Volt VPL-1019-26-4-BBZ Bedienungsanleitung

VOLT®Low Voltage Landscape Lighting

VOLT®Customizable Bollard Light

VPL-1019-26-4-BBZ

INSTALLATION INSTRUCTIONS

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

- 1 -

[email protected] • 813.978.3700

VOLT®Customizable Bollard Light

VPL-1019-26-4-BBZ

Important: Please Read Before Installation

INSTALLATION INSTRUCTIONS

Important Safety Instructions

- 2 -

This xture is intended for installation in accordance with local codes and

the National Electric Code (NEC). Failure to adhere to these codes and

instructions may result in serious injury, property damage and void the

warranty.

These instructions do not intend to cover all variations in installation,

operation maintenance or mounting situations.

1. Make sure that the power is turned OFF before installing or servicing

this xture.

2. Warning: this xture is not intended to be installed within 10 feet [3

meters] of a pool, spa or fountain.

3. This xture is intended to be used only with a power supply

(transformer) rated maximum of 50 watts (25 AMPS) at 12 volts.

4. Underground Low Energy Cable must not be buried over 6” (15.2 cm)

in order to connect to the main low voltage cable.

5. Wiring connections must be made with UL listed wire connectors that

are suitable for outdoor use.

6. Position the wire connector so that it is located within 6 inches (15.2

cm) from a building structure, a luminaire, or tting.

LIGHTED LAMP IS HOT!

WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.

1. Turn off/unplug and allow to cool before reducing lamp.

2. Lamp gets HOT quickly!

3. Do not touch the hot lens, guard or cowl.

4. Keep lamp away from materials that may burn.

5. Do not touch lamp at any time.

6. Use a soft cloth.

7. Oil from skin may damage lamp.

8. Do not operate the xture with a damaged or missing lens or shield.

Product Dimensions

- 3 -

www.voltlighting.com

Package Contents

Parts Required

A. (1) Fixture Body C. (2) Threaded Couplers

B. (2) Bi-Pin Brass Puck Lights

A. (4) Side Panels

B. Mounting Accessory

8”x8”

6.38”x6.38”

25.87”

3”

www.voltlighting.com

INSTALLATION INSTRUCTIONS

- 4 -

VOLT®Customizable Bollard Light

VPL-1019-26-4-BBZ

Remove Top Cover

Push

Rotate

Remove

Top Cover

Fixture

Push the top cover down and rotate it clockwise to remove it from the

xture.

[email protected] • 813.978.3700

- 5 -

Install Side Panels

Insert the side panels of your choice into the slots on the xture body.

Side Panel

Slot

Fixture

OPTIONAL SIDE PANELS

INSTALLATION INSTRUCTIONS

www.voltlighting.com

- 6 -

VOLT®Customizable Bollard Light

VPL-1019-26-4-BBZ

Install Top Cover

Push

Rotate

Top Cover

Hole

Bolt

Fixture

Align the bolts on the top cover

to the holes on top of the xture.

Insert the bolts into the holes and

push down. Then rotate the top

cover counter clockwise to secure

it in place.

Install Stakes to Fixture

Lay the xture down on a at surface. Twist the couplers into the

mounting holes on the bottom of the xture. Then thread the stakes onto

the couplers. Hand tighten until snug to secure the stakes to the xture.

Fixture

Coupler

[email protected] • 813.978.3700

- 7 -

Install Fixture

Fixture

Determine the desired location for

the xture. Insert the stakes into

the ground until ange of stakes

are ush to grade.

NOTE: If the ground is hard and the

stakes are difcult to install, make

a crosscut in the ground using a at

shovel.

Stake

Ground

Pigtail

Wire Connection

Strip both leads from the luminaire pigtail. Using two UL listed wire

connectors (sold separately), connect the leads from the xture to the

main supply cable leads.

Pigtail

Main Supply Cable

Wire Connectors

INSTALLATION INSTRUCTIONS

www.voltlighting.com

- 8 -

VOLT®Customizable Bollard Light

VPL-1019-26-4-BBZ

Replace Bi-Pin

12 3

1. Remove the cover off the bottom and top of the xture.

2. Using a screwdriver, remove the two screws from the socket base.

Insert the Bi-pin brass puck light onto the socket and secure with the

two screws.

3. Thread the previously removed cover back onto the socket base.

CAUTION: This xture is for LED use only. Do not exceed maximum

wattage marked on luminaire label.

NOTE: DO NOT touch the Bi-pin brass puck light with bare hands. Use soft

cloth to handle the puck light.

Cover

Socket

Base

Socket

Base

Socket

Screw Bi-pin

Puck Light
