Use & Care Guide

Manual de Uso y Cuidado

Manuel d'entretien et d'utilisation

Model/Modelo/Modèle: KW3030

Household Wet/Dry Canister Vacuum

Aspiradora con depósito de uso

doméstico en seco/mojado

Aspirateur-Traîneau D’Atelier Sec Et

Humide Domestique

www.kenmorefloorcare.com

Vacuum Cleaner Help Line:

1-877-531-7321 (US) / 1-844-608-3081 (CA)

8:00am-5:00pm EST, M-F

- 2 -

Before Using Your New Vacuum Cleaner ........................................................................ 2

Packing List ..................................................................................................................... 3

Important Safety Instructions........................................................................................4-5

Vacuum Cleaner Warranty .............................................................................................. 6

Double Insulation Instructions..........................................................................................7

Extension Cords............................................................................................................... 8

Parts and Features........................................................................................................8-9

Assembly Instructions................................................................................................10-12

Operating Instructions ............................................................................................... 12-16

Vacuum Maintenance and Care.................................................................................17-19

Troubleshooting .............................................................................................................20

Requesting Assistance or Service......................................................................Back Cover

TABLE OF CONTENTS

Read this Use & Care Guide. It will help you assemble and operate your new Kenmore

vacuum cleaner in the safest and most effective way.

For more information about vacuum cleaner care and operation, call the Vacuum Cleaner

Help Line at 1-877-531-7321 (US) / 1-844-608-3081 (CA). You will need the complete model

and serial numbers when requesting information.

Your vacuum cleaner’s model and serial numbers are located on the Model and Serial

Number Plate. Use the space below to record the model number and serial number of your

new Kenmore vacuum cleaner.

Model No.____________________________________________

Serial No. ____________________________________________

Date of Purchase ______________________________________

Keep this book and your sales check (receipt) in a safe place for future reference.

BEFORE USING YOUR NEW VACUUM CLEANER

- 3 -

PACKING LIST

Your KENMORE VACUUM CLEANER is packaged with the following parts and components

assembled separately in the carton:

1 Vacuum Assembly

1 Hose

1 Base

1 Wall Mount Rack

1 Round Dusting Brush

1 Crevice Tool

1 Multi-Surface Floor Nozzle

1 Utility Tool

1 Reusable Cloth Filter (Pre-installed)

1 Foam Wet Filter

1 Dust Bag

3 Extension Wands

2 Casters

2 Wheels

1 Handle

4 Small Screws (Bag)

2 Screws (Bag)

1 Use & Care Guide

- 4 -

IMPORTANT SAFETY INSTRUCTIONS

• Do not run vacuum unattended.

• Do not use to pick up flammable or

combustible liquids, such as gasoline, or

use in areas where they may be present.

• Do not vacuum, or use this vacuum near

flammable liquids, gases, or explosive

vapors like gasoline or other fuels,

lighter fluids, cleaners, oil-based paints,

natural gas, hydrogen, or explosive dusts

like coal dust, magnesium dust, grain

dust, or gun powder. Sparks inside the

motor can ignite flammable vapors or

dust.

• To reduce the risk of health hazards

from vapors or dusts, do not vacuum

toxic materials.

• Do not use or store near hazardous

materials.

• Do not pick up anything that is burning

or smoking, such as cigarettes, matches,

or hot ashes.

• Do not expose to rain. Store indoors.

• If vacuum is not working as it should, has

been dropped, damaged, left outdoors,

or dropped into water, immediately

discontinue use and call 1-877-531-

7321 (US) / 1-844-608-3081 (CA) for

assistance.

• Do not unplug by pulling on cord. To

unplug, grasp the plug, not the cord.

• Do not use with damaged cord or plug.

• Do not pull or carry by cord, use cord as

a handle, close a door on cord, or pull

cord around sharp edges or corners.

• Keep cord away from heated surfaces.

• Do not run the vacuum over cord.

• Do not handle plug or vacuum with wet

hands.

• Do not use without dust bag and/or

filters in place.

• Do not allow to be used as a toy. Close

attention is necessary when used by or

near children.

• To reduce the risk of injury from

accidental starting, unplug power cord

before changing or cleaning filter.

• Do not leave vacuum when plugged in.

Unplug from outlet when not in use and

before servicing.

• Turn off all controls before unplugging.

• Unplug before connecting or

disconnecting hose, or any other

accessories.

