Daewoo RC-7005S Bedienungsanleitung

;;;;;;

VACUUM CLEANER

RC-7005S

READ AND KEEP THIS

• Thank you for purchasing this vacuum cleaner.

• For proper operation, please read this manual before using.

OWNER’S MANUAL

DESCRIPTION AND OPERATION

1. POWER CORD

2. POWER ON/OFF BUTTON

3. POWER CORD REWIND BUTTON

4. ACCESSORIES

5. DUSTMETER

6. ADAPTER HOSE

7. HOSE HANDLE

8. SUCTION CONTROL

9. EXTENTION PIPE

10. DUST BAG

11. HANDLE

12. BRUSH

1111

1122

1100

Lift the lid of the bag compartment and check

that the dust bag is in place.

Snap the hose into the vacuum cleaner is

shown in the picture.

When removing the hose. press the catch at

the coupling and withdraw.

Extend the cord and connect to the outlet.

The vacuum cleaner is equipped with an

automatic cord reel. The cord is rewound by

pressing the foot pedal.( )

The vacuum cleaner is switched on and off

using the foot pedal on the top of the vacuum

cleaner.

The bag-full indicator(dust meter) on the

machine indicates that the dust bag is

blocked and the machine has therefore lost

so much suction effect that it risks

overheating on continued use.

The bag should therefore be changed even if

it is not full.

Never vacuum liquid, broken glass or other

sharp objects.

Do not vacuum ash or inflammable liquids or

gases.

Make sure that the exhaust vent of the

vacuum cleaner is not blocked or

obstructed during e.g. cleaning of stairs or

small areas.

;;

The safety filter in the bag compartment

should be changed when necessary

Open the cover and lift up the filter

• Rinse the dirty side(the inside) of the filter

under tap water as shown.

• Allow the filter to air dry.

When changing filter(should be done at about

every 5th dust bag), open the filter cover.

• HEPA filter (RC-7005S)

Take out the old filter unit. It can be thrown

away with everyday rubbish.

Put in a new original filter unit and replace the

filter cover.

Tube and nozzle can be attached in a

horizontal “parking” position.

When storing the vacuum cleaner, it is to be

switched off. The cable needs to be

disconnected from the outlet.

The vacuum cleaner is to be stored in a dry

place at room temperature. The hose and

tube can be attached as shown in the picture.

Lift the full bag straight up.

The dust bag can be thrown away with everyday

rubbish.

The bag compartment can be cleaned with a

soft cloth.

Put the new dust bag by slotting the cardboard

disc into the holder.

The lid cannot be closed over the unfitted bag.

IMPORTANT SAFEGUARDS

Read All Instructions Carefully Before Using.

WARNING -To reduce the risk of fire, electric shock, or injury

11. Do not leave appliance when plugged in, Unplug from outlet when not in use and before

servicing.

12. Do not use outdoors or on wet surfaces.

13. Do not allow to be used as a toy. Close attention is necessary when used by or near

children.

14. Use only as described in this manual. Use only manufacturer’s recommended

attachments.

15. Do not use with damaged cord or plug. If appliance is not working as it should, has been

dropped, damaged, left outdoors, or dropped into water, return it to a service center.

16. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord

around sharp edges or corners. Do not run appliance over cord. Keep cord away from

heated surfaces.

17. Hold plug when rewinding onto cord reel. Do not allow plug to whip when rewinding.

18. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

19. Do not handle plug or appliance with wet hands.

10. Do not put any object into openings. Do not use with any opening blocked; keep free of

dust, lint, hair, and anything that may reduce air flow.

11. Keep hair, loose clothing, fingers, and all parts of body away from openings and moving

parts.

12. Do not pick anything that is burning or smoking, such as cigarettes, or hot ashes.

13. Do not use without dustbag and/or filters in place.

14. Turn off all controls before unplugging.

15. Use extra care when cleaning on stairs.

16. Do not use to pick up flammable or combustible liquids such as gasoline or use in areas

where they may be present.

17. Unplug before connecting power brush.

18. This appliance is intended for household use only and not for commercial or industrial

use.

SAVE THESE INSTRUCTIONS

BEFORE ASKING FOR SERVICE

PROBLEM

• Suction power is weak.

• The cleaner does not work.

• Power cord does not rewind.

• Power cord is not pulled out

of the cleaner.

CHECK POINT

• Filter bag

• Hose

• Is the hose adapter inserted

into the suction opening of

the cleaner completely?

• Power cord

MEASURE

• If it is filled with dust,

change it.

• If clogged or blocked,

remove the object.

• Insert it completely.

• Pull the power cord out a

little and press the cord

rewind button.

• Do not pull it by force

Rewind it a little by

pressing the cord rewind

button and pull it out.

Please check each item below if you have trouble with your cleaner.

Before checking, ensure the cleaner is unplugged from the power supply.

SPECIFICATIONS

Model RC-7005S

Rating 230V~/50Hz

Watts MAX. 1500W

Noise level 70 dB

Weights(Net) 5.2 kg

Dimension (L X H X D) 354 X 240 X 262mm

Cord Length 6 m
