Vacuum Cleaner G10 Plus User Manual

Safety Instructions

This product is for household use only. Read this manual carefully before use, and retain it for future reference.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

Do not use the product at an ambient temperature above 38°C or below 5°C or on a floor with liquids or sticky substances.

If the charger or battery pack is damaged, it must be replaced by a special cord or assembly available from the manufacturer or

its service agent.

To reduce the risk of fire, explosion, or personal injury, check to make sure the lithium-ion battery and charger are undamaged

before use. Do not use the vacuum cleaner if either the battery or charger is damaged.

Only use the vacuum cleaner on dry indoor surfaces. Do not install, charge, or use this product outdoors, such as in bathrooms,

or near a pool.

Do not touch the plug or any part of the vacuum cleaner with wet hands.

The high torque brush bar, mini electric brush, battery, extension rod, and the vacuum cleaner are electrically conductive and

should not be immersed in water or other liquid. Make sure all parts are thoroughly dry after you carry out cleaning on them.

To prevent injury caused by moving parts, turn off the vacuum cleaner before cleaning the high torque brush bar and mini electric

brush. The high torque brush bar, dust compartment, and filter must all be properly installed before using the vacuum cleaner.

Do not use the vacuum cleaner to pick up flammable or combustible liquids, such as gasoline, bleach, ammonia, or drain cleaners;

nor other liquids like water.

Do not use the vacuum cleaner to pick up drywall particles, ashes like fireplace ash, or smoking or burning materials such as coal,

cigarette butts or matches.

Do not use the vacuum cleaner to pick up sharp or hard objects, such as glass, nails, screws, or coins, which may damage the product.

Keep hair, loose clothing, fingers, and other parts of the body away from the vacuum cleaner's openings and moving parts. Do not

point the suction opening, extension rod, or other accessories at your eyes or ears or put them in your mouth.

Do not put any object into the vacuum cleaner's openings, nor use the vacuum cleaner with any opening blocked. Keep free of

dust, lint, hair, or other items which may reduce airflow.

Do not rest the vacuum cleaner against a chair, table, or other unstable surfaces, as this may cause damage to the product or

personal injury. If the vacuum cleaner malfunctions because of being knocked over or damaged, please contact the authorized

service department. Never attempt to disassemble the vacuum cleaner on your own.

The dust compartment cover, pre-filter, cyclone assembly, and filter must all be properly installed prior to using the vacuum cleaner.

Make sure the charger is unplugged when not used for extended periods as well as prior to performing any maintenance or repairs.

Please be extra careful when using the vacuum cleaner to clean stairs.

Fire Hazard Warning: Do not apply any type of fragrance to the vacuum cleaner's filter. These types of products are known to

contain flammable chemicals which may cause the vacuum cleaner to catch fire.

DO NOT expose the battery and appliance to fire as it may cause explosion.

DO NOT expose or submerge the battery and appliance in any water, salt water, or other liquids.

WARNING: Do not use any third-party battery pack and charger.

Use only with BLJ24W308080P-V charger.

Use only with V2210-7S1P-BCA/V2210-7S1P-BWA battery pack.

Please strictly follow the instructions in this user manual when using the vacuum cleaner. Users are responsible for any loss or

damage that may arise from improper use of the vacuum cleaner.

Product Overview

Accessories List

Note: Illustrations of product, accessories, and user interface in the user manual are for reference purposes only. Actual product and functions may vary due to

product enhancements.

Crevice Nozzle

Mini Electric BrushExtension Rod 2-in-1 Brush Nozzle

High Torque Brush Bar

Water Tank

2-in-1 Charging & Storage Mount

(includes screw × 2, wall plug × 2, and

mounting template sticker)

Charger

Mop Pad

(Pre-installed)

Component Name

Dust Compartment Bottom

Cover Release Button

Antistatic Contact

Dust Compartment

Charging Port

Power Button

Press: Turn on

Release: Turn off

Charging Contact

Dust Compartment

Release Switch

Display Screen

Battery Release Button

Battery Status Indicator

Display Screen

Note: If the vacuum cleaner experiences a malfunction, the display screen will show an error message. For a solution, please refer to the Troubleshooting section.

