Agilent Technologies

Agilent 16800 Series

Portable Logic Analyzers

Installation/Quick Start

Guide

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2 16800 Series Portable Logic Analyzers Installation/Quick Start Guide

Notices

No part of this manual may be reproduced in

any form or by any means (including elec-

tronic storage and retrieval or translation

into a foreign language) without prior agree-

ment and written consent from Agilent

Technologies, Inc. as governed by United

States and international copyright laws.

Manual Part Number

16800-97000

Edition

First Edition, July 2006

Printed in Malaysia

Agilent Technologies, Inc.

1900 Garden of the Gods Road

Colorado Springs, CO 80907 USA

Warranty

The material contained in this docu-

ment is provided “as is,” and is sub-

ject to being changed, without notice,

in future editions. Further, to the max-

imum extent permitted by applicable

law, Agilent disclaims all warranties,

either express or implied, with regard

to this manual and any information

contained herein, including but not

limited to the implied warranties of

merchantability and fitness for a par-

ticular purpose. Agilent shall not be

liable for errors or for incidental or

consequential damages in connec-

tion with the furnishing, use, or per-

formance of this document or of any

information contained herein. Should

Agilent and the user have a separate

written agreement with warranty

terms covering the material in this

document that conflict with these

terms, the warranty terms in the sep-

arate agreement shall control.

Technology Licenses

The hardware and/or software described in

this document are furnished under a license

and may be used or copied only in accor-

dance with the terms of such license.

Restricted Rights Legend

U.S. Government Restricted Rights. Soft-

ware and technical data rights granted to

the federal government include only those

rights customarily provided to end user cus-

tomers. Agilent provides this customary

commercial license in Software and techni-

cal data pursuant to FAR 12.211 (Technical

Data) and 12.212 (Computer Software) and,

for the Department of Defense, DFARS

252.227-7015 (Technical Data - Commercial

Items) and DFARS 227.7202-3 (Rights in

Commercial Computer Software or Com-

puter Software Documentation).

Safety Notices

CAUTION

A CAUTION notice denotes a haz-

ard. It calls attention to an operat-

ing procedure, practice, or the like

that, if not correctly performed or

adhered to, could result in damage

to the product or loss of important

data. Do not proceed beyond a

CAUTION notice until the indicated

conditions are fully understood and

met.

WARNING

A WARNING notice denotes a

hazard. It calls attention to an

operating procedure, practice, or

the like that, if not correctly per-

formed or adhered to, could result

in personal injury or death. Do not

proceed beyond a WARNING

notice until the indicated condi-

tions are fully understood and

met.

Microsoft ®is a U.S. registered trademark

of Microsoft Corporation.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

16800 Series Portable Logic Analyzers Installation/Quick Start Guide 3

16800 Series Logic Analyzers—At a Glance

The Agilent Technologies 16800 Series logic analyzers are

portable logic analyzers that range from 34 to 204 logic

acquisition channels and 48 pattern generator channels,

depending on the model.

Pod Cables

Accessories Pouch (top flap)

Tie-down Straps

Run/Stop Keys

USB 2.0 Ports (2)

Scroll Knob

Table 1 Model comparisons

Agilent model number 16801A 16802A 16803A 16804A 16806A 16821A 16822A 16823A

Logic acquisition channels 34 68 102 136 204 34 68 102

Pattern generator channels 0 0 0 0 0 48 48 48

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4 16800 Series Portable Logic Analyzers Installation/Quick Start Guide

Features, Logic Acquisition

• 1 M to 32 M memory depth per channel (depending on

memory option), software upgradeable.

• 250 MHz or 500 Mb/s maximum state data rate (depending

on state speed option), software upgradeable. The 500 Mb/s

maximum state data rate option is available on the

68-channel and above logic analyzer models.

• 1 GHz, 64 M deep timing analysis on half channels.

•Eye finder (automatic threshold and sample position setup)

feature.

• 4 GHz timing zoom with 64 K memory depth.

Features, Mainframe

• Built-in 15 inch TFT color LCD display, 1,024 x 768 (XGA)

resolution. Touch screen with 16800A Option 103.

