Dirt Devil REBEL 4.0 Bedienungsanleitung

LET’S GO.

DACBLV21E2

REBEL 4.0

BAGLESS VACUUM

CLEANER

1 YEAR WARRANTY

USER GUIDE

Let’s talk safety

Basic

safety

precautions

Don’ts

Do’s

This vacuum cleaner is intended for household use only and

NOT for commercial or industrial use.

READ ALL THE INSTRUCTIONS BEFORE USING

THIS APPLIANCE

• Only use the vacuum cleaner indoors and keep the area you’re

cleaning well lit.

• Keep fingers, hair and loose clothing from moving parts and

openings whilst using the vacuum cleaner.

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities

or lack of experience and knowledge unless they have

been given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

• Do not pull or carry by cord, use cord as a handle, close a door

on cord, or pull cord around sharp edges or corners. Do not

place product on cord. Do not run appliance on cord.

• Don’t handle the plug or use the vacuum cleaner with wet hands.

• Don’t use the vacuum cleaner with incorrect voltage as this may

result in damage or injury to the user. The correct voltage is

listed on the rating label.

• Don’t vacuum up hot coals, cigarette butts, ash, matches or

smoking hot burning items or use in an area where there may be

harmful fluids (chlorine, bleach, and ammonia drain cleaner).

• Always make sure the filter and dust container are fitted

correctly before using your vacuum cleaner.

• Turn off all controls on the vacuum cleaner before

disconnecting or connecting the battery.

• Take extra care when cleaning on the stairs.

• Always switch off the vacuum cleaner before disconnecting

or connecting the hose and accessories.

• Always protect the cord from heated surfaces or near open

flames.

Children should not play with the vacuum cleaner. Cleaning and user

maintenance should not be made by children without supervision

• Only Dirt Devil recommended tools and accessories should be used with

this vacuum cleaner

• Dirt Devil recommends the use of a Residual Current Device rating of 30 mA

or less.

• If the supply cord is damaged, it must be replaced by the manufacturer,

or similarly qualified person in order to avoid a hazard, or invalidating

the warranty.

• IMPORTANT: The motor is equipped with a thermal cut-out. If for any

reason the unit should overheat, the thermostat will automatically turn the

unit off. Should this occur, unplug the vacuum cleaner from the electrical

outlet and turn off the switch. Remove dust container and empty. Clean

filters. Allow the unit to cool for approximately one (1) hour.

• Do not pull or carry by cord, use cord as a handle, close a door

on cord, or pull cord around sharp edges or corners. Do not

place product on cord. Do not run appliance on cord.

• Don’t handle the plug or use the vacuum cleaner with wet hands.

• Don’t use the vacuum cleaner with incorrect voltage as this may

result in damage or injury to the user. The correct voltage is

listed on the rating label.

• Don’t vacuum up hot coals, cigarette butts, ash, matches or

smoking hot burning items or use in an area where there may be

harmful fluids (chlorine, bleach, and ammonia drain cleaner).

• Don’t attempt to remove blockages with sharp objects as this may cause

damage to the vacuum cleaner.

• Do not vacuum hard or sharp objects such as glass, nails, screws or coins etc.

• Don’t not vacuum plaster dust, concrete dust or any other building

or vitreous material.

• Do not vacuum flour, baking soda or any other powder-based carpet

refresher or deodoriser.

• Don’t use this vacuum cleaner if it has been dropped, damaged or left outdoors.

• Don’t vacuum up any flammable or combustible materials (lighter fluid, petrol,

kerosene etc.) or use the vacuum cleaner in an area with explosive vapours

or liquid.

• Use only Australian Certified approved 10amp extension cords. Care should

be taken to arrange the extension cord as it can be a trip hazard.

• Always carry the vacuum cleaner by the handle.

• Store your vacuum cleaner in a cool, dry area.

• Always keep the power cord away from the brushes whilst using your

vacuum cleaner.

PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.

Thank you for purchasing the Dirt Devil Rebel 4.0

Taking care of your carpets and hard oors

The Rebel 4.0 is designed to make vacuuming carpets and hard floors regularly as effective

and efficient as possible and this user guide will help you get the most out of your machine.

Maintaining your carpets will ensure they keep their appearance for longer.

Taking care of your Rebel 4.0

Also inside this guide are instructions on maintaining your new machine, so that it’s always ready

when you are to tackle your carpets and hard floors.

We’re here if you need us

Australia: 1300 829 287

New Zealand: 0800 829 695

Please make a note of the serial number and model number of the product

before calling.

Contents

Included with

your machine

2-in-1 Tool

Combination Floor Head

2x Extension Tubes

Hose and Handle

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

What to do if it goes wrong

Notes

Also included is a warranty card and a user guide.

Contents vary dependant on model purchased.

Pictures shown are for illustration purpose only.

Getting to know your machine

Name: Dirt Devil Rebel 4.0 Bagless Vacuum

Model: DACBLV21E2

Voltage: 220-240V ~50Hz

Wattage: 2000W

Cord Length: 5m

Weight: 5.4kg

Capacity: 3L

Hose Length: 1.5m

Technical Specication

Double

Insulated

This product

meets applicable

regulatory

requirements

Indoor

Use

Only

Read

Instructions

Subject to technical change without notice.

Images are illustrative only.

Contents vary dependant on model purchased.

Carry handle

Cyclone separator and shroud

Dust container lid

Variable power dial

On/off button

Dust container

Cord rewind button

Wheel

Dust container release button

Filter grille release button

Blockage indicator

Hose inlet

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE

Getting started

CAUTION: Always switch off the vacuum cleaner before connecting or disconnecting the hose/attachments,

or removing and emptying the dust container.

