Tornado Pet 700W Bagged Vacuum

FLR00047

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Tornado Pet 700W Bagged Vacuum

FLR00047

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be

followed. These instructions should be saved for future reference:

•Read and familiarise yourself with all operating instructions before using this

Vacuum Cleaner.

•Before plugging your unit into the mains, visually check that the unit is intact

and has not suffered any transit damage.

•Check that the voltage indicated on the data plate corresponds with that of the

local network before connecting the appliance to the mains power supply.

•This appliance can be used by persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have been given

supervision or instruction concerning use of the appliance in a safe way and

understand the hazards involved.

•Children shall not play with the appliance.

•Keep the appliance and its cord out of reach of children less than 8 years when it

is energised or cooling down.

•Do not immerse the appliance or its cord in water or any otherliquids.

•Do not leave the appliance unattended during use.

•Do not leave the appliance unattended whilst connected to the mains supply.

•Do not use this appliance outdoors.

•It is imperative to unplug the power cord after the appliance has been used,

before it is cleaned and whilst being repaired.

•Repairs to electrical appliances should only be performed by a qualified

electrician. Improper repairs may place user at serious risk.

•Do not operate this appliance with a damaged plug or cord, after a malfunction

or after being dropped or damaged in any way.

•Regular, periodic checks should be carried out on the mains cable to

•ensure no damage is evident. Should there be any signs of damage the

appliance should not be used.

•If the power cable is damaged, it should only be replaced by the manufacturer

or a suitable qualified after-sales-service in order to avoid a hazard

•Do not allow the mains cable to hang over sharp edges or come in contact with

hot surfaces.

•Allow the unit to cool before storage.

•Before cleaning, disconnect the appliance from the mains supply and allow to

cool.

•This appliance is intended for household use only and should not be used for

industrial purposes.

•Do not use any accessories or attachments with this appliance other than those

supplied or recommended by supplier.

•Do not use this appliance for anything other than its intended use.

•Do not push objects into any openings as damage to the appliance and/or

electric shock may occur.

•Unplug after each use. Grasp the plug, not the cord.

Tornado Pet 700W Bagged Vacuum

FLR00047

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

•Do not pull or carry the Vacuum Cleaner by the electrical cord, use the handle

provided.

•Ensure fingers and other objects are never placed in any part of the vacuum

cleaner. Clothing or hair may become trapped if thevacuum is used

improperly.

•Keep hair, loose clothing, jewellery, fingers and all parts of the body away

from openings and moving parts.

•Keep all air vents clear and free of dust, lint, hair and anything else that may

reduce airflow.

•Avoid directing the appliance towards naked flames as the air discharged may

extinguish gas fires or pilot lights and may disturb ashes in open fires.

•Do not Vacuum water or any other liquids with this vacuum.

•Do not Vacuum hot ashes or lit cigarettes, etc.

Description of Parts –Vacuum Cleaner

Description of Parts –Accessories

1. Dust Compartment Release Catch

2. Foot operated On/Off Switch

3. Rear air outlet & filter

4. Power/speed controller

5. Mains cable & plug

6. Cable retract button (press to retract cable)

7. Wheel(s)

8. Dust Bag Full Indicator

9. Dust compartment

10.Air intake/hose connection

11.Handle

12.Floor Tool

13.Crevice & Upholstery multi tool

14.Flexible hose

15.Hose connector

16.Air control valve

17.Hose tool connector

18.Telescopic Tube

19.Pet Brush

Tornado Pet 700W Bagged Vacuum

FLR00047

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Assembling Your Vacuum Cleaner

CAUTION Ensure that the vacuum cleaner is not connected to the mains supply before using

the attachments.

Attaching the Flexible Hose (14) to the vacuum

Attach the Flexible Hose (14) to the vacuum cleaner by pushing the Hose Connector (15)

into the Air Intake (10) until it clicks home, arrowed below:

NB to remove the hose, press the catches on either side (arrowed below) of the Hose

Connector (15) and pull out of the Air Intake (10):

Attaching the Telescopic Tube (18) and Floor Tool (12)

1. Push the Telescopic Tube (18) onto the Hose tool connector (17) as shown below left:

2. Extend the Telescopic Tube (18) to the desired length by

pushing the catch down and extending.