• 80 GB hard disk drive (or external hard drive 16800A Option

109).

• 10/100 Base-T LAN port.

• USB 2.0 ports (six total, two on front, four on back).

• One PCI expansion slot.

• One PCI Express x1 expansion slot.

• Windows® XP Professional operating system.

•Agilent Logic Analyzer application which takes the

complexity out of making logic analyzer measurements. You

can perform all operations directly from one window.

Features, Pattern Generator

• 24 channels at 300 MHz clock; 48 channels at 180 MHz clock.

• Memory Depth: 16,777,216 vectors in half-channel mode.

• Logic Level (data pods): 5 V TTL, 3-state TTL, 3-state

TTL/CMOS, 3-state 1.8 V, 3-state 2.5 V, 3-state 3.3 V, ECL, 5 V

PECL, 3.3 V LVPECL, and LVDS.

• Data Inputs: 3-bit pattern level sensing (clock pod).

• Clock Output: Synchronized to output data, delay of 7 ns in

14 steps (clock pod).

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

16800 Series Portable Logic Analyzers Installation/Quick Start Guide 5

• Clock Input: DC to 300 MHz (clock pod).

• Internal Clock Period: Programmable from 1 MHz to

300 MHz in 1 MHz steps.

• External Clock Period: DC to 300 MHz.

• External Clock Duty Cycle: 1.3 ns minimum high time.

Supplied Accessories

•PS2mouse.

•PS2keyboard.

• Accessory pouch and power cord.

Snap the accessories pouch to the top of the 16800 Series

logic analyzer. Use it to store probe leads, accessories, or

manuals. Use the tie-down straps under the flap to

conveniently hold pod cables not in use or during transport.

Optional Accessories

•Probes.

Front Panel

Refer to the online help in the logic analyzer for information on

using the analyzer.

Rear Panel

Before you turn on the system, connect your mouse and

keyboard to the 16800 Series logic analyzer rear panel. If a

touch screen (Option 103) is not included, a connected mouse

and keyboard are required for normal system use.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6 16800 Series Portable Logic Analyzers Installation/Quick Start Guide

In This Guide…

This guide describes how to set up, use, and update your 16800

Series logic analyzer. It also contains information on solving

problems and additional safety information.

1 First-Time Set Up

This chapter describes the steps in setting up the logic analyzer

for the first time.

2 Getting Started with the Logic Analyzer

This chapter describes some basic features of the logic analyzer

and tells you where to find more information on using the logic

analyzer.

3UpdatingtheLogicAnalyzer

This chapter describes how to change your logic analyzer’s

network and Windows Firewall settings. It also describes how to

get and install software updates.

4 Solving Problems

This chapter describes the logic analyzer’s built-in self tests and

recovering system software.

5SafetyNotices

This chapter contains additional safety information.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

16800 Series Portable Logic Analyzers Installation/Quick Start Guide 7

Contents

1 First-Time Set Up 11

Proper Cooling 12

First-Time Set Up Considerations 13

Determine Whether the Instrument will be Connected to the Network 13

Get Network Setup Information 14

Answering Windows Welcome Questions 15

If expected Windows Welcome questions do not appear 16

Additional First-Time Setup Steps 17

Establishing an Administrator Account (recommended for standalone and

networked instruments) 17

Protecting the Instrument’s Operating System 17

2 Getting Started with the Logic Analyzer 19

Probing 20

Making a Measurement 21

Snap to Edge Markers 23

Left-Click Menus 24

Tree Structure Bus/Signal Names 24

Offline Analysis 25

Marker Overview 25

Tool Tips 26

Trigger History 27

To power off the system 28

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8 16800 Series Portable Logic Analyzers Installation/Quick Start Guide

