Daewoo RC-450 Bedienungsanleitung

,,,,,







VACUUM CLEANER

RC-45O

READ AND KEEP THIS

■ Thank you for purchasing this vacuum cleaner

■ For proper operation, please read this manual before using

OWNER'S MANUAL

RC-450(¿ -ALGHANIM) 99.9.23 8:44 PM ˘`1

DESCRIPTION AND USING

A DUST METER

B HOSE HANDLE

C CORD REWIND

BUTTON

D POWER CORD

E CLEANING TOOLS

F HOSE ADAPTOR

G STORAGE

• How to check the DUST METER

Operate the cleaner with MAX power and keep the suction

brush apart from the floor

• If the red indicator of the DUST METER appears.

➪ Change the paper filter bag.

➪ In case the hose is blocked with a large object, remove it.

• When cleaning with the crevice tool or the dusting brush, the

red indicator may appear, in this case, continue cleaning.

• POWER CONTROL

• Connect to the same voltage as shown on the rating label.

• To plug or unplug, grasp the plug body. Do not hold or pull

the cord.

• Crcvice tool

• Dusting tool

• Sweeping/Upholstely Brush

• When separating the hose from the body, pull the hose

adapter and pressing the button.

• Loop the hose behind the handle. (See diagram on page 5).

RC-450(¿ -ALGHANIM) 99.9.23 8:44 PM ˘`2

2.DESCRIPTION

C D

MAX

HIGH

POWER

CONTROL

MID

MIN

STOP

PIPE HOLDER

SUCTION

BRUSH

HOSE

DUST

COVER

HANDLE

BUTTON

GROOVE

CREVICE

TOOL

DUSTING BRUSH

ROTATE

UPHOLSTERY

NOZZIE

RC-450(¿ -ALGHANIM) 99.9.23 8:44 PM ˘`3

HOSE

This vacuum cleaner should only be used for household vacuuming of dry paeticles only.

The manufacturer cannot be held responsible for any damage caused by use or operation of the

cleaner contrary to these instructions.

If the cleaner is wrongly operated for a purpose other than that for which it is intended, no liability can

be accepted for any possible damage.

PRECAUTIONS FOR SAFE USE

RED MARK

• Do not vacuum areas which contain moisture

or water and inflammable matter, needles,

pins,razor blades, matches, cigarette-ends,

ect.. since they may damage the cleaner or

filter bag or make fire.

• When rewinding the power cord, hold the plug

body before pressing the cord rewind button

to prevent whipping.

• Do not pull the power cord out beyond the

specified length.

• Make sure a filter bag and a motor protection

filter are always inserted. • This product provided with a cable which, if

damaged, must be replaced by a repair shop

authorized by the manutacturer.

• This hose contains electrical connections.

– Do not use to suck up water.

– Do not immerse in water for cleaning.

– The hose should be checked regularly and

must not be used if damaged.

RC-450(¿ -ALGHANIM) 99.9.23 8:44 PM ˘`4

REPLACING THE FILTER BAG

DUST COVER

FILTER BAG

GUIDE

• Open the dust cover and take out the filter bag

• Insert the new filter bag along the guides.

• The dust cover cannot be closed completely if the dust bag is inserted incorrectly.

CLEANING THE MOTOR PROTECTION FILTER

MOTOR

PROTECTION

FILTER

• Open the dust cover and take out the motor protection filter.

• Clean the filter.

• Insert the filter as it was.

RC-450(¿ -ALGHANIM) 99.9.23 8:44 PM ˘`5

BEFORE ASKING FOR SERVICE

PROBLEM CHECK POINT ACTION

• Suction power is weak • Filter bag

• Hose

• If it is full with dust,change it.

• If clogged or blocked,

remove the object.

• The cleaner dose not work • Could you please weck if the

hose is inserted correctly

into the main body?

• When the filter bag is full or

blocked of any of the

accessones are blocked,

the over-heating protection

for the motor is activated

auto-matically

• Insert it completely

• Swtch off and unplug the

cleaner and check the dust

bag and accessories and

remove any blockages. The

cleaner can be switched on

again after about 30

minutes.

• Power cord does not rewind.

• Power cord is not pulled out

of the cleaner

• Power cord

• Pull the power cord out a

little and press the cord

rewind button.

• Do not pull it by force.

Rewind it a little by pressing

the cord rewind button and

pull it out.

Please check each item below if you have trouble with your cleaner. Before checking, ensure that the

cleaner is unplugged from the power supply.

RC-450(¿ -ALGHANIM) 99.9.23 8:44 PM ˘`6

SPECIFICATIONS

Model RC-450

Rating 220V~240/50Hz

Watts MAX 1500W

Weights(Body) 5.2kg

Dimension(L x H x D) 376 x 231 x 286mm

Cord Length 6m

RC-450(¿ -ALGHANIM) 99.9.23 8:44 PM ˘`7
