CYP PU-506-KIT Bedienungsanleitung

PU-506-KIT

3-Play HDBaseT™ Extender Kit (2-way IR, RS-232 & HDMI,

up to 100m)

OPERATION MANUAL

DISCLAIMERS

The information in this manual has been carefully checked and is

believed to be accurate. CYP (UK) Ltd assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be

contained in this document. CYP (UK) Ltd also makes no commitment to

update or to keep current the information contained in this document.

CYP (UK) Ltd reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer le, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express

written permission and consent from CYP (UK) Ltd.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts inside

the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if

it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sucient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE SUMMARY OF CHANGE

v1.01 08/10/13 First release

CONTENTS

1. Introduction...........................................6

2. Applications ...........................................6

3. Package Contents ..................................6

4. System Requirements ...........................6

5. Features..................................................7

6. Operation Controls and Functions.......8

6.1 Transmitter Front and Rear Panels....... 8

6.2 Receiver Front and Rear Panels ............ 9

6.3 D-Sub 9-Pin Denitions.........................10

6.4 IR Cable Pin Assignment .......................10

7. Connection Diagram .......................... 11

8. Specications...................................... 12

9. Acronyms............................................. 13

1. INTRODUCTION

The PU-506-KIT allows uncompressed HDMI signals to be transmitted over

a Single CAT5e/6/7 cable. This solution has the added features of RS-232

and 2-way IR control functionality over the same CAT5e/6/7 cable. These

combined HDMI and control signals can be transmitted up to lengths of

100 metres. Utilise the USB power output from a TV as an optional way

of powering the PU-506-RX receiver unit alternative to a mains power

supply.

2. APPLICATIONS

Domestic HDMI installation

University lecturing systems

Retail showroom systems

Conference presentation and control

3. PACKAGE CONTENTS

1×HDMI over Single CAT5e/6/7 Transmitter

1×HDMI over Single CAT5e/6/7 Receiver

2×IR Blaster

2×IR Extender

1×3.5 mm Mini-jack to RS-232 Female Cable

1×3.5 mm Mini-jack to RS-232 Male Cable

2×5V/2.6 A DC Power Adaptor

Operation Manual

4. SYSTEM REQUIREMENTS

HDMI source equipment such as a DVD or Blu-ray player and HDMI

equipped display (TV or monitor). HDMI and CAT5e/5/7 connection

cables.

5. FEATURES

Supports all v1.4 HDMI resolutions plus 4k.

Supports uncompressed video/audio up to 10.2Gbps

Common supported resolutions: HDTV: 480p, 576p, 720p, 1080i,

1080p, 1080p24; PC: VGA, SVGA, XGA, WXGA, SXGA, UXGA, WUXGA.

HDMI, HDCP & DVI compliant

Supports HDCP repeating and CEC functions

Uncompressed data transfer over single CAT cable (100m - CAT6/7;

80m - CAT5e)

Audio support up to 7.1CH & Dolby TrueHD, DTS-HD

3-Play™ convergence

Compact design

Supports 3D signals

Choose to power the PU-506-RX via the USB output from a TV (Cable

available separately - APC-USB) : * Please note the performance and

consistency of USB power outputs from TV's can vary and cannot be

guaranteed by CYP.

Note: This system was tested with CAT6/23AWG cable. Results may vary

with cables of dierent specications.

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Transmitter Front and Rear Panels

Power

Link

CAT 5e /6 Out

DC 5V

IR2 Extender

RS232 In IR1 Blaster

HDMI In

RearFront

231 5

RS232 In: Connect to a PC/laptop or RS-232 enabled device (with

supplied 3.5 mm mini-jack to D-sub 9-pin adaptor) for the transmission

of RS-232 commands.

IR2 Extender: Connect to the supplied IR extender cable for IR signal

reception. Ensure that remote control being used is within the direct

line-of-sight of the IR extender.

IR1 Blaster: Connect to the supplied IR blaster cable for IR signal

transmission. Place the IR blaster in direct line-of-sight of the

equipment to be controlled.

HDMI In: Connect to the HDMI source equipment such as a DVD or

Blu-ray player.

DC 5V: Connect the 5V DC power supply to the unit and plug the

adaptor into an AC outlet.

Link LED: The yellow LED will illuminate when both the input and

output CAT5e/6/7 signals are connected.

Power LED: This green LED will illuminate when the device is

connected to a power supply.

CAT5e/6 Out: Connect to the receiver unit with a single CAT5e/6/7

cable for transmission of all data signals.

6.2 Receiver Front and Rear Panels

Power

Link

CAT 5e /6 In

DC 5V IR1 Extender

RS232 Out IR2 Blaster

HDMI Out

RearFront

675

DC 5V: Plug the 5V DC power supply into the unit and connect the

adaptor to an AC outlet.

Power LED: This green LED will illuminate when the device is

connected to a power supply.

Link LED: The yellow LED will illuminate when both the input and

output CAT5e/6/7 signals are connected.

CAT5e/6 In: Connect to the transmitter unit with a Single CAT5e/6/7

cable for transmission of all data signals.

RS232 Out: Connect to the device that is to be controlled (with

the supplied 3.5mm mini-jack to D-sub 9-pin adaptor) by RS-232

commands.

IR1 Extender: Connect to the supplied IR extender cable for IR signal

reception. Ensure that the remote being used is within the direct line-

of-sight of the IR extender

IR2 Blaster: Connect to the supplied IR blaster cable for IR signal

transmission. Place the IR blaster in direct line of sight of the

equipment to be controlled.

HDMI Out: Connect to a HDMI equipped TV/monitor for display of the

HDMI input source signal.

6.3 D-Sub 9-Pin Denitions

PIN DEFINE TX/RX

1N/C

2TxD/RxD

3RxD/TxD

4N/C

5GND

6N/C

7N/C

8N/C

9N/C

6.4 IR Cable Pin Assignment

Power 5V

IR Blaster Signal

IR Signal

Power 5V

Grounding

IR Extender

IR Blaster