Lock/Unlock Status Battery Level Indicator

Electronic Lock Button

Charging/Low Battery Level Indicator

Battery Level Percentage

The indicator displays the remaining battery.

When the battery level is lower than 10%, the

indicator will change from green to red.

Error Message

Modes

Suction Level Button

Blinking red: Battery level ≤ 10%

Green: Battery level > 10%

Pulsing red: Battery level ≤ 10% (charging)

Pulsing green: Battery level > 10% (charging)

When the display shows "LO", it indicates that the

battery level is lower than 10%.

Filter Not Installed

Roller Brush Stuck

Airway Blocked

High-temperature Alert

High Power

Standard

Eco

Press to enable/disable the continuous mode

Press to switch the suction levels

Installing the Accessories onto the Vacuum Cleaner

Note: Mini electric brush should not be used with the extension rod.

How to Install

Insert until it clicks into place

Installing the 2-in-1 Charging & Storage Mount

1. The 2-in-1 charging & storage mount should be installed in a cool, dry place with an electrical outlet nearby. Prior to installing, ensure that there are not any wires

or pipes in the space directly behind where the mount will be installed.

2. The bottom of the mounting template sticker should be level and at least 1.03 m from the ground, and its top should have at least 30 cm of clearance above it.

3. Use a power drill with an 8 mm drill bit to drill a hole into each hole marker on the mounting template sticker, then insert a wall plug into each hole.

4. Align the mounting holes on the 2-in-1 charging & storage mount to the holes on the wall, then attach the mount to the wall using the included screws.

Recommended Height: At least 1.03 meters from the ground

The replaceable battery is not

included and purchased separately.

Extended Dock Charging Plate

Extended Dock

Located on the top of the 2-in-1

charging & storage mount and used

for installing the battery pack*. It

supports charging the battery pack

together with the vacuum cleaner.

103 cm

30 cm

Display Screen

The number on the display screen represents the current battery level in a

percentage during charging. When the number turns into 100, the battery is

fully charged.

When the vacuum cleaner is being charged, you can press the power button to

wake up the display and check the current charging percentage.

Charging

Notes:

Fully charge the vacuum cleaner before using it for the first time. This will take

about 4 hours.

The vacuum cleaner cannot be used while charging.

Vacuuming at the highest suction level for a prolonged period will cause the

battery to heat up, which may increase the charging time. Before charging the

vacuum cleaner, it is better to cool it down for 30 minutes.

Battery Status Indicator

Once the vacuum cleaner is fully charged, the indicator will turn off after 5 minutes, and the

vacuum cleaner will then enter the energy-saving mode.

Note: means off, means on, and means blinking.

Low battery

Fully charged

Half battery

Nearly full

Charging the vacuum cleaner with the charger

Battery Status Indicator

Charging the vacuum cleaner on the charging mount

Charging Contact

Working Modes

The vacuum cleaner has two working modes, you can select the desired one

based on your cleaning needs.

Non-continuous Mode

Hold down the power button to start the vacuum cleaner, then release to

stop it.

Continuous Mode

Notes:

In Continuous Mode, the vacuum cleaner will enter into standby mode when

pressing the power button, and resume running if pressing the button again.

When the vacuum cleaner keeps in standby mode for more than 10 seconds,

its display screen will go off and the vacuum cleaner will then exit the

Continuous Mode.

Continuous Mode

Press the button to enable Continuous Mode, then press the power button

to turn the vacuum cleaner on. To exit Continuous Mode, press the button .

Enabling the Continuous Mode allows the vacuum cleaner to run continuously

without having to hold down the power button, which can help release your

fingers.

How to Use

Switching Suction Levels

Non-continuous Mode

Press the button to cycle through the vacuum cleaner's suction levels of

Eco, Standard, and Turbo. The corresponding suction level indicator will be

highlighted on the display.

Note: After the vacuum cleaner is turned off and turned back on again, the

suction level will be the last used one.
