MZ-SPOT PR Bedienungsanleitung

Uplus Lighting

Uplus Lighting RETRO 360 Bedienungsanleitung

Uplus Lighting

Uplus Lighting 6 EYE RETRO BAR Bedienungsanleitung

Uplus Lighting

Uplus Lighting LED PROFILE FIX Bedienungsanleitung

Uplus Lighting

Uplus Lighting W3725 Bedienungsanleitung

Uplus Lighting

Uplus Lighting 750 BSWF Bedienungsanleitung

Uplus Lighting

Uplus Lighting BR360 Bedienungsanleitung

Uplus Lighting

Uplus Lighting 37X15ZWASH Bedienungsanleitung

Uplus Lighting

Uplus Lighting 460LED BSW Bedienungsanleitung

Uplus Lighting

Uplus Lighting 4020 IP Bedienungsanleitung

Uplus Lighting

Uplus Lighting COB400 ZOOM Bedienungsanleitung

Uplus Lighting

Uplus Lighting 200 LED BSW Bedienungsanleitung

Uplus Lighting

Uplus Lighting 3010 IP PAR Bedienungsanleitung

Uplus Lighting

Uplus Lighting IP MATRIX 5 Bedienungsanleitung

Uplus Lighting

Uplus Lighting 200 LED BSW Bedienungsanleitung

Uplus Lighting

Uplus Lighting BAR 6 LASER Bedienungsanleitung

Uplus Lighting

Uplus Lighting BL6 Bedienungsanleitung

Uplus Lighting

Uplus Lighting PIXEL IP20X15 BAR Bedienungsanleitung

Uplus Lighting

Uplus Lighting 300 MZ-SPOT PR Bedienungsanleitung

Uplus Lighting

Uplus Lighting LED PROFILE MZ Bedienungsanleitung

Beliebte Beleuchtungsausrüstung Handbücher anderer Marken

Brizo

Brizo 8SP-MU-4 Bedienungsanleitung

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Bedienungsanleitung

IKEA

IKEA BJÖRKSPIREA Bedienungsanleitung

Laserworld

Laserworld Evolution Series ES-400RGB Bedienungsanleitung

Alien

Alien RG STAR Bedienungsanleitung

EuroLite

EuroLite LED B-40 Bedienungsanleitung

Qazqa

Qazqa Suplux SL 3 Black 103062 Bedienungsanleitung

Commercial Electric

Commercial Electric 54568141 Bedienungsanleitung

CREE LIGHTING

CREE LIGHTING 304 Series Bedienungsanleitung

Goobay

Goobay 49867 Bedienungsanleitung

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Bedienungsanleitung

Alkalite

Alkalite Krypton KT-81 Bedienungsanleitung

Clas Ohlson

Clas Ohlson GU10 Bedienungsanleitung

DTS

DTS DELTA 10 F Bedienungsanleitung

ring

ring Solar Steplight Bedienungsanleitung

One Stop Gardens

One Stop Gardens 57696 Montageanleitung

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Bedienungsanleitung

SIREM

SIREM Swimeo A2 Bedienungsanleitung
