Volt VPL-3025 Series Bedienungsanleitung

VOLT®Low Voltage Landscape Lighting

VOLT®All-StarTM Mini Innovator Path & Area Light

VPL-3025 Series

INSTALLATION INSTRUCTIONS

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

- 1 -

All-StarTM Mini Innovator Path & Area Light

VPL-3025 Series

Package Contents

Product Dimensions

Important: Please Read Before Installation

Important Safety Instructions

INSTALLATION INSTRUCTIONS

This xture is intended for installation in accordance with local codes and

the National Electric Code (NEC). Failure to adhere to these codes and

instructions may result in serious injury, property damage and void the

warranty.

These instructions do not intend to cover all variations in installation,

operation maintenance or mounting situations.

1. Make sure that the power is turned OFF before installing or servicing

this luminaire.

2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M)

or more from pool, spa or fountain.

3. This luminaire is intended to be used only with a power supply

(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.

4. Wiring connections must be made with wire connectors that are suitable

for outdoor use.

5. Position the low voltage wire and wire connector so that it is

located within 6 inches (15.2 cm) from a building structure, a luminaire

or tting.

6. The main low voltage cable is intended for shallow burial - less than 6

inches (152 mm).

7. If additional lengths of low voltage cable are required, please contact

www.voltlighting.com or call 1-813-978-3700.

INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS

Lighted lamp is HOT!

WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.

1. Turn off/unplug and allow to cool before replacing lamp.

2. Lamp gets HOT quickly! Contact only switch/plug when turning on.

3. Do not touch the hot lens, guard or enclosure.

4. Keep lamp away from materials that may burn.

5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may

damage lamp.

6. Do not operate the luminaire tting with a missing or damaged shield.

SAVE THESE INSTRUCTIONS

A. (1) Stem

B. (1) Fixture Body

www.voltlighting.com [email protected] • 813.978.3700

C. (1) Stake

- 3 -- 2 -

7.5”

26.2”

Parts Required (sold separately)

A. (1) MR11 Bulb

4.5”

3.2”

2.7”

www.voltlighting.com [email protected] • 813.978.3700

Install Shield and Glare Guard

Set Screw

Shield

Fixture Body

Glare Guard

Place the shield over the bulb and

thread onto the xture. Attach the

glare guard back onto the shield and

secure with the set screw.

INSTALLATION INSTRUCTIONS

- 5 -- 4 -

Install Fixture Body to Stem

Pass the supply wire from the

xture body through the stem.

Thread the xture body onto

the stem. Then tighten the set

screw to lock the xture body

into place.

Set Screw

Fixture Body

Supply Wire

Stem

Remove Shield and Glare Guard

Loosen the set screw and remove

the glare guard from the shield.

Remove the shield from the

xture body.

Set Screw

Shield

Fixture Body

Glare Guard

Install Bulb

Insert the bulb with the correct

wattage and type marked on the

xture label.

CAUTION: Do not exceed maximum

wattage marked on luminaire label.

NOTE: DO NOT touch bulb with bare

hands. Use soft cloth to handle

bulb.

Socket

MR11 Bulb

Install Stake

Determine the desired location for

mounting the xture. Hammer the stake

into the ground until ange of stake is

ush to grade. To avoid damage to the

stake, place a board on top of the stake

while hammering.

NOTE: If the ground is hard and the

stake is difcult to install, make a

crosscut in the ground using a at

shovel.

Board

Stake

Soil

Ground

All-StarTM Mini Innovator Path & Area Light

VPL-3025 Series

INSTALLATION INSTRUCTIONS

www.voltlighting.com [email protected] • 813.978.3700

- 7 -- 6 -

Adjust Angle of Fixture Body

Using an Allen Wrench, loosen the

adjustment screws and modify

the xture body to the desired

angle. Then tighten the

adjustment screws.

Allen Wrench

Adjustment Screw

Clear away an area in the ground at

the wireway slot on top of the stake.

Lay the luminaire pigtail into the

wireway slot and attach the xture

onto the stake.

Install Fixture to Stake

Fixture

Stake

Pigtail

Wireway Slot

Wire Connection

Strip both leads from the luminaire pigtail. Using two wire connectors

(sold separately), connect the leads from the luminaire to the main

supply cable leads.

Pigtail

Main Supply Cable

Wire Connectors

Install/Replace Bulb

Loosen the set screw on glare guard, remove the glare guard and the

shield to expose the bulb. Replace it with the correct wattage and type

marked on the xture label. Then reinstall the shield and glare guard and

tighten with the set screw.

IMPORTANT: Halogen bulb must be protected from moisture and dust at all

times. Always reinstall the shield and glare guard when removed.

All-StarTM Mini Innovator Path & Area Light

VPL-3025 Series

is-VPL-3025-ver5.pdf

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

www.voltlighting.com

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

- 8 -
