Uplus Lighting 200 BLINDER Bedienungsanleitung

User manual

200 BLINDER

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions…………………………………………………………………………………3

2.Technical Specifications……………………………………………………………………………4

3.Control Menu …………………………………………………………………………………………4

4.DMX Channels ………………………………………………………………………………………5

5.Trouble Shooting……………………………………………………………………………………6

6.Fixture Cleaning………………………………………………………… …………………………6

STATEMENT

The product has well capability and intact packing when leave factory. All of the user should

comply with warning item and manual, any misuse cause of the damages are not included in our

guarantee, and also can not be responsible for any malfunction & problem owing to ignore the

manual.

1.Safety Instructions

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also

receive this instruction booklet.

•Unpack and check carefully there is no transportation damage before using the unit.

•Before operating, ensure that the voltage and frequency of power supply match the power requirements of the

unit.

•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

•The unit is for indoor use only. Use only in a dry location.

•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surfaces. Be sure

that no ventilation slots are blocked.

•Disconnect main power before replacement or servicing.

•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.

•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always by taking its

base.

•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher than this Unit

surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand during its operation. Turn off

the power and allow about 15 minutes for the unit to cool down before replacing or serving.

•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit by yourself.

Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest

authorized technical assistance center. Always use the same type spare parts.

•DO NOT touch any wire during operation as high voltage might be causing electric shock.

Warning:

•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Caution:

•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any repairs yourself.

In the unlikely event your unit may require service, please contact your nearest dealer.

Installation:

•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to

avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit

is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can

hold 12 times of the weight of the unit when installing the fixture.

•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the touch of

people.

2.Technical Specifications

VOLTAGES:AC 100V-240V，50/60Hz

2*100W COB Blinder Light

Light source: 2*100W high bright COB LED

Color temperature:3200K/6500K

Beam Angle: 60゜

DMX Channel:4/8 CH

CONTROL:DMX512

WORK ENVIRONMENT TEMPERATURE: -10°C-40°C

Aluminum housing; IP20 indooor,

digital display

Good cooling system, over heat protection

NW:5 KGS

3.Control Menu

Operation method

Show

Function

Instruction

d001

DMX Address

(001~512)

DMX-512 address set, 4 Channels mode

A001

DMX Address

(001~512)

DMX-512 address set, 8 Channels mode

r255

(000~255)

UP、DOWN Change brightness

G255

(000~255)

UP、DOWN Change brightness

b255

(000~255)

UP、DOWN Change brightness

u255

(000~255)

UP、DOWN Change brightness

FH99

Strobe flash (01~99)

UP、DOWN Change the speed

CL01

Different Colors Output

(01~08)

UP、DOWN Change brightness

CC99

Colors Jump Change

(01~99)

UP、DOWN Change the speed

DE99

Colors Gradate

(01~99)

UP、DOWN Change the speed

CP99

Colors Pulse Change

(01~99)

UP、DOWN Change the speed

SU01

Colors sound-Active

(01~09)

UP、DOWN Change the effects

4.DMX Channels

DMX512Control： 8 Channel Model(A001)

Display

Function

CH1

Dimmer

Y1、W1、Y2、W2 dimmer : from dark to bright

CH2

Y1 dimmer

Y1 dimmer : from dark to bright

CH3

W1 dimmer

W1 dimmer : from dark to bright

CH4

Y2 dimmer

Y2 dimmer : from dark to bright

CH5

W2 dimmer

W2 dimmer: from dark to bright

CH6

Strobe

Y1、W1、Y2、W2 strobe: from slow to fast

CH7

Function choice

0~50: DMX 8CH Control.

51~100: Different Colors Output

101~150: Colors Jump Change.

151~200: Colors Gradate.

201~250: Colors Pulse Change.

251~255: Sound-Active

CH8

Function speed

Speed function, from slow to fast

DMX512Control： 4Channel Model(D001)

Channel

Function

Instruction

CH1

Y1 dimmer

Dimmer- Dark to Bright

CH2

W1 dimmer

Dimmer- Dark to Bright

CH3

Y2 dimmer

Dimmer- Dark to Bright

CH4

W2 dimmer

Dimmer- Dark to Bright

5.Trouble Shooting

ollo

ing

few

oble

occu

uring

ope

tion

leshooting

The

does

work

ght

Check

nect

ion of p

owe

eas

ure

ins

volt

Check

pow

LED

responding

LED

on.

che

nectors,

link

ope

espons

el,

che

ess

etti

ity

nter

ittent

oble

che

ins

onn

ecto

PCB

nit

the

iou

ntroller

Check

or run

lon

volta

les

terfer

ence

inter

face

circui

One

the

cha

ing

tep

moto

dam

the

nect

PCB

oken.

oto

’

ive

PCB

ndition

6.Fixture Cleaning

The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to

optimize light output. Cleaning frequency depends on the environment in which the fixture operates:

damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.

Clean with soft cloth using normal glass cleaning fluid.

Always dry the parts carefully.

Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
