1 OPERATING INSTRUCTIONS

The operating instructions contain important information.

▶Read the operating instructions carefully and follow the safety

instructions in particular, and also observe the operating conditions.

▶Operating instructions must be available to each user.

▶The liability and warranty for the device are void if the operating

instructions are not followed.

1.1 Symbols

▶Designates an instruction to prevent risks.

→Designates a procedure which you must carry out.

Warning of injuries:

Danger!

Imminent danger! Serious or fatal injuries.

Warning!

Potential danger! Serious or fatal injuries.

Caution!

Danger! Minor or moderately severe injuries.

Warns of damage to property:

note!

Contents

1 Operating instructions.................................................................. 2

2 Intended use ............................................................................... 3

3 Basic safety instructions .............................................................. 4

4 Technical data ............................................................................. 5

5 Installation ................................................................................... 9

6 Maintenance, troubleshooting ................................................... 11

7 Spare parts ............................................................................... 14

8 Transport, storage, disposal....................................................... 15

english

2.1 Denition of therm “device”

In these operating instructions, the term “device” always refers to

the solenoid valve Type 5404.

2 INTENDED USE

Incorrect use of the solenoid valve Type 5404 can be dangerous

to people, nearby equipment and the environment.

▶The device is designed to control, shut o and meter neutral media

up to a viscosity of 21mm2/s.

▶In areas at risk of explosion, only use devices approved for use in

those areas. These devices are labeled with a separate Ex type label.

For use in areas at risk of explosion, note the information provided

on the separate Ex type label and the separate explosion-related

operating instructions included in the scope of supply.

▶Provided the cable plug is connected and installed correctly, the

device satises protection class IP65 in accordance with DIN EN

60529 / IEC 60529.

▶Use according to the permitted data, operating conditions and

conditions of use specied in the contract documents and operat-

ing instructions.

▶Correct transportation, correct storage and installation and careful

use and maintenance are essential for reliable and problem-free

operation.

▶Use the device only as intended.

english

3 BASIC SAFETY INSTRUCTIONS

These safety instructions do not consider any contingencies or inci-

dents which occur during installation, operation and maintenance.

The operator is responsible for observing the location-specic safety

regulations, also with reference to the personnel.

Danger of high pressure.

▶Before loosening the lines and valves, turn o the pressure and

vent the lines.

Risk of electric shock.

▶Before reaching into the device, switch o the power supply and

secure to prevent reactivation.

▶Observe applicable accident prevention and safety regulations for

electrical equipment.

Risk of burns/Risk of re if used continuously through hot device

surface.

▶Keep the device away from highly ammable substances and media

and do not touch with bare hands.

Risk of injury due to malfunction of valves with alternating

current (AC).

Sticking core causes coil to overheat, resulting in a malfunction.

▶Monitor process to ensure function is in perfect working order.

Risk of short-circuit/escape of media through leaking screw

joints.

▶Ensure seals are seated correctly.

▶Carefully screw valve and connection lines together.

General hazardous situations.

To prevent injury, ensure that:

▶The device may be operated only when in perfect condition and

in consideration of the operating instructions.

▶Do not make any changes and do not subject the device to

mechanical loads.

▶Secure system against unintentional activation.

▶Installation, operation and maintenance may only be performed

by qualied specialists.

english

▶Install the device according to the regulations applicable in the

country.

▶After an interruption in the power supply or pneumatic supply,

ensure that the process is restarted in a dened or controlled

manner.

▶Observe the general rules of technology.

3.1 Warranty

The warranty is only valid if the device is used as intended in accor-

dance with the specied application conditions.

3.2 Information on the Internet

The operating instructions for Type 5404 can be found on the

internet at: www.burkert.com

4 TECHNICAL DATA

4.1 Operating conditions

The following values are indicated on the type label:

•Voltage (Tolerance ±10 %) / Current type

•Coil power consumption (active power in W - at operating

temperature)

•Pressure range

•Body material: Brass (MS), cast iron (GG)

•Seal material: PTFE + FKM (EF), PTFE + EPDM (EA),

PTFE + Graphite (EG), EPDM + Graphite (AG)

Circuit function 2/2-way valve:

A (NC) B (NO)

Protection class: IP65 in accordance with DIN EN 60529 / IEC

60529 with cable plug, e.g. Bürkert Type 2518

english

Special instructions for valves circuit function B (NO) with deaer-

ation connection G1/8 on the coil (CF05):

The deenergized valve is open. The

medium also ows o via the deaeration

connection on the coil.

Valves of this design are therefore

suitable for relieving compressors only.

4.2 Conformity

The device conforms with the EU Directives according to the EU

Declaration of Conformity (if applicable).

4.3 Standards

The applied standards, which verify conformity with the EU Directives,

can be found on the EU-Type Examination Certicate and / or the EU

Declaration of Conformity (if applicable).

