VOLT®Low Voltage Landscape Lighting

VOLT®Dojo Deck Light

VDL-6009-4-BBZ

INSTALLATION INSTRUCTIONS

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

- 1 -

VOLT®Dojo Deck Light

VDL-6009-4-BBZ

Package Contents

Product Dimensions

Important: Please Read Before Installation

Important Safety Instructions

INSTALLATION INSTRUCTIONS

This xture is intended for installation in accordance with local codes and

the National Electric Code (NEC). Failure to adhere to these codes and

instructions may result in serious injury, property damage and void the

warranty.

These instructions do not intend to cover all variations in installation,

operation maintenance or mounting situations.

1. Make sure that the power is turned OFF before installing or servicing

this xture.

2. Warning: this xture is not intended to be installed within 10 feet [3

meters] of a pool, spa or fountain.

3. This xture is intended to be connected to a low voltage transformer.

4. Underground Low Energy Cable must not be buried over 6” (15.2 cm)

in order to connect to the main low voltage cable.

5. Wire connections must be made with UL listed wire connectors that

are suitable for outdoor use.

LIGHTED LAMP IS HOT!

WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.

1. Turn off/unplug and allow to cool before replacing lamp.

2. Lamp gets HOT quickly!

3. Do not touch the hot lens, guard or cowl.

4. Keep lamp away from materials that may burn.

5. Do not touch lamp at any time.

6. Use a soft cloth.

7. Oil from skin may damage lamp.

8. Do not operate the xture with a damaged or missing lens or shield.

A. (1) Fixture Body

www.voltlighting.com [email protected] • 813.978.3700

3”

B. (2) Lock Screw

3.5”

- 3 -- 2 -

ProTip for Hiding Splice Connections

ProTip for Hiding Lead Wire

Determine the location for the xture. Drill a hole straight through the

desired mounting location and run the lead wire out the backside of

the location so that the wires are not visible from the front side. Use a

matching trim piece and cut a groove in the back of trim. Cover the lead

wires with the matching trim piece.

All xtures come with 4’ of lead wire enabling you to hide the splice

connections out of sight. If you must make a splice connection in view, use

an inline heat shrink style connection that is less visible than traditional

twist caps.

1.75”

www.voltlighting.com [email protected] • 813.978.3700

INSTALLATION INSTRUCTIONS

Install Face Cover

Push face cover back onto the

xture body aligned with the gaps

in the xture body. Once the face

cover is ush with the xture body,

rotate the face cover until it stops

and locks into place.

Remove Face Cover

Rotate the face cover until it

stops and then lift the cover

straight off.

Note: The rst time it may be

difcult because the xture

has a very tight o-ring seal and

a grease sealant for moisture

protection.

Face Cover

Fixture Body

Rotate

Fixture

Body

- 5 -- 4 -

Install Fixture Body

Fixture Body

Lock Screw

Wall Anchor

(optional)

Attach the xture body to your

desired location and secure with lock

screws.

Note: Wall anchors may be required

for certain installation conditions

(e.g. Brick walls, Concrete Walls,

etc.). Mark on the wall using holes

on the xture body to drill holes for

your wall anchors. Remove base and

drill proper holes in the wall, then

insert wall anchors.

Hole

Face

Cover

Wire Connections

Strip both leads from luminaire

pigtail. Using two wire connectors

(sold separately), connect leads

from luminaire to main supply cable

leads.

Fixture

Wire

Connector

Main Supply Cable

Pigtail

VOLT®Dojo Deck Light

VDL-6009-4-BBZ

- 6 - - 7 -

www.voltlighting.com [email protected] • 813.978.3700

IS-VDL-6009-4-BBZ-VER3.pdf

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

www.voltlighting.com

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

- 8 -
