Volt 310 Series Bedienungsanleitung

VOLT®Low Voltage Landscape Lighting

Black Path & Area Lights

INSTALLATION INSTRUCTIONS

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

VOLT®Low Voltage Landscape Lighting

Path & Area Lights

Important: Please Read Before Installation

IMPORTANT SAFETY INSTRUCTIONS

INSTALLATION INSTRUCTIONS

This luminaire is intended for installation in accordance with local codes

and the National Electric Code (NEC). Failure to adhere to these codes and

instructions may result in serious injury, property damage and void the

warranty.

These instructions do not intend to cover all variations in installation,

operation maintenance or mounting situation.

1. Make sure that the power is turned OFF before installing or servicing this

luminaire.

2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M) or

more from pool, spa or fountain.

3. This luminaire is intended to be used only with a power supply

(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.

4. Wiring connections must be made with wire connectors that is suitable for

outdoor use.

5. Position the low voltage wire and wire connector so that it is located

within 6 inches (15.2 cm) from a building structure, a luminaire or tting.

6. The main low voltage cable is intended for shallow burial - less than 6

inches (152 mm)

7. If additional lengths of low voltage cable is required, please contact www.

voltlighting.com or call 1-813-978-3700.

INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS

Lighted lamp is HOT!

WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.

1. Turn off/unplug and allow to cool before replacing lamp.

2. Lamp gets HOT quickly! Contact only switch/plug when turning on.

3. Do not touch the hot lens, guard or enclosure.

4. Keep lamp away from materials that may burn.

5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may

damage lamp.

6. Do not operate the luminaire tting with a missing or damage shield.

SAVE THESE INSTRUCTIONS

www.voltlighting.com

customersupport@voltlighting.com • 813.978.3700

Package Contents

A. (1) Finial

B. (1) Waterproof Washer

C. (1) Shade

D. (1) Inner Shield

E. (1) Harp

F. (1) Stake

G. (1) Rod with Socket

Product Dimensions

9”

23/4”

21 1/2”

7”

2 3/4”

21”

5”

2 1/2”

21 1/2”

6”

3”

21”

7”

23/4”

21”

310 Series 320 Series 322 Series

330 Series 340 Series

INSTALLATION INSTRUCTIONS

www.voltlighting.com

VOLT®Low Voltage Landscape Lighting

Path & Area Lights

Screw harp off socket assembly. Remove

harp and glass lens from socket assembly.

Remove Harp and Glass Lens

Harp

Glass Lens

Socket

Assembly

Install Stake

Determine desired location for mounting

luminaire. Hammer stake into ground until

ange of stake is ush to grade. To avoid

damage to stake, place a board on top of stake

while hammering.

NOTE: If ground is hard and stake is difcult to

install, make a crosscut in ground using a at

shovel.

Board

Stake

Soil

Ground

customersupport@voltlighting.com • 813.978.3700

Install Shade

Place shade and waterproof washer

on top end of harp and secure with

nial. Hand tighten until snug.

Finial

Waterproof

Washer

Shade

Harp

Insert lamp with correct wattage and type

marked on luminaire label.

CAUTION: Do not exceed maximum

wattage marked on luminaire label.

NOTE: DO NOT touch lamp with bare

hands. Use soft cloth to handle lamp.

Place glass lens back onto socket assembly

and screw harp on.

Install Lamp

Harp

Lamp

Glass Lens

Socket

Assembly

www.voltlighting.com

VOLT®Low Voltage Landscape Lighting

Path & Area Lights

INSTALLATION INSTRUCTIONS

Wire Connections

Pigtail

Main Low Voltage

Supply Cable

Strip two leads from luminaire pigtail. Using two wire connectors, sold

separately, connect leads from luminaire to main low voltage supply

cable leads.

Wire Connectors

Install Luminaire to Stake

Clear away area in ground at wireway

slot in top of stake. Lay luminaire

pigtail into wireway slot and screw

stem into stake. If assembly does

not look straight, adjust by pushing

or pulling on stake only. Use bubble

level against side of stem to make

sure stem is perpendicular to ground.

Pigtail

Stem

Stake

Wireway Slot

customersupport@voltlighting.com • 813.978.3700

Maintenance – Install/Replace Lamp

Please reverse Step 2 - Step 4 to expose the lamp and replace it with

correct wattage and type marked on luminaire label. Reinstall inner shield

and shade.

IMPORTANT: Halogen lamps must be protected from moisture and dust at all

times. Always re-install shade and lens when moved.

Specications and product details subject to change without notice.

reserved [email protected] • 813.978.3700

www.voltlighting.com

is-stem-bk-ver1.pdf

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