Contents

Using the Windows Shutdown 28

Using a Short Press of the Power Button 28

Using a Long Press of the Power Button 29

Unplugging the Power Cord or Power Loss 29

Specifications and Characteristics 30

3 Updating the Logic Analyzer 33

Changing Network Settings 34

Changing Windows Firewall Settings 35

To give other applications/ports access through the firewall 35

To restore the logic analyzer firewall defaults 37

Software Installation and Upgrades 40

Agilent Logic Analyzer Software 40

Optional Products 40

4 Solving Problems 41

Running Self-Tests 42

If the logic analyzer powers itself down 43

If the Power LEDs do not come on 43

If you get a registry error and the system won’t boot 43

If there are network connection problems 44

If there are touch screen problems 45

Using the System Recovery Software 46

Contacting Agilent Service/Support 46

5SafetyNotices47

Warnings 48

To clean the instrument 49

Safety Symbols 50

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Contents

16800 Series Portable Logic Analyzers Installation/Quick Start Guide 9

Index 51

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Andere Handbücher für 16800 Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Agilent Technologies Messgerät Handbücher

Agilent Technologies

Agilent Technologies 8720E Series Bedienungsanleitung

Agilent Technologies

Agilent Technologies M9302A Bedienungsanleitung

Agilent Technologies

Agilent Technologies WireScope 350 Bedienungsanleitung

Agilent Technologies

Agilent Technologies E4418B Bedienungsanleitung

Agilent Technologies

Agilent Technologies U1731A Bedienungsanleitung

Agilent Technologies

Agilent Technologies 16700 SERIES LOGIC ANALYSIS SYSTEM 16700 Bedienungs- und Sicherheitshinweise

Agilent Technologies

Agilent Technologies E4402B Option H3B Handbuch

Agilent Technologies

Agilent Technologies E4411-60019 Installations- und Betriebshandbuch

Agilent Technologies

Agilent Technologies 4155C Bedienungsanleitung

Agilent Technologies

Agilent Technologies 8753ET Bedienungsanleitung

Agilent Technologies

Agilent Technologies E8363BU-014 Installations- und Betriebshandbuch

Agilent Technologies

Agilent Technologies 4284A Bedienungsanleitung

Agilent Technologies

Agilent Technologies Agilent 4396B Bedienungsanleitung

Agilent Technologies

Agilent Technologies OmniBER OTN Series Bedienungsanleitung

Agilent Technologies

Agilent Technologies Agilent 4396B Bedienungsanleitung

Agilent Technologies

Agilent Technologies 16850 Series Bedienungsanleitung

Agilent Technologies

Agilent Technologies 85052A Betriebsanleitung

Agilent Technologies

Agilent Technologies LogicWave Bedienungsanleitung

Agilent Technologies

Agilent Technologies 6813B Bedienungsanleitung

Agilent Technologies

Agilent Technologies 4339B Bedienungsanleitung

Agilent Technologies

Agilent Technologies 8720ES Service-Handbuch

Agilent Technologies

Agilent Technologies PSA Series Bedienungsanleitung

Agilent Technologies

Agilent Technologies Acqiris U10 Series Bedienungsanleitung

Agilent Technologies

Agilent Technologies X Series Bedienungsanleitung

Beliebte Messgerät Handbücher anderer Marken

Suaoki

Suaoki D40 Bedienungsanleitung

Elster

Elster BK-G1.6 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Deltabar FMD71 Handbuch

Duratool

Duratool D03128 Bedienungsanleitung

Vega

Vega VEGAPULS 65 Bedienungsanleitung

Tonghui

Tonghui TH2618B Bedienungsanleitung

Tenmars

Tenmars TM-801 Bedienungsanleitung

MSR

MSR 145 Bedienungsanleitung

TPS

TPS WP-82 Bedienungsanleitung

ELMETRON

ELMETRON CP-511 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics 003C30 Bedienungsanleitung

Tenma

Tenma 72-10465 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Proline Promag 50 Technische Daten

Siemens

Siemens SITRANS F Coriolis FCT030 Stücklistenhandbuch

KLINGER

KLINGER CMF V Series Bedienungsanleitung

EXFO

EXFO FTB-2 Bedienungs- und Wartungshandbuch

Keysight

Keysight M8290A Bedienungsanleitung

ADTEK

ADTEK MW-5 Bedienungsanleitung
