Chapter 1 Getting Started

Diagrams

LS210D

Function

OFF

LS220D/LS220DE

510

1 Power LED

The white power LED will light up while the LinkStation is on.

The white power LED blinks while booting or shutting down.

The red power LED blinks when an error occurs.

If there is a status message, the power LED blinks amber.

If there is new firmware available, the power LED glows amber.

2 Function LED

This LED glows white while the LinkStation is being initialized and while dismounting USB devices. It blinks

white during Direct Copy.

For enclosure model, the red function LED glows when turning the LinkStation on to the initial hard drive

installation and blinks after pushing the function button.

3 Function Button

Use this button for Direct Copy, dismounting USB devices, and initializing settings.

4 Power Switch

Move the switch up and down to power on and off.

5 USB 2.0 Port

Compatible Buffalo USB hard drives, USB flash drives, digital cameras, and USB printers can be connected. USB

hubs are not supported.

6 LAN Port

Connect to a router, hub, or switch on your Ethernet network with the included Ethernet cable.

7 Link and Activity LED

This LED shows network activity. It blinks green when the LinkStation is accessed over the network.

8 Power Connector

Use the included power cable to connect to a surge protector or outlet.

9 Power Status LED

The LED glows green when the power cable is connected.

10 Anti-Theft Security Slot

Use this slot to secure your LinkStation with a cable lock (not included).

11 Drive 1 Error LED (LS220D/LS220DE only)

If there is an error on drive 1, this LED will light.

12 Drive 2 Error LED (LS220D/LS220DE only)

If there is an error on drive 2, this LED will light.

Changing Admin Password and Adding a Shared Folder

After initial setup, changing your password and creating other shared folders are recommended.

1 Double-click the icon to start NAS Navigator2.

2 Right-click on your LinkStation's icon and select Settings. On the Mac, select the LinkStation's icon while

holding down the control key, then select Settings.

3 Changing the password from the default is recommended.

Note: You can open this same screen by clicking Getting Started from Easy Admin.

4 Enter the new password (twice), then click Next.

Note: The default username and password are "admin" and "password". To keep the defaults, leave both fields

blank and click Next.

5 Configure levels of sharing for all existing shared folders (public or private) to complete the initial setup wizard.

Notes:

• Select "Set as private folder" to restrict access to the folder to specific users.

• Click Create Shared Folder to create a new shared folder from the wizard. By default, SMB and AFP connections

can be used to access this folder.

6 Click OK when the following message is displayed.

Installing Applications

NAS Navigator2

1 Insert the LinkNavigator CD into your computer. You can also download the latest LinkNavigator from Buffalo's

website. LinkNavigator will launch.

2 Click NAS Navigator2 Install.

3 Follow the screen instructions to install NAS Navigator2.

4 When the installation finished, click Finish.

SmartPhone Navigator

SmartPhone Navigator will allow to open LinkStation's Settings, change the IP address, and configure WebAccess

settings. Follow the instructions below to install the application.

1 Open the App Store (iOS devices) or Google Play (Android devices).

2 Install "SmartPhone Navigator".

WebAccess

WebAccess will allow you access files in the LinkStation. Follow the instructions below to install WebAccess

application.

1 Open the App Store (iOS devices) or Google Play (Android devices).

2 Install "WebAccess".

Accessing Shared Folders

Accessing from a Computer

1 Double-click the icon to start NAS Navigator2.

2 In NAS Navigator2, double-click your LinkStation's icon. The Explorer will open with shared folders' lists. For

Mac OS, the LinkStation is mounted as a drive icon on the desktop or it is displayed in the sidebar of the Finder.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Buffalo Netzwerkspeicherserver Handbücher

Buffalo

Buffalo iSCSI Rackmount TeraStation Pro Bedienungsanleitung

Buffalo

Buffalo LS520D Series Bedienungsanleitung

Buffalo

Buffalo TeraStation Bedienungsanleitung

Buffalo

Buffalo TeraStation WSS 5000 Bedienungsanleitung

Buffalo

Buffalo TeraStation Pro WSS Bedienungsanleitung

Buffalo

Buffalo TeraStation WSH5610DN2 Bedienungsanleitung

Buffalo

Buffalo TS3210DN Bedienungsanleitung

Buffalo

Buffalo TeraStation WSS WS5020N6 Bedienungsanleitung

Buffalo

Buffalo TeraStation Benutzerhandbuch

Buffalo

Buffalo LS520D Series Bedienungsanleitung

Buffalo

Buffalo LinkStation 200 Series Bedienungsanleitung

Buffalo

Buffalo HD-RQSSU2/R5 Bedienungsanleitung

Buffalo

Buffalo TeraStation 3020 Bedienungsanleitung

Buffalo

Buffalo TeraStation III TS-IXL Bedienungsanleitung

Buffalo

Buffalo TeraStation WSS 5000 Bedienungsanleitung

Buffalo

Buffalo CloudStation CS-X Bedienungsanleitung

Buffalo

Buffalo TeraStation WSS HR WSH5000N2 Series Bedienungsanleitung

Buffalo

Buffalo LS220D0802-EU Bedienungsanleitung

Buffalo

Buffalo TeraStation 5010 TS5210DN Bedienungsanleitung

Buffalo

Buffalo LinkStation LS220D Series Bedienungsanleitung

Buffalo

Buffalo BS-GS2008P Bedienungsanleitung

Buffalo

Buffalo LinkStation Live Bedienungsanleitung

Buffalo

Buffalo TERASTATION HS-D1.0TGL/R5 Bedienungsanleitung

Buffalo

Buffalo TeraStation WSS 5000 Bedienungsanleitung

Beliebte Netzwerkspeicherserver Handbücher anderer Marken

HP NetStorage 6000 Bedienungsanleitung

Seagate

Seagate U10 ST320423A Bedienungsanleitung

Synology

Synology RackStation RS816 Handbuch

D-Link

D-Link ShareCenter Pro DNS-1200-05 Bedienungsanleitung

Avid Technology

Avid Technology VideoRAID ST Sicherheitsleitfaden

Western Digital

Western Digital My Cloud Home Duo Bedienungsanleitung

PrimeArray

PrimeArray 4xxx Bedienungsanleitung

Planex

Planex MZK-NAS01SG Bedienungsanleitung

Intel

Intel SS4000-E - Entry Storage System NAS Server Bedienungsanleitung

Synology

Synology RS2212+ Bedienungsanleitung

Allnet

Allnet ALL69000 Bedienungsanleitung

Adaptec

Adaptec 5325301580 Bedienungsanleitung

Motorola

Motorola EXORdisk II Bedienungsanleitung

Sony

Sony XDAAI1PK Bedienungsanleitung

Cisco

Cisco Linksys NAS200 Original Betriebsanleitung

Sans Digital

Sans Digital MR4UT6G Bedienungsanleitung

AIC

AIC FB128-LX Bedienungsanleitung

Dell

Dell PowerVault NX3500 Gebrauchsanweisung
