Kramer FC-331 3G HD-SDI to HDMI Format Converter

Kramer Electronics, Ltd.

Preliminary

USER MANUAL

Model:

FC-331

SD/HD-SDI to HDMI Converter

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 3

2.3 Recycling Kramer Products 3

2.4 Quick Start 4

3Overview 5

3.1 Accessory to Medical Equipment (IEC 60601-1) 5

4Your FC-331 SD/HD-SDI to HDMI Converter 6

5Connecting the FC-331 SD/HD-SDI to HDMI Converter 8

6Technical Specifications 9

Figures

Figure 1: FC-331 SD/HD-SDI to HDMI Converter 6

Figure 2: Connecting the FC-331 SD/HD-SDI to HDMI Converter 8

Tables

Table 1: FC-331 SD/HD-SDI to HDMI Converter Features 7

Table 2: Technical Specifications of the FC-331 SD/HD-SDI to HDMI Converter 9

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront video, audio, presentation, and broadcasting

professionals on a daily basis. In recent years, we have redesigned and

upgraded most of our line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly

defined by function: GROUP 1: Distribution Amplifiers; GROUP 2:

Switchers and Routers; GROUP 3: Control Systems; GROUP 4:

Format/Standards Converters; GROUP 5: Range Extenders and Repeaters;

GROUP 6: Specialty AV Products; GROUP 7: Scan Converters and

Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room

Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio;

and GROUP 14: Collaboration.

Thank you for purchasing the Kramer DigiTOOLS®FC-331 SD/HD-SDI to

HDMI Converter, which is ideal for:

Home theater, presentation and multimedia applications

Rental and staging

SD/HD-SDI to HDMI Converter for medical equipment

The package includes the following items:

FC-331

Power supply (5V DC input)

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

Review the contents of this user manual

Go to www.kramerav.com/downloads/FC-331 to check for up-to-

date user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer

high-performance, high-resolution cables) to avoid interference,

deterioration in signal quality due to poor matching, and elevated

noise levels (often associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight

coils

Avoid interference from neighbouring electrical appliances that may

adversely influence signal quality

Position your FC-331 away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may

only be connected to other equipment that is installed inside

a building.

Getting Started

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside

the unit

Warning:

Use only the power cord that is supplied with

the unit

Warning:

Do not open the unit. High voltages can

cause electrical shock! Servicing by qualified

personnel only

Warning:

Disconnect the power and unplug the unit

from the wall before installing

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive

2002/96/EC aims to reduce the amount of WEEE sent for disposal to

landfill or incineration by requiring it to be collected and recycled. To

comply with the WEEE Directive, Kramer Electronics has made

arrangements with the European Advanced Recycling Network (EARN)

and will cover any costs of treatment, recycling and recovery of waste

Kramer Electronics branded equipment on arrival at the EARN facility. For

details of Kramer’s recycling arrangements in your particular country go to

our recycling pages at

http://www.kramerelectronics.com/support/recycling/.

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2.4 Quick Start

This quick start chart summarizes the basic setup and operation steps.

Overview

3 Overview

The FC-331 SD/HD-SDI to HDMI Converter is a high-performance format

converter for SDI (SMPTE 259M), HD-SDI (SMPTE 292M), and 3G

HD-SDI (SMPTE 424M) signals. It converts an SDI (Level A) audio and

video signal to an HDMI output signal with the same resolution and frame

rate

The FC-331 features:

An SD/HD-SDI/3G HD-SDI input on a BNC connector

An SDI loop on a BNC connector and an HDMI output

HDTV compatibility

Automatic active input LED indicators on the front panel. Green

indicates a standard definition (SDI) input signal and blue indicates a

high-definition (HD-SDI) input signal

5V DC power

Medical equipment compliance

3.1 Accessory to Medical Equipment (IEC 60601-1)

In the modern medical environment remote access is essential, for example,

to transfer clinical data between doctors and to train to medical students.

The FC-331 is certified according to the IEC 60601-1-2, Clause 2.1.3,

Medical Electrical Equipment, Part 1: General Requirements for EMC

standard which is required when accessory devices are used at locations

where medical personnel and patients are present.

The FC-331 constitutes an optional component that can be considered

necessary and suitable as part of medical equipment or for use as part of a

medical system to provide real time simultaneous video feeds to those

present at the local medical environment and at remote locations. In this

environment, the FC-331 can be added to the system ONLY if the

connecting equipment has been evaluated and meets the IEC 60601-1-2

EMC standards. Note, that when attaching accessory devices to a digital or

analog interface, they must comply with the IEC standard for which they

are used: EMC Standard (IEC 60601-1-2), Information Technology

equipment (IEC 60950-1 (2ed)).

No scaling is performed

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your FC-331 SD/HD-SDI to HDMI Converter

4 Your FC-331 SD/HD-SDI to HDMI Converter

Figure 1 and Table 1 define the FC-331 SD/HD-SDI to HDMI Converter:

Figure 1: FC-331 SD/HD-SDI to HDMI Converter

Your FC-331 SD/HD-SDI to HDMI Converter

Table 1: FC-331 SD/HD-SDI to HDMI Converter Features

Feature

Function

SD/HD-SDI IN BNC Connector

Connects to an SD or HD-SDI source

SD/HD-SDI LOOP BNC Connector

Connects to an SD or HD-SDI acceptor

SDI AUDIO GROUP SELECT

Turn to select the SDI input stereo channel (0 to 7)

HDMI OUT Connector

Connects to an HDMI acceptor

5V DC

+5V DC connector for powering the unit

SD/HD LED

Illuminates green for an SD input signal and blue for an

HD-SDI input signal

OUT LED

Illuminates green to indicate that a display is connected

ON LED

Illuminates green when receiving power
