INSTALLATION AND PROGRAMMING GUIDE

734N Series Access

Control Modules

About the 734N Series .............................. 1

Power Supply ................................................................... 1

Zone Terminals................................................................. 1

Annunciators..................................................................... 1

Indicator LEDs.................................................................. 1

Form C Relay ................................................................... 2

Programming Connection .......................................... 2

Wiegand and OSDP Reader Support..................... 2

Local Event Storage...................................................... 2

PCB Features...............................................3

Install the 734N Series Module.................4

Mount the 734N.............................................................. 4

Wire the Access Control Lock .................................. 5

Isolation Relay (optional)............................................ 8

Install the 333Suppressor.......................................... 9

Wire the Zone Terminals ............................................10

Connect a Wiegand Card Reader...........................12

Connect an OSDP Card Reader ..............................15

Network Connection....................................................19

Set the 734N Address................................................20

Connect the Power Supply ...................................... 22

TABLE OF CONTENTS

Program the Panel....................................23

Device Setup..................................................................23

Device Number .................................................................23

Device Name......................................................................23

Device Type........................................................................24

Communication Type......................................................24

Program the 734N Series Module..........25

734N Menu ...................................................26

Programmer Menu.......................................................26

Initialization Options................................................... 27

Initialize Communication ............................................. 27

Initialize Access ............................................................... 27

Communication Menu ................................................28

734N Device Number .....................................................28

734N DHCP ........................................................................28

734N IP Address...............................................................28

Subnet Mask.......................................................................28

Gateway Address .............................................................29

Panel IP Address...............................................................29

Panel IP Port ......................................................................29

734N Passphrase..............................................................29

Access Options............................................................ 30

Reader Protocol Type.................................................... 30

Activate Zone 2Bypass .................................................32

Activate Zone 3 Request to Exit.................................34

Activate Onboard Speaker ...........................................35

Card Formats.....................................................................35

Require Site Code............................................................38

Number of User Code Digits .......................................39

Card Format Added/Changed (Custom Format)40

No Communication with Panel .................................. 40

Stop ...................................................................................41

Test the 734N Series Module ................. 42

734N Menu ...................................................42

Diagnostics Menu ............................................................42

Zone Status Display ........................................................43

Public Card Formats ............................... 44

734N Series Network Speciﬁcations .... 45

Compliance Listing Speciﬁcations ........47

UL Access Control .......................................................47

ULC Commercial Burglary (XR150/XR550Series

Panels)..............................................................................49

Certiﬁcations............................................ 50

Underwriters Laboratory (UL Listed) ................. 50

Product Speciﬁcations ............................ 51

Readers and Credentials .........................53

Digital Monitoring Products, Inc. | 734N Series Installation and Programming Guide 1

Annunciators

An onboard programmable piezo provides

local annunciation at the module. You can

also connect a variety of switched ground

annunciators to the module for remote

annunciation.

Indicator LEDs

734N Series modules provide three

indicator LEDs:

• RELAY (red) turns on for the same

duration as the door strike relay.

• WIEGAND (yellow) turns on for one

second to indicate receipt of valid input.

• DATA (green) indicates that the module

is communicating with the panel.

The 734N and 734N‑POE Access Control Modules allow you to add IP network access

control capability to XR150/XR550Series panels using proximity, credential, or

mag‑stripe card readers. The modules also allow you to use the powerful built‑in access

control capability of DMP Panels.

Power Supply

734N Series modules operate at

12/24VDC from the power supply

supporting a door’s magnetic lock or

door‑strike. The 734N‑POE can also be

powered from POE.

Warning: To avoid the risk of

equipment damage, do not exceed

750mA total output current for

zones connected to the module.

Zone Terminals

Four input zones are provided to allow

connection of nearby burglary devices.

ABOUT THE 734N SERIES

2 734N Series Installation and Programming Guide | Digital Monitoring Products, Inc.

Form C Relay

The 10Amp Form C relay draws up to

35mA of current. Refer to “Wire the

Access Control Lock” and “Isolation Relay

(optional)” in this document for more

information.

Programming Connection

The modules also provide a keypad

programming connection that allows

you to use a standard DMP LCD keypad

for initial setup. Programming can be

completed using a keypad connected to

the module or from XR150/XR550panels.

Wiegand and OSDP Reader

Support

The 734N Series supports both Wiegand

and OSDP card readers. For information

on compatible readers, refer to “Readers

and Credentials”. OSDP support requires

734N/734N‑POE modules with PCB Rev 9

and higher.

Local Event Storage

When communication is lost with the

panel, 734N and 734N‑POE Access

Control Modules store access granted

events locally in module memory. When

communication is reestablished, stored

events are sent and synced with panel

events, then inserted into the event buer

according to the actual time when they

occurred. To enable local event storage,

CARD FORMAT must be set to DMP or

CUSTOM and NO COMM WITH PNL must

be set to SITE or ANY.