3. Attach the Floor Tool (12) to the other end as shown above

4. Hose tool connector (17), Telescopic Tube (18) and Floor Tool

(12) shown complete:

Telescopic Tube

Hose Tool Connector

Telescopic Tube

Floor Tool

Left: Removing the flexible

hose from the vacuum

Right: Attaching the flexible

hose to the vacuum

Tornado Pet 700W Bagged Vacuum

FLR00047

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Using Your Vacuum Cleaner

1. Pull the Mains Cable and Plug (5) fully out of the vacuum cleaner, do not use the

vacuum without pulling the cable all the way out.

2. Insert the mains plug into the nearest socket.

3. Press the On/off Switch (2) to power up the vacuum.

NB Adjust the lever on the Floor Tool (12) according to the type of floor being cleaned. Push

the lever down for use on hard floors (i.e. non carpeted, laminated, tiled, etc.), pull the

lever up for vacuum cleaning carpets:

Using the Crevice & Upholstery multi tool (13)

Attach the Crevice & Upholstery multi tool (13) onto the Telescopic Tube (18) to

clean carpet edges, upholstered furniture and hard to get at areas:

NB If the Telescopic Tube (18) is not required, the Crevice & Upholstery multi tool (13) or

the Floor tool (12) can attached directly to the Hose tool connector (17) on the end of the

flexible hose, this useful whilst cleaning soft furnishings, stairs, etc. as below:

Left: Adjust the lever on the

Floor Tool for carpeted or

hard floors:

Up for carpets

Down for hard floors

Left: Attached the Crevice &

Upholstery multi tool to

clean carpet edges

Right: Fold the brush down

to clean hard to get at areas

and upholstery.

Left: Attached the Crevice &

Upholstery multi tool to the

Hose. Use the brush to clean

upholstery.

Right: Attached the Floor

tool to the Hose to clean the

stairs.

Tornado Pet 700W Bagged Vacuum

FLR00047

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

1. Once the Dust Bag Full Indicator (8) turns

red as shown left, the dust bag will need

replacing and the filters cleaned.

2. To remove the bag, lift the Dust

Compartment Release Catch (1).

3. lift the dust compartment cover to reveal

the dust bag holder.

4. Lift out the dust bag holder and dust bag

as shown below:

Using the Hose and Pet Brush (19)

For difficult to remove soiling on upholstery such as pet hairs, the

pet brush can be used.

This should be fitted onto the hose as shown above.

The fixed combs and rotating pneumatic brush clean up the

stubborn or matted hairs.

Using the Power/Speed Controller (4)

This control is useful for varying the suction power. Rotate the control anticlockwise to

reduce power whilst cleaning hard floors or similar and rotate clockwise to increase suction

power for carpets, rugs, etc.

NB vacuum power can also be varied using the Air Control Valve (16) on flexible hose.

Emptying and Cleaning Your Vacuum Cleaner

WARNING Always disconnect the cleaner from the mains power supply before cleaning.

WARNING do not continue to use your

vacuum cleaner once the Dust Bag Full

Indicator (8) turns red as permanent

damage may occur to the appliance.

Tornado Pet 700W Bagged Vacuum

FLR00047

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

5. Push the bag retaining clip forwards as

shown right (a.).

Slide the card front of the bag out of the

dust bag holder (b.) and dispose of the used

dust bag. Slide the card front of the new

dust bag into the dust bag holder ensuring

the retaining clip locks the card into place.

6. Whilst replacing the dust bag, slide out

the dust compartment filter as shown a. &

b. right. Wash the filter in warm running

water until clean. Allow the filter to dry

thoroughly for 24 hours before replacing

and reuse:

Tornado Pet 700W Bagged Vacuum

FLR00047

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Care and Use of your Vacuum Cleaner

WARNING Always disconnect the cleaner from the mains power supply before cleaning.

•Clean outside of the cleaner with a clean damp cloth. Never clean with harsh or abrasive

cleaners.

•Do not submerge the cleaner in water or any other liquids.

•Empty the dust bag as soon as the dust bag full indicator (8) turns red.*

•Wash the dust compartment and rear air outlet filters regularly –see table below.

•Allow all the filters to thoroughly dry out for 24 hours before reassembly and use.

*WARNING do not continue to use your vacuum cleaner once the dust bag full indicator (8)

turns red as permanent damage may occur to the appliance.

Recommended cleaning times

Filter Type

Recommended cleaning period

WARNING Ensure the filters are cleaned periodically according to the table above, failure to

clean the filters regularly will severely impair the performance and permanent damage may

occur to the appliance.

