Volt VAL-1004-4-BBZ Bedienungsanleitung

VOLT®Low Voltage Landscape Lighting

VOLT® Cast Brass Round Wall Wash

VAL-1004-4-BBZ

INSTALLATION INSTRUCTIONS

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

VOLT®Cast Brass Round Wall Wash

VAL-1004-4-BBZ

Package Contents

Product Dimensions

Important: Please Read Before Installation

IMPORTANT SAFETY INSTRUCTIONS

INSTALLATION INSTRUCTIONS

This luminaire is intended for installation in accordance with local codes

and the National Electric Code (NEC). Failure to adhere to these codes and

instructions may result in serious injury, property damage and void the

warranty.

These instructions do not intend to cover all variations in installation,

operation maintenance or mounting situations.

1. Make sure that the power is turned OFF before installing or servicing

this luminaire.

2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M)

or more from pool, spa or fountain.

3. This luminaire is intended to be used only with a power supply

(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.

4. Wiring connections must be made with wire connectors that are

suitable for outdoor use.

5. Position the low voltage wire and wire connector so that it is located

within 6 inches (15.2 cm) from a building structure, a luminaire or

tting.

6. The main low voltage cable is intended for shallow burial - less than 6

inches (152 mm).

7. If additional lengths of low voltage cable are required, please contact

www.voltlighting.com or call 1-813-978-3700.

INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS

Lighted lamp is HOT!

WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.

1. Turn off/unplug and allow to cool before replacing lamp.

2. Lamp gets HOT quickly! Contact only switch/plug when turning on.

3. Do not touch the hot lens, guard or enclosure.

4. Keep lamp away from materials that may burn.

5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may

damage lamp.

6. Do not operate the luminaire tting with a missing or damaged shield.

SAVE THESE INSTRUCTIONS

A. (1) Luminaire

www.voltlighting.com [email protected] • 813.978.3700

4.25”

B. (1) Stake

Install Stake

Determine the desired location for mounting

the luminaire. Hammer the stake into the

ground until ange of stake is ush to grade.

To avoid damage to the stake, place a board on

top of the stake while hammering.

NOTE: If the ground is hard and the stake

is difcult to install, make a crosscut in the

ground using a at shovel.

Board

Stake

Soil

Ground

Parts Required (sold separately)

A. (1) Bipin Lamp

4”

INSTALLATION INSTRUCTIONS

www.voltlighting.com [email protected] • 813.978.3700

VOLT®Cast Brass Round Wall Wash

VAL-1004-4-BBZ

Remove Lens

Install Lamp

Loosen the lens and remove it

from the luminaire.

Insert the lamp with the correct

wattage and type marked on the

luminaire label.

CAUTION: Do not exceed maximum

wattage marked on luminaire label.

NOTE: DO NOT touch lamp with bare

hands. Use soft cloth to handle lamp.

NOTE: “Wafer” bi-pin LED lamp also can

be used for this luminaire.

Luminaire

Lamp

“Wafer” Bi-pin

LED Lamp

Lens

Socket

Thread the lens back onto

the luminaire and hand

tighten until snug.

Clear away an area in the ground at

the wireway slot on top of the stake.

Align the wireway slot on the base of

the stake. Lay the luminaire pigtail

into the wireway slot and screw the

luminaire onto the stake. Tighten

until snug to secure the base.

Install Lens

Install Luminaire to Stake

Luminaire

Stake

Pigtail

Wireway Slot

Wire Connection

Strip both leads from the luminaire pigtail. Using two wire connectors

(sold seperatley), connect the leads from the luminaire to the main low

voltage supply cable leads.

Pigtail

Main Low Voltage

Supply Cable

Wire Connectors

INSTALLATION INSTRUCTIONS

www.voltlighting.com

VOLT®Cast Brass Round Wall Wash

VAL-1004-4-BBZ

Install/Replace Lamp

Please reverse Step 6 - Step 3 to expose the Lamp and replace it with the

correct wattage and type marked on the luminaire label. Reinstall Diffuser.

IMPORTANT: Lamp must be protected from moisture and dust at all times.

Always reinstall diffuser when moved.

is-val-1004-ver5.pdf

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

www.voltlighting.com

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