• Do not put any object into openings. Do

not use with any opening blocked; keep

free of dust, lint, hair, and anything that

may reduce air flow.

• Keep hair, loose clothing, fingers, and

all parts of body away from openings

and moving parts.

• Use extra care when cleaning on stairs.

• Use only as described in this manual.

Use only manufacturer’s recommended

attachments.

• This vacuum is provided with

double insulation. Use only identical

replacement parts. See DOUBLE

INSULATION INSTRUCTIONS.

• This vacuum is designed for household

use only!

WARNING!

Your safety is important to us. To reduce the risk of fire, electrical shock, injury to persons

or damage when using your vacuum cleaner, follow basic safety precautions including the

following:

Read all instructions in this guide before assembling or using your vacuum cleaner.

- 5 -

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

Proper assembly and safe use of your vacuum cleaner are your responsibilities. Your vacuum

cleaner is intended for Household Use. Read this Use & Care Guide carefully for important

use and safety information. This guide contains safety statements under warning and caution

symbols.

CAUTION

To reduce the risk of injury from moving

parts - Unplug before servicing.

WARNING

To reduce the risk of electric shock - Unplug

before cleaning or servicing.

When using as blower:

• Direct air discharge only at work area.

• Do not use Wet/Dry Vacuum as a

sprayer.

• Do not direct air at bystanders.

• Keep children away when blowing.

• Wear safety goggles.

- 6 -

VACUUM CLEANER WARRANTY

LIMITED WARRANTY

FOR ONE YEAR from the date of sale this product is warranted against defects in material

or workmanship.

WITH PROOF OF SALE, a defective product will be replaced free of charge.

The Kenmore brand is used under license. Direct all claims for warranty service to:

1-877-531-7321 (US) / 1-844-608-3081 (CA).

This warranty does not cover attachments such as filter, hose, nozzles, or casters which are

expendable parts that can wear out from normal use within the warranty period.

This warranty is void if this product is ever used for other than private household purposes.

This warranty gives you specific legal rights, and you may also have other rights which

vary from state to state.

Cleva North America, Inc., Greenville SC 29607

- 7 -

DOUBLE INSULATION INSTRUCTIONS

This Wet/Dry Vacuum is double insulated, eliminating the need for a separate grounding

system. Use only identical replacements parts. Read the instructions for Servicing Double-

Insulated Wet/Dry Vacuums before servicing. Use this vacuum as described in this manual.

Observe the following warnings that appear on the motor housing of your vacuum.

Double Insulated – Grounding not

required - When servicing use only identical

replacement parts.

WARNING

To reduce the risk of electric shock - do not

expose to rain. Store indoors.

WARNING

For your own safety, read and understand

the operator’s manual. Do not run

unattended. Do not pick up hot ashes,

coals, toxic, flammable or other hazardous

materials. Do not use around explosive

liquids or vapors.

CAUTION

Do not vacuum drywall dust, fireplace soot,

or ash with standard wet/dry filter. This

type of dust is very fine which may not be

captured by the filter and cause damage to

motor. When vacuuming fine dust use a fine

dust filter.

WARNING

Servicing of double-insulated wet/dry

vacuums

With a double-insulated wet/dry vacuum,

two systems of insulation are provided

instead of grounding. No grounding means

is provided on a double-insulated appliance,

nor should a means for grounding be

added. Servicing a double insulated wet/

dry vacuum requires extreme care and

knowledge of the system and should be

done only by qualified service personnel.

Replacement parts for a double-insulated

wet/dry vacuum must be identical to the

parts they replace. Your double-insulated

wet/dry vac is marked with the words

‘double insulated’ and the symbol

(Square within a square) may also be

marked on the appliance.

- 8 -

EXTENSION CORDS

When using an extension cord with your Wet/Dry Vacuum refer to the following table to

determine the required A.W.G. wire size. Before using the cleaner make sure the power

cord and extension cord are in good working condition. Make repairs or replacements

before using the vacuum cleaner. Only use extension cords that are rated for outdoor use.

Length of Extension Cord

120V 25ft (7.62m) 50ft (15.24m) 100ft

(30.48m)

150ft

(45.72m)

Ampere rating A.W.G. Wire Size

More than Not more than

0 6 18 16 16 14

6 10 18 16 14 12

10 12 16 16 14 12

12 16 14 12 Not recommended

PARTS AND FEATURES

It is important to know your vacuum cleaner’s parts and features to assure its proper and

safe use. Review these before using your vacuum cleaner.