Local Event Storage requires 734N/734N‑

POE modules with ﬁrmware Version 105

or higher, along with XR Series ﬁrmware

Version 202 or higher.

Digital Monitoring Products, Inc. | 734N Series Installation and Programming Guide 3

PCB FEATURES

Input

Reader

Inputs Zones

Piezo

Indicator

LEDs

Door Relay

Network

Connection

Figure 1: PCB Features

Keypad

Programming

Header

Status

Indicator

Outputs

Output 1

Reset Header

Output 2

4 734N Series Installation and Programming Guide | Digital Monitoring Products, Inc.

INSTALL THE 734N SERIES MODULE

Mount the 734N

The module comes in a high‑impact plastic housing that you can mount directly to a

wall, backboard, or other ﬂat surface.

For easy installation, the back and ends of the 734N housing have wire entrances. The

back also contains multiple mounting holes that allow you to mount the module on

a single‑gang switch box. DMP recommends mounting the 734N near the protected

door. Refer to Figure 2for mounting hole locations on the housing base.

1. Remove the PCB from the

plastic housing by loosening

the clips on one side and gently

lifting it out of the housing base.

2. Insert the included screws in the

desired mounting hole locations

and tighten them to secure the

housing to the surface.

3. Reinstall the PCB in the housing

base.

Mounting Holes

Figure 2: Mounting Hole Locations

Digital Monitoring Products, Inc. | 734N Series Installation and Programming Guide 5

Wire the Access Control Lock

The module provides a Form C (SPDT) relay for controlling locks and other

electronically‑controlled barriers. The three relay terminals marked NO C NC allow

you to connect the device wiring to the relay for module control.

When the 734N Series module is powered with a 12/24V power supply, the device

can power an electric strike, up to 750mA. See Figure 3 and Figure 4 for typical

magnetic lock and door strike wiring. The 734N‑POE can also be powered with POE.

See Figure 5for POE door strike wiring.

The Form C relay draws up to 35mA of current and contacts are rated for 10Amps

(resistive) at 12/24VDC. When connecting multiple locks to the Form C relay, the

total current for all locks cannot exceed 10Amps. If the total current for all locks

exceeds 10Amps, problems may arise and an isolation relay may be needed. See

“Isolation Relay (optional)” for more information.

6 734N Series Installation and Programming Guide | Digital Monitoring Products, Inc.

Model 333

Suppressor

–+

12/24 VDC

Power Supply

734N

Normally Closed

Magnetic Door

Lock

Mag lock positive

to 734N terminal NC

Power supply positive

to 734N terminal C

Mag lock negative to

power supply negative

Figure 3: Typical Magnetic Lock Wiring

Model 333

Suppressor

–+

12/24 VDC

Power Supply

734N

Normally Open

Door strike positive

to 734N terminal NO

Power supply positive

to 734N terminal C

Door strike negative to

power supply negative

DC Door Strike

Figure 4: Typical Door Strike Wiring

Andere Handbücher für 734N Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere DMP Electronics Steuereinheit Handbücher

DMP Electronics

DMP Electronics RoBoard RM-G146 Bedienungsanleitung

DMP Electronics

DMP Electronics 736V Bedienungsanleitung

DMP Electronics

DMP Electronics 893A Bedienungsanleitung

DMP Electronics

DMP Electronics RoBoard RM-G145 Bedienungsanleitung

DMP Electronics

DMP Electronics Wiegand 734N Bedienungsanleitung

DMP Electronics

DMP Electronics 717 Bedienungsanleitung

DMP Electronics

DMP Electronics XR100 Bedienungsanleitung

DMP Electronics

DMP Electronics RoBoard RM-G212 Bedienungsanleitung

DMP Electronics

DMP Electronics 780 Installationsanleitung

DMP Electronics

DMP Electronics 400 Bedienungs- und Wartungsanleitung

DMP Electronics

DMP Electronics 867 W LX-BUS Bedienungsanleitung

DMP Electronics

DMP Electronics RoBoard RM-G211 Bedienungsanleitung

DMP Electronics

DMP Electronics 893A Bedienungsanleitung

DMP Electronics

DMP Electronics 711S Bedienungsanleitung

DMP Electronics

DMP Electronics 708 Bedienungsanleitung

DMP Electronics

DMP Electronics 263EXT Bedienungsanleitung

DMP Electronics

DMP Electronics 714N-POE Installationsanleitung

DMP Electronics

DMP Electronics 714 Bedienungsanleitung

DMP Electronics

DMP Electronics myQ 736Q Montageanleitung

DMP Electronics

DMP Electronics ITI 738I Installationsanleitung

DMP Electronics

DMP Electronics 716 Bedienungsanleitung

DMP Electronics

DMP Electronics 734N-WIFI Administratorhandbuch

DMP Electronics

DMP Electronics 734 Installationsanleitung

DMP Electronics

DMP Electronics 867 Style W Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
