BestScope BS-2081 Bedienungsanleitung

BS-2081,2083 Scientific Microscope

Instruction Manual

This manual is for users of BS-2081,2083 Scientific Microscope in laboratory. To ensure your safety, obtain

optimum performance, and to familiarize yourself fully with the use of this microscope, we recommended that

you study the instruction manual carefully.

BestScope International Limited

Contents

Notice For Use................................................................................................................ 3

1.Components Name..................................................................................................... 5

2.Structure Overview..................................................................................................... 6

3.Adjustment And Operation......................................................................................... 8

3.1Open Power Source...............................................................................................8

3.2Adjust Lighting And Switch Light Source............................................................... 8

3.3Light Source Socket............................................................................................... 8

3.4Mount Specimen And Adjust Stage...................................................................... 9

3.5Adjust Interpupillary Distance...............................................................................9

3.6Three Light Path Switching.................................................................................... 9

3.7Focusing...............................................................................................................10

3.8 Handwheel For Adjusingt The Tightness Of Focusing........................................ 10

3.9The Limit Of Focusing..........................................................................................11

3.10Adjust The Pendulum Type Condenser............................................................. 11

3.11Using ND Filter.................................................................................................. 12

3.12The Using OF Extensional Function Board........................................................ 12

3.13ECO Function Key.............................................................................................. 12

3.14Replace Fuse......................................................................................................13

3.15ECO Device........................................................................................................ 14

4.Installation.................................................................................................................15

4.1 Installation Diagram........................................................................................... 15

4-2 procedure...........................................................................................................16

4-2-1Install The Mechanical Slide Bracket ....................................................... 17

4-2-2Install The Mechanical Object Stage..........................................................17

4-2-3Install Nosepiece........................................................................................18

4-2-4Install Camera Lens And Photo Acc........................................................... 18

4-2-5Install Eyepiece.......................................................................................... 18

BestScope International Limited

4-2-6Install Objective......................................................................................... 19

4-2-7Install The Pendulum Type Condenser...................................................... 19

4-2-8Replace The Camera Interface...................................................................19

4-2-9Install The LED Lamp Chamber.................................................................. 20

5．Technical Specification........................................................................................... 21

6.Troubleshooting guide...............................................................................................23

6.1 Optical Part.........................................................................................................23

6.2 Mechanical System............................................................................................ 25

6.3 Electrical System................................................................................................ 26

BestScope International Limited

Notice For Use BS-2081,2083

I. Safety Precaution

Symbol

Description

During use, the power box of microscope become very hot, so should not

be touched with bare hands.

Before using, please read the user manual carefully. If can not use

inappropriately, it will cause an accident that harm operators or damage

instrument

Power switch is open.

Power switch is closed.

П. Safety Precaution

1. Be careful before opening box. Don’t attach fingerprint and Perspiration on the camera

lens. Prevent camera and some accessories from dropping and damaging.

2. Don’t place microscope in direct sunlight, high temperature, high humidity or dusty, and

vulnerable to strong vibration. Ensure that the objective table is flat ,level and strong enough.

3. When working, near the microscope lamp room will be a little fever. Please ensure that

there is enough heat dissipation space around the room light.

4. Place the microscope on the grounding, avoid lightning strike.

5. To ensure safety, before change halogen lamp or fuse ,please guarantee the main

power switch is “O”, cut off light source, and wait for the light and lamp room are cooling. Check

input voltage: the input voltage indicated on the back of microscope and the power supply

voltage is consistent, otherwise it will lead to serious damage to the microscope.

6. Please use the special wire of the company to provide.

BestScope International Limited

III. Maintenance and Storage

1. All camera lenses are proofread and adjusted. Please tear open outfit

2. Revolving nosepiece and coarse micro focusing mechanism, which structure are

precise. Please don’t remove easily.

3. Instruments shall be kept clean, always remove dust. Please care about that don’t

contaminate optic components.

4. Smears on the optic lens, such as fingerprint ，oil and so on ,which are wiped by

cotton，lens paper or gauze dipping anhydrous alcohol，xylene and ether.( Either,

xylene and alcohol are highly flammable, which can not near open fire. Please use

these chemicals in a well ventilated room.)

5. Don’t use organic solvent to wipe any optic components of microscope. If

cleaning ,please use neutral detergent.

6. When using, if the microscope are wet by liquid, please close power source and wipe

dry right now.

7. Don’t open any component parts of the microscope. Because it will degrade the

performance of the microscope.

8. Place instrument in a shady and dry space. If do not use microscope , please cover

with dust cover. Before covering, please ensure that the light box has cooled.

BestScope International Limited

1.Components Name BS-2081,2083

Eyepiece

Viewing head

Nosepiece

Objective

Stage

Condenser

Mainframe

BestScope International Limited

2.Structure Overview BS-2081,2083

1.Filter switching knob

2.Coarse and fine focusing handwheel

3.Focusing limiting and locking

Handwheel

4.Condenser height adjustment wheel

5.Lighting switching button

6.Lighting adjustment handwheel

7.Condenser

8.”ECO”infrared sensor

9.Coaxial pinion for X stage movement

10.Coaxial pinion for Y stage movement

11.Condenser disk

12.Biopsy clip

13.Screw for fastening extensional board

14. Extensional board

BestScope International Limited

BS-2081,2083

1.pushing rod for switching light path

2.Condenser fastening screw

3.Condenser height adjustment

wheel

4.”ECO”button

5.Aperture size adjustment knob

6.Fine focusing handwheel

7.Coarse focusing handwheel

8.Focusing limiting and locking

handwheel

9.Screw for fastening lamp chamber

10.Socket of lamp chamber

11.Grounding bar

12.Plug of lamp chamber

13.Lamp chamber

14.Allen wrench

BestScope International Limited

3.Adjustment And Operation BS-2081,2083

Fig 1

Fig 2

Fig 3

3.1 Open Power Source(fig.1)

Plug power source, toggle the main switch in ‘－’state，

which on the back of microscope.

3.2 Adjust Lighting And Switch

Light Source (fig 2)

1. Rotating the handwheel according to the direction

indicated by an arrow on the figure 2, the brightness will

increase. If not, brightness will reduce.

2. As shown in figure 2, when the light switch

button is push-in, the light on the top is opening, as

picture . When the light switch button is

push-out, the light on the bottom is opening, as picture

3..3.3 Light Source Socket(fig 3)

As shown in figure 3, the light socket and

the plug all with red dots. Before plugging

in the socket, please adjusting the direction until their

red dots are aligned, then plugging the plug.

☆the silk-screen is corresponding with the switch

button of lights. As shown in the figure, is

the socket of above light source. is the

socket of under light source.

Red dot

BestScope International Limited

BS-2081,2083

Fig 4

Fig 5

Fig 6

★when switching light button, if found the button

is not matched with the shown in the figure,

please check that

3.4 Mount Specimen And Adjust

Stage(fig 4，fig 5)

Push the cover glass slowly into the jaw, then clamp

glass gently.

Rotate handwheel to move ruler athwartships or

length ways. The specimen will be moved to a place

you need.

★Be careful to change objectives. When you have

observed the specimen with a Low-power objective

and needed to change objective, objective may

encounter specimen.

★The degree of tightness of handwheel can be

adjusted. Please Draw down handwheel A and find

two adjusting ring(B,C),then rotate ring. B is the

adjusting ring of X direction. C is the adjusting ring

of Y direction.

★the altitude of handwheel also can be adjusted.

Draw down handwheel A and D can rise integral

handwheels. You can also adjust it to negative

direction and rise handwheels.