4.4 Application conditions

Ambient temperature: max. +55°C

Permitted medium temperature depending on coil material and seal

material:

Coil

material

Type Seal

material

Medium

temperature

Epoxide 5404 NA38 PTFE + FKM -10...+120 °C

Epoxide 5404 NA38 PTFE + EPDM -30...+130 °C

Epoxide 5404 NA07+NA38 PTFE + Graphite -40...+160°C*

Epoxide 5404 NA07+NA38 EPDM + Graphite -30...+135 °C

Polyamide 5404 PTFE + FKM -10...+100 °C

NA38: Coil for higher temperatures

NA07: Steam version

* Observe temperature derating for steam version NA07.

english

100 110 120 130 140 150 160

Medium temperature [°C]

Ambient temperature [°C]

100 % ED 50 % ED max.

cycle time

40min

50 % ED max.

cycle time

10min

Characteristic values intermittent operation:

tSD – Cycle time

tED – Duty cycle

tSP – De-energized pause

ED – Relative duty cycle

SH – Switching frequency

tED

tSP

tSD

tSD [s] = 60

SH 1

min

tED [s] =

tSP [s] = tSD [s] – tED [s]

ED[%]

100

tSD

[s]

english

Observe for values with UL/UR approval:

Medium Seal designation Medium

temperature

Ambient

temperature

Air, inert gas

(PTFE + FKM)

-10...+110 °C -10...+55 °C

Water 0...+100 °C 0...+55 °C

Water

(Fire Protection

Service Valve,

var. Code PE48)

+5...+90 °C +5...+55 °C

Air, inert gas,

(var. code NA07)

(PTFE + Graphit)

-40...+160 °C -40...+45 °C

-40...+150 °C -40...+55 °C

Water ,steam

(var. code NA07)

(PTFE + Graphit)

0...+160 °C 0...+45 °C

0...+150 °C 0...+55 °C

oxygen

(var. code NL02) EF

(PTFE + FKM)

-10...+60 °C -10...+55 °C

No. 2 fuel oil -10...+110 °C -10...+55 °C

Operating duration: Unless otherwise indicated on the type label,

the solenoid system is suitable for continuous

operation. Observe temperature derating for

steam version NA07.

Important information for functional reliability during continuous

operation: If standstill for a long period at least 1-2 activations

per day are recommended.

Service life: High switching frequency and high pressures reduce

the service life

Permitted media depending on seal material:

Seal material Permitted media

PTFE + FKM Neutral media such as compressed air, water,

hydraulic oil, Oxygen1), hot air, hot oils, oils

with additives, Per solutions

PTFE + EPDM Cold and warm water, oil and grease-free

media

PTFE + Graphite Hot water and steam

1) for special design NL02 only

note!

If liquid media is used with high dierential pressures, water

hammer can occur.

english

4.5 Type label

Type

Circuit function

Nominal diameter Seal material

Body material

Order number Manufacture code

Voltage, Frequency, Power

consumption

Connection thread, Operating

pressure

5404 A 12,0 EB MS

Made in Germany

00308502

W12MN

230 V 50 Hz 8W

G1/2 P

N 1

- 50 bar

5 INSTALLATION

Danger!

Risk of injury from high pressure and discharge of medium.

▶Before loosening the lines and valves, turn o the pressure and

vent the lines.

Risk of electric shock.

▶Before reaching into the device, switch o the power supply and

secure to prevent reactivation.

▶Observe applicable accident prevention and safety regulations

for electrical equipment.

Warning!

Risk of injury from improper installation.

▶Installation may be carried out by authorized technicians only

and with the appropriate tools.

▶Secure system from unintentional activation.

▶Following assembly, ensure a controlled restart.

english

5.1 Before installation

Installation position: any, actuator preferably upwards.

→Check pipelines for dirt and clean.

→Install a dirt lter before the valve inlet (≤ 500μm).

5.2 Installation

note!

Caution risk of breakage.

•Do not use the coil as a lever arm.

→Hold the device using a suitable tool on the body and screw into

the pipeline.

Valve body must not be installed under tension.

Sealing material must not get into the device.

→Observe direction of ow:

The arrow on the body indicates the direction of ow.

5.3 Electrical connection of the cable plug

Warning!

Risk of injury due to electrical shock.

▶Before reaching into the system, switch o the power supply

and secure to prevent reactivation.

▶Observe applicable accident prevention and safety regulations

for electrical equipment.

If the protective conductor is not connected, there is a risk of

electric shock.

▶Always connect protective conductor and check electrical conti-

nuity between coil and body.

→Tighten cable plug (authorized cable plug see data sheet),

observing maximal torque 1 Nm.

→Check that seal is tted correctly.

→Connect protective conductor and check electrical continuity

between coil and body.

english

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Burkert Steuereinheit Handbücher

Burkert

Burkert 0290 Bedienungsanleitung

Burkert

Burkert 6213 EV Bedienungsanleitung

Burkert

Burkert 2000 INOX Bedienungsanleitung

Burkert

Burkert 6011 Bedienungsanleitung

Burkert

Burkert 3233 Bedienungsanleitung

Burkert

Burkert 8691 Bedienungsanleitung

Burkert

Burkert 8181 Bedienungsanleitung

Burkert

Burkert 2012 Bedienungsanleitung

Burkert

Burkert 3360 Bedienungsanleitung

Burkert

Burkert 2030 Bedienungsanleitung

Burkert

Burkert 2730 Series Bedienungsanleitung

Burkert

Burkert 2300 Series Bedienungsanleitung

Burkert

Burkert 3320 Bedienungsanleitung

Burkert

Burkert 2030 Bedienungsanleitung

Burkert

Burkert 6106 Bedienungsanleitung

Burkert

Burkert 2100 series Bedienungsanleitung

Burkert

Burkert 2933 Bedienungsanleitung

Burkert

Burkert 8840 Bedienungsanleitung

Burkert

Burkert 2730 Series Bedienungsanleitung

Burkert

Burkert 0406 Bedienungsanleitung

Burkert

Burkert 8647 AirLINE SP Bedienungsanleitung

Burkert

Burkert 2080 Bedienungsanleitung

Burkert

Burkert 3233 Bedienungsanleitung

Burkert

Burkert 0211 Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