7. Finally, push the latch down on the rear air outlet & filter (3)

cover as shown in a, b, & c below. Remove the filter and wash

clean in warm running water ensuring it is thoroughly dry for

24 hours before replacing and reuse:

•Shake

out

debris

once

month

•

Rinse

under

war

water

once

every

3-6

months

•Allow to dry thoroughly for 24 hours before reuse.

Dust Compartment Filter

Rear Outlet Filter

•Shake

out

debris

once

month

•

Rinse

under

war

water

once

every

3-6

months

•Allow to dry thoroughly for 24 hours before reuse.

Tornado Pet 700W Bagged Vacuum

FLR00047

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Fitting a new plug

The mains lead must be connected as shown below. The wires are coloured with the

following code - Brown wire = Live (L), Blue wire = Neutral (N).

NB no connection must be made to the Earth (E) terminal.

•The Blue wire must be connected to the terminal marked N or coloured Black.

•The Brown wire must be connected to the terminal marked L or coloured Red.

•Check that there are no cut or stray strands of wire inside the plug.

•Use a 13 Amp BS 1362 fuse, only use BSI or ASTA approved fuses.

•If you are in any way unsure which plug or fuse to use, always refer to a qualified

electrician.

•After replacing or changing a fuse on a moulded plug, the cover must be refitted to the

plug; the appliance must not be used without a fuse cover.

Technical Specification

Model Number

FLR00047

Supply Voltage

AC 220-240V ~ 50/60Hz

Rated Power

700W

Protection Class

Unpacked Weight (approx.)

3.9 Kgs

Unpacked Weight with Accessories

4.8 Kgs

Dimensions (approx.)

246mm (h) x 286mm (w) x 430mm (d)

Vacuum

≥16kpa

Dust Compartment Capacity

3.0L

Connect

Brown to

Live (L)

Connect

Blue to

Neutral (N)

Ensure the outer sheath of the mains lead

is securely held by the cable clamp

Tornado Pet 700W Bagged Vacuum

FLR00047

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Troubleshooting Guide

Problem

Possible Cause

Solution

Unit fails to turn on.

The unit may not be

properly plugged in.

The fuse may have

tripped.

Ensure the plug is fully

inserted into the socket and

the socket is switched on.

Check the fuse on the mains

board, if it has tripped, reset

it.

Low suction or poor pick-up.

Dust Bag is full.

Filters are clogged.

Blockage in the hose.

Replace Dust Bag. Check and

clean the filters.

Check the hose and clear if

necessary.

The vacuum is making a “hissing”

sound.

The airflow is

restricted

Replace Dust Bag. Check and

clean the filters.

Check the hose and clear any

blockages if necessary.

Waste electrical products should not be disposed of with household waste. Please

recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.

Andere Handbücher für TORNADO PET

Inhaltsverzeichnis

Andere Daewoo Staubsauger Handbücher

Daewoo

Daewoo TORNADO FREEDOM PRO Bedienungsanleitung

Daewoo

Daewoo RC-230 Bedienungsanleitung

Daewoo

Daewoo RC900M0001 Bedienungsanleitung

Daewoo

Daewoo RC-6003F Bedienungsanleitung

Daewoo

Daewoo DAAVC800-15L Bedienungsanleitung

Daewoo

Daewoo RC-350BKN Bedienungsanleitung

Daewoo

Daewoo RC-4008S Bedienungsanleitung

Daewoo

Daewoo RC-7005S Bedienungsanleitung

Daewoo

Daewoo RC-1700P Bedienungsanleitung

Daewoo

Daewoo Cyclone Freedom FLR00010 Bedienungsanleitung

Daewoo

Daewoo RC-700M Bedienungsanleitung

Daewoo

Daewoo RC-400B Bedienungsanleitung

Daewoo

Daewoo DAVC 90-30L Bedienungsanleitung

Daewoo

Daewoo RC-2200 Bedienungsanleitung

Daewoo

Daewoo RCC-11GR EU Bedienungsanleitung

Daewoo

Daewoo Cyclone Freedom Pro Bedienungsanleitung

Daewoo

Daewoo RC-800 Bedienungsanleitung

Daewoo

Daewoo TORNADO PET Bedienungsanleitung

Daewoo

Daewoo RC-550 Bedienungsanleitung

Daewoo

Daewoo RC-701M Bedienungsanleitung

Daewoo

Daewoo Cyclone Lyte Bedienungsanleitung

Daewoo

Daewoo CYCLONE DIGI ONE Bedienungsanleitung

Daewoo

Daewoo Cyclone Digi-Flex Bedienungsanleitung

Daewoo

Daewoo RCC-153 Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