To order a replacement part, call 1-877-531-7321 (US) / 1-844-608-3081 (CA).

REPLACEMENT PARTS

Item Part No.(US) Part No.(CA)

Reusable Cloth Filter 551715106 551715106

Foam Wet Filter 551009111 551009111

Extension Wand 551003109 551003109

Hose 551012124 551012124

Dust Bag 551098110 551098110

Crevice Tool 551012109 551012109

Round Dusting Brush 551004116 551004116

Utility Tool 551004113 551004113

Multi-Surface Floor Nozzle 551004115 551004115

Wall Mount Rack 551098111 551098111

- 9 -

NOTE: The hose and accessories for this vacuum are 1-1/4'' (32mm) diameter.

PARTS AND FEATURES

Accessory

Storage

Hose Storage

Hook

Handle

Wheel

Latch

Blower Port

On/Off Switch

Vacuum Port

Caster

Powerhead

Collection Tank

Base

Reusable Cloth

Filter

Hose

Extension Wands

Dust Bag

Foam Wet Filter

Wall Mount Rack

Multi-Surface

Floor Nozzle

Utility Tool

Round Dusting BrushCrevice Tool

4 Small Screws (Bag)

2 Screws (Bag)

- 10 -

NOTE: A Phillips head screwdriver is

required.

1. Undo the latches.

2. Lift the powerhead off the collection

tank.

3. Remove the contents from inside the

collection tank; make sure you have all

contents as listed on page 9.

Before assembling the vacuum cleaner, check the PACKING LIST (page 3). Use this list to

verify that you have received all the components of your new Kenmore Vacuum Cleaner.

Please pay special attention to these hazard alert boxes, and follow any

instructions given. WARNING statements alert you to such hazards as fire,

electric shock, burns and personal injury. CAUTION statements alert you to

such hazards as personal injury and/or property damage.

ASSEMBLY INSTRUCTIONS

WARNING

Electrical Shock Hazard.

DO NOT plug into electrical supply until

assembly is complete. Failure to do so

could result in electrical shock or injury.

To reduce the risk of electric shock, do

not expose to rain.

4. Insert the casters and wheels into the

respective sockets on the bottom of the

base. Apply pressure until casters and

wheels snap into place.

5. Turn the collection tank upside down

and fit the base assembly onto the tank.

Secure the base to the tank with the

supplied four small screws. Verify that

the base is assembled correctly. Do not

over-tighten screws.

Andere Handbücher für KW3030

Inhaltsverzeichnis

Sprachen:

Andere Kenmore Staubsauger Handbücher

Kenmore

Kenmore Pet HandiMate Bedienungsanleitung

Kenmore

Kenmore CSV Go XL Bedienungsanleitung

Kenmore

Kenmore 116.32923 Bedienungsanleitung

Kenmore

Kenmore CSV Go XL DS4030 Bedienungsanleitung

Kenmore

Kenmore 116.36724 Bedienungsanleitung

Kenmore

Kenmore 116.28014 Bedienungsanleitung

Kenmore

Kenmore 27814 - Canister Vacuum, Yellow Bedienungsanleitung

Kenmore

Kenmore 116.35922 Bedienungsanleitung

Kenmore

Kenmore 116.25812 Bedienungsanleitung

Kenmore

Kenmore 1T6.31100 Bedienungsanleitung

Kenmore

Kenmore Intuition BU4021 Bedienungsanleitung

Kenmore

Kenmore FeatherLite DU1040 Bedienungsanleitung

Kenmore

Kenmore 116.36622 Bedienungsanleitung

Kenmore

Kenmore VACUUM CLEANER 116.32289 Bedienungsanleitung

Kenmore

Kenmore COIZDMWOOU00 - KC01ZDMWZOUO Bedienungsanleitung

Kenmore

Kenmore Central Vacuum System Bedienungsanleitung

Kenmore

Kenmore 116.23155C Bedienungsanleitung

Kenmore

Kenmore 125.81714610 Bedienungsanleitung

Kenmore

Kenmore 116.23612 Bedienungsanleitung

Kenmore

Kenmore 116.33912 Bedienungsanleitung

Kenmore

Kenmore 216.31703 Bedienungsanleitung

Kenmore

Kenmore Sears 116 Bedienungsanleitung

Kenmore

Kenmore CROSSOVER MAX 116.10325 Bedienungsanleitung

Kenmore

Kenmore Intuition BU4050 Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