IMPORTANT: The condition of the filters affects the performance of your machine. Filters should be tapped over a

bin every 4-6 uses, to remove dirt and debris, and replaced every 6-9 months depending on use. For full cleaning

instructions, see “Cleaning the pre-motor filter” and “Cleaning the post-motor filter”.

IMPORTANT: Do not use the vacuum cleaner with blocked filters and without all of the filters in place.

Pre-motor Filter HEPA Post-motor Filter

Using your machine

Operating the appliance

Adjust the Variable Power Dial to

increase or decrease the suction.

Fully unwind the power cord.

A yellow mark on the cord

indicates the recommended cord

length. Do not exceed the cord

length beyond the yellow mark.

Taking care of your machine

Turn on the mains power supply,

then press the On/Off Button

on the vacuum to turn on the

vacuum.

Assembling your vacuum cleaner

NOTE: The floor head and 2-in-1 tool can all be attached directly to the extension tubes or hose handle.

NOTE: The floor tool may be difficult to move on some carpeted surfaces, adjust the Air Relief Valve on the hose

handle to reduce the suction pressure.

Hard floors

Carpets

Insert the hose into the hose inlet

on the vacuum until it clicks into

place. To remove the hose, press

the locking tabs on either side of

the hose connector and gently

pull.

Gently insert the handle into the

extension tubes and push until it is

secured into place.

Insert the opposite end of the

extension tubes into the floor

head. The floor head is ideal for

daily cleaning on carpets and hard

floors.

WARNING: Always switch off and unplug the vacuum cleaner from the electrical socket before assembling,

opening or emptying the dust container or before connecting/disconnecting the attachments.

Packing away and storage

Emptying and cleaning the dust container

Taking care of your machine

Press the On/Off Button to turn

off the vacuum. Unplug the power

plug from the power supply. Press

the Cord Rewind Button with one

hand and guide the power cable

with the other hand to ensure that

it does not whip.

For convenience, there is a

parking slot located at the rear

of the vacuum cleaner where the

floor head and extension tubes

can be attached for storage and

carrying.

Gently remove the dust container

by pressing the Dust Container

Release Button.

NOTE: The dust container should be emptied before dust and debris reaches the “MAX” line, which is indicated

on the side of the dust container.

Hold the dust container over a

rubbish bin and press the Dust

Release Button to empty the dust

container. Reinsert the dust con-

tainer into cleaner ensuring that it

clicks into place.

Taking care of your machine

IMPORTANT: Water temperature should not exceed 40°C when washing the pre-motor filter. Allow the filter to dry

completely for 24 hours before reinstalling the filter back into the vacuum cleaner.

Cleaning the pre-motor lter

24hr

The filter should be tapped over a

bin every 4-6 uses, to remove dirt

and debris, and replaced every

6-9 months depending on use.

For best performance, it is

recommended to wash the filter

every 3 months, or when it

becomes visibly dirty. The water

temperature should not exceed

40°C when washing the pre-

motor filter.

40�C max

Remove the dust container

from the vacuum. Turn the dust

container lid so that the arrow

on the dust container lid points

to the unlock symbol on the dust

container.

Remove the pre-motor filter, as

shown.

Allow the filter to dry completely

for 24 hours before reinstalling

the filter back into the dust

container.

Dieses Handbuch passt für folgende Modelle

Andere Dirt Devil Staubsauger Handbücher

Dirt Devil

Dirt Devil M089800 Bedienungsanleitung

Dirt Devil

Dirt Devil M0100 Bedienungsanleitung

Dirt Devil

Dirt Devil Lightweight Bedienungsanleitung

Dirt Devil

Dirt Devil BLACK LABEL BG74 Bedienungsanleitung

Dirt Devil

Dirt Devil Auto Clean M277 Bedienungsanleitung

Dirt Devil

Dirt Devil DDHVWD6V Bedienungsanleitung

Dirt Devil

Dirt Devil Factory M3320 Bedienungsanleitung

Dirt Devil

Dirt Devil REBEL24 Bedienungsanleitung

Dirt Devil

Dirt Devil DD5001 Bedienungsanleitung

Dirt Devil

Dirt Devil M130000 Bedienungsanleitung

Dirt Devil

Dirt Devil Platinum Force M0890 Bedienungsanleitung

Dirt Devil

Dirt Devil POWERCYCLONE 2300 Kurzanleitung

Dirt Devil

Dirt Devil Platinum Force Bedienungsanleitung

Dirt Devil

Dirt Devil Swivel Glide Bedienungsanleitung

Dirt Devil

Dirt Devil DQC-DVB-HKA Bedienungsanleitung

Dirt Devil

Dirt Devil Vacuum Cleaner Bedienungsanleitung

Dirt Devil

Dirt Devil DD7375 Bedienungsanleitung

Dirt Devil

Dirt Devil Vacuum Cleaner Bedienungsanleitung

Dirt Devil

Dirt Devil ND40100BPC Bedienungsanleitung

Dirt Devil

Dirt Devil Platinum Force Bedienungsanleitung

Dirt Devil

Dirt Devil M608 Navigator Bedienungsanleitung

Dirt Devil

Dirt Devil M0886 Bedienungsanleitung

Dirt Devil

Dirt Devil Upright vacuum cleaner Bedienungsanleitung

Dirt Devil

Dirt Devil Vacuum Cleaner Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
