Volt VFL-4501-4-BBZ Bedienungsanleitung

VOLT®Low Voltage Landscape Lighting

VOLT®G2 Big Par36 Cast Brass Flood Light

VFL-4501-4-BBZ

INSTALLATION INSTRUCTIONS

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

- 1 -

VOLT®G2 Big Par36 Cast Brass Flood Light

VFL-4501-4-BBZ

INSTALLATION INSTRUCTIONS

www.voltlighting.com

- 2 -

Important: Please Read Before Installation

Important Safety Instructions

This luminaire is intended for installation in accordance with local codes

and the National Electric Code (NEC). Failure to adhere to these codes and

instructions may result in serious injury, property damage and void the

warranty.

These instructions do not intend to cover all variations in installation,

operation maintenance or mounting situation.

1. Make sure that the power is turned OFF before installing or servicing

this luminaire.

2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M)

or more from pool, spa or fountain.

3. This luminaire is intended to be used only with a power supply

(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.

4. Wiring connections must be made with UL Listed wire connectors that

is suitable for outdoor use.

5. Position the low voltage wire and UL listed wire connector so that

it is located within 6 inches (15.2 cm) from a building structure, a

luminaire or tting.

6. The main low voltage cable is intended for shallow burial - less than 6

inches (152 mm).

7. If additional lengths of low voltage cable is required, please contact

www.voltlighting.com or call 1-813-978-3700.

INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS

Lighted lamp is HOT!

WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.

1. Lamp gets HOT quickly!

2. Do not touch the hot lens, guard or enclosure.

3. Keep lamp away from materials that may burn.

4. Do not touch lamp at any time. Use a soft cloth. Oil from skin may

damage lamp.

5. Do not operate the luminaire tting with a missing or damaged shield.

SAVE THESE INSTRUCTIONS

Package Contents

Parts Required (sold separately)

A. (1) PAR36 Bulb

B. (1) Mounting Accessory

[email protected] • 813.978.3700

- 3 -

Product Dimensions

2.3”

4.65”

4.25”

Remove Glare Guard

A. (1) Fixture

Rotate the glare guard

counter clockwise and remove

it from the xture. Then

remove the bulb holder.

ROTATE

Fixture

Bulb Holder

Glare Guard

www.voltlighting.com

INSTALLATION INSTRUCTIONS

- 4 -

VOLT®G2 Big Par36 Cast Brass Flood Light

VFL-4501-4-BBZ

Install PAR36 Bulb

Fixture

Supply Wire

PAR36 Bulb

Screw

Use a PAR36 bulb (sold separately),

with the correct wattage and type

as marked on luminaire label.

Connect the supply wires using the

screws on the bottom of the PAR36

bulb, tighten with a screwdriver.

CAUTION: Do not exceed maximum

wattage marked on luminaire

label.

NOTE: DO NOT touch lamp with

bare hands. Use soft cloth to

handle lamp.

Install Bulb Holder and Glare Guard

Glare Guard

Tuck the excess wires inside

of the xture and place the

PAR36 bulb inside. Place the

bulb holder onto the top of

the PAR36 bulb and thread

the glare guard onto the

xture.

Fixture Bulb Holder

PAR36 Bulb

[email protected] • 813.978.3700

- 5 -

Install Stake

Board

Ground

Soil

Stake

Determine the desired location

for mounting the stake. Hammer

the stake into the ground until

ange of stake is ush to grade.

To avoid damage to the stake,

place a board on top of the stake

while hammering.

Note: If the ground is hard and

the stake is difcult to install,

make a crosscut in the ground

using a at shovel.

Install Fixture to Stake

Fixture

Wireway Slot

Ground

Soil

Stake

Cable

Clear away an area in the

ground at the wireway slot on

the top of the stake. Place the

xture wire into the wireway

slot and thread the xture onto

the stake. Hand tighten until

snug.

INSTALLATION INSTRUCTIONS

www.voltlighting.com

- 6 -

VOLT®G2 Big Par36 Cast Brass Flood Light

VFL-4501-4-BBZ

Wire Connection

Pigtail

MainSupplyCable

Wire Connectors

Main Supply Cable

Strip both leads from the xture pigtail. Using two UL listed wire

connectors (sold separately), connect the leads from the xture to the

main supply cable leads.

Fixture

Supply Wire

Adjust Fixture

Fixture

Screw

ROTATE

Loosen the knuckle and adjust the

xture to the desired orientation.

Tighten the knuckle after you nd

the desired orientation.

[email protected] • 813.978.3700

- 7 -

Install/Replace PAR36 Bulb

Reverse Step 1 - Step 3 to expose the PAR36 bulb and replace it with correct

wattage and type marked on luminaire label. Reinstall glare guard.

IMPORTANT: Halogen lamps must be protected from moisture and dust

at all times. Always reinstall glare guard when removed.
