CYP PU-442PL-KIT Bedienungsanleitung

PU-442PL-KIT

4 x 4 HDBaseT™ Lite Matrix with PoE, plus 2 Additional

Independent HDMI Zone Outputs (total 4 x 6 Matrix)

OPERATION MANUAL

DISCLAIMERS

The information in this manual has been carefully checked and is

believed to be accurate. CYP (UK) Ltd assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be

contained in this document. CYP (UK) Ltd also makes no commitment to

update or to keep current the information contained in this document.

CYP (UK) Ltd reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer le, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express

written permission and consent from CYP (UK) Ltd.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts inside

the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if

it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sucient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE SUMMARY OF CHANGE

v1.00 16/12/2013 First release

v1.01 17/12/2013 Corrected description/features

v1.02 13/01/2014 Added new image/description

CONTENTS

1. Introduction...........................................6

2. Applications ...........................................6

3. Package Contents ..................................6

4. System Requirements ...........................6

5. Features..................................................7

6. Operation Controls and Functions .......8

6.1 Front Panel................................................... 8

6.2 Rear Panel..................................................... 9

6.3 Side Panel...................................................10

6.4 Remote Control........................................10

6.5 IR Pin Assignment....................................11

6.6 RS-232 Protocols......................................11

6.7 RS-232 & Telnet Commands.................12

6.8 Telnet Control............................................14

6.9 Web GUI Control ......................................16

7. Connection Diagram .......................... 18

8. Specications...................................... 19

9. Acronyms............................................. 20

1. INTRODUCTION

This 4 by 6 HDBaseT™ Lite Matrix utilises four HDMI inputs and four

HDBaseT outputs over a single CAT5e/6/7 cable (up to 60m) for

each output, plus two additional HDMI outputs. All six outputs are

independent allowing any source to be distributed to any output. The

HDBaseT outputs feature Power over Ethernet (PoE) functionality and

allow the user to power the supplied PU-515PL-RX receivers without the

need for a separate mains power supply.

The PU-442PL-KIT supports the transmission of video (resolutions up to

1080p Full HD and 1920x1200@60Hz), PoE, 2-way IR, multi-channel digital

audio, and control via IR, RS-232, or Web GUI/Telnet IP. Use the IP control

feature to enable users to access and control the matrix remotely and also

allow additional options for integration of third-party control systems.

2. APPLICATIONS

HDMI system controls

Video/TV wall display and control

Security surveillance and control

Commercial advertising, displaying and control

Lecture room display and control

3. PACKAGE CONTENTS

4 by 6 HDMI HDBaseT Lite Matrix

4×PU-515PL-RX receivers

5×IR Receiver

5×IR Emitter

1×24V/3.75A DC Power Supply

1×Remote Control

1×Operation Manual

4. SYSTEM REQUIREMENTS

Input source equipment with HDMI connection cables

Certied CAT5e/6/7 cables

Output displays or audio receiver equipment with HDMI connection

cables

5. FEATURES

Supports all v1.3 HDMI resolutions

Supports uncompressed video/audio up to 10.2Gbps

Common supported resolutions: HDTV: 480p, 576p, 720p, 1080i,

1080p, 1080p24; PC: VGA, SVGA, XGA, WXGA, SXGA, UXGA, WUXGA.

HDMI, HDCP and DVI complaint

High Denition Audio supported: Dolby TrueHD, Dolby Digital Plus

and DTS-HD Master Audio plus LPCM (up to 192kHz)

Uncompressed data transfer over single CAT cable (60m - CAT5e/6/7)

Supports HDMI input up to 15m 1080p 8bit or 10m 1080p 12bit.

Supports RS-232, 2-Way IR, Manual Selection Buttons, and HDMI CEC

control pass through

Selectable EDID settings - TV (downstream) and STD (xed)

Compact 1U Rack mount design

Supports 3D signals

Supports additional IR Control via a master (ALL) Input/Output

Supports full IP control

Supplied with 4x PU-515PL-RX receivers

6. OPERATION CONTROLS AND FUNCTIONS

The following sections describe the hardware components of the unit.

6.1 Front Panel

POWER LOCK MENU

OUT

A1C3

D4IN

1 2 3 4 5 6

1LCM: This monitor displays your setting information with each input

and output selection.

2IR: This IR window accepts the remote control signal of this device

only.

3Power Button & LED: Press this button to turn ON the device and

the green LED will illuminate when the power is ON. When the LED

illuminate in red it is in standby mode.

4LOCK: Press this button to lock all the buttons on the panel and the

LED will illuminate. To unlock, just press it again.

5Menu: Press this button once to select EDID setting from STD(internal)

1 or TV(external) 2 then press it again to conrm the selection. Press

this button every time to conrm the selection.

61~4/A~F & OUT/IN button: Press OUT/IN button rst to select the

output/input then press the number button to make the selection

accordingly. For example, output A~B wish to select input 1 and C~E

wish to select input 2. Press OUT→A→IN→1→Menu, and then press

Out→C→D→E→In→2→Menu. If the menu button is not pressed the

selection will not be changed.

6.2 Rear Panel

SERVICE

RS-232

CONTROL

B CA E FD

DC 24V

GND

GND GND

IR OUT

IR IN

ALL

V+

IR IN IR OUT

HDMI IN 1 HDMI IN 2 HDMI IN 3 HDMI IN 4

HDMI OUT CAT5e/6/7 OUT CAT5e/6/7 OUT

2 3 4 45 5 5 10 115 6

8 9

1RS-232: This slot is to connect with D-Sub 9pin cable from the PC/

Laptop device for RS232 control.

Note: This RS-232 obtain routable function that is, from the Matrix it can

send commands to all receivers or from receiver sides it can also send

commands to control the Matrix. In order to allow the receivers to send

command to control the Matrix, a null modern cable/adaptor is required.

In order to allow the receivers to send command to control the Matrix, a

null modern cable/adaptor is required.

2CONTROL: This port is for Telnet and Web GUI control. Connect and

active network system with RJ45 terminated cable (for details, please

refers to section RS-232 & Telnet commands and Web GUI Control).

Warning: Please do not connect this port directly to the PC/Laptop as the

Telnet function will not work.

3Service: This slot is to connect with mini USB B type cable for rmware

update only.

4HDMI OUT A/E: These slots are to connect with HD TV/display for

instant display.

5CAT5e/6/7 OUT B/C/D/F: These slots are to connect with HDMI over

CAT5e/6/7 Receiver for signal extension up to 60m.

6HDMI IN 1~4: These slots are to connect to input source equipment

such as DVD player or Set-Top-Box with HDMI cable or DVI to HDMI

converter cable for input signal sending.

7IR IN 1~4: These slots are to connect with IR Receiver included in the

package for IR signal receiving.

8IR OUT 1~4: These slots are to connect with IR Emitter included in the

package for IR signal sending.

9ALL IR OUT: This slot is to connect with the IR Emitter for IR signal

received from receiver sides and send to the source side.

10 ALL IR IN: This slot is to connect with the IR receiver for IR signal

receiving and send out to receiver sides.

11 DC24V: This slot is to plug the power cord with adaptor included in

the package and then connect them with AC wall outlet for power

supply.

6.3 Side Panel

1Ventilator: These are fan ventilation areas, DO NOT block or cover

with any object.

6.4 Remote Control

1Power: Press this button to

switch ON the device or set it to

standby mode.

2IN: Input ports selection 1~4.

3OUT: Output ports selection A~F.

CR-110

IN OUT
