User Manual

Návod k použití

Bedienungsanleitung

Instrukcja obsługi

Инструкция по эксплуатации

Посібник користувача

Levenhuk Biologic Microscopes

General Information

The microscope is safe for health, life and property of the consumer and the environment when

properly used; the microscope meets the requirements of international standards. The microscope is

designed for observing transparent objects in the transmitted and reected light using the bright eld

method, for biological use and teaching demonstrations.

Levenhuk DEM200 digital camera was exclusively designed for use with this microscope. It allows

transfer of the precise image of the observed object to your PC display. Levenhuk ToupView software

is included in the package; it allows viewing and editing of the received images.

Specication

Magnication 40x-1280x

Magnication of objective 4x, 10x, 40x

Eyepiece magnication 10x, 16х

Barlow lens 2x

Linear eld in the images space 18 mm

Tube length 160 mm, 6,299”

Stage dimensions 95x95 mm, 3,74”x 3,74”

Stage moving range 0 to 15 mm, 0 to 0,591”

Upper/Lower illumination power

supply batteries or AC adapter

Illumination LED

Camera model DEM200

MAX resolution (at rest) 1600x1200

Megapixels 2

Sensor 1/4" CMOS

Pixel size 2.8μm X 2.8μm

Sensitivity, v/lux-sec @550 nm 1

Speed (depends on the PC model) 15 fps

Video recording Yes

Active range 68dB

Location ocular tube (not eyepiece)

Image format BMP, TIFF, JPG, PICT, SFTL etc.

Field of view diameter 18 mm

Spectral range 400-650 nm

Programmable options Image size, brightness, white balance, exposure

control, etc.

Slot USB 2.0, 480 Mb/s

System requirements Windows 2000/XP(SP2)/2003/Vista; USB port

Software USB 2.0 driver, Levenhuk ToupView

Power supply via USB cable

Temperature range -30...70 °C, -86...158 °F

1Barlow lens 2Objectives 3Slide holders 4Stage 5Lower illumination 6Eyepiece 7Monocular

nosepiece 8Revolving head 9Stand 10 Focusing knob 11 Diaphragm disk 12 ON/OFF button 13 Base

stand 14 USB port 15 Digital camera 16 USB cable 17 Adapters 18 Setup CD

Legend

Package

Levenhuk 40L NG

Microscope unit with stage, revolving head for three objectives,

focusing mechanism, condenser lens and illumination 1 Pc

Monocular nosepiece 1 Pc

Objectives: 4x, 10x and 40x 1 Pc each

Eyepieces: 10x; 16x 1 Pc each

Barlow lens 1 Pc

Removable illumination 1 Pc

AC adapter 1 Pc

Carrying case 1 Pc

User manual and warranty slip 1 Pc each

Levenhuk 50L NG

In addition to Levenhuk 40L NG: Levenhuk K50 experiments kit:

Prepared slides 5 Pcs

Clean slides 5 Pcs

Flasks: with pitch, sea salt, yeast, brine shrimp 1 Pc each

Brine shrimp hatchery 1 Pc

Microtome 1 Pc

Forceps 1 Pc

"Attractive microscope. Scrutinizing the microcosm" user guide 1 Pc

Levenhuk D50L NG

In addition to Levenhuk 50L NG: Levenhuk DEM200 digital camera:

Digital camera 1 Pc

USB cable 1 Pc

2 adapters for dierent microscopes 1 Pc

SETUP CD Levenhuk ToupView (auto setup guide, drivers, soft-

ware for image visualization, xation and processing) 1 Pc

Focusing mechanism located on the stand allows vertical movement of the stage. The stage is moved

by focusing knob. The total focusing value is at least 15 mm.

Slide holders are xed on the stage surface. Diaphragm disk is attached to the lower part of the stage.

Revolving head holds the objectives; the objectives can be replaced by rotating the ring until it reach-

es the xed position.

The objectives included in the package are designed for tube length 160 mm.

Objectives:

Linear magnication Numerical aperture

40,1

10 0,25

40 0,65

The 40x objective is equipped with a spring casing, which protects the frontal lens from contacting the

specimen during the focus adjusting.

Modules description and usage

Camera

The digital camera was exclusively designed for use with this microscope.

The object image can be transferred to your PC display in its actual colors and stored in the PC mem-

ory.

Levenhuk ToupView software is included in the package; it allows viewing and editing of the received

images. Supported le formats: *.bmp, *.jpg, *.jpeg, *.png, *.tif, *.ti, *.gif, *.psd, *.ico, *.emf, etc.

The USB cable is used as camera power supply and for connection with PC.

Compatible OS: Windows 2000/XP/2003/Vista.

Maintenance and care

Using the microscope

Unpacking and getting started

• Unpack the microscope.

• Make sure all the parts are present.

• Move the stage to the lowermost position using the focusing knob.

• Press the ON/OFF button located on the back side of the microscope base next to the power cord to

turn the microscope on.

Focusing

• Place an object on the stage and x it with the slide holders.

• Rotating the revolving head, switch magnication to the 4x objective.

• Move the object to x its thickest part exactly under the objective.

• Rotate the focusing knob to raise the stage until the objective is close to the specimen; keep check-

ing the distance between the objective and the object to avoid their contact.

• Look through the eyepiece installed in the monocular head and lower the stage slowly rotating the

focusing knob until you see the object image.

Such adjustment protects the frontal lens from contacting the object when you use objectives of other

magnications; though, slight refocusing might be required.

Selecting the objective

We recommend that you start your observations with the lowest power objective; it helps to select a

segment for the detailed research. Once the segment is selected, you should center its image in the

microscope’s eld of view. This operation should be performed as precisely as possible, otherwise the

required segment might fail to appear in the eld of view of the higher power objectives.

• The microscope is designed for use in macroclimatic conditions with temperate or frigid climate, in

the laboratories at temperatures from 10 to 35 °C (50 to 95 °F) and the relative air humidity up to

80% at 25 °C (77 °F).

• The room should be free from dust, acid or alkali vapors, evaporations of other active substances.

• The microscope should be used in the room protected from shocks or vibrations.

• High temperatures and humidity may cause formation of mold or moisture condensation on the

optical and mechanical parts of the microscope, which can negatively aect its operation.

• When not in use the microscope should be covered with a special case.

• The microscope is designed for use in macroclimatic conditions with temperate or frigid climate, in

the laboratories at temperatures from 10 to 35 °C (50 to 95 °F) and the relative air humidity up to

80% at 25 °C (77 °F).

• The room should be free from dust, acid or alkali vapors, evaporations of other active substances.

• The microscope should be used in the room protected from shocks or vibrations.

• High temperatures and humidity may cause formation of mold or moisture condensation on the

optical and mechanical parts of the microscope, which can negatively aect its operation.

• When not in use the microscope should be covered with a special case.

• Metallic parts should be kept clean. Special attention should be paid to maintaining cleanliness of

the optics (especially objectives and eyepieces).

• To maintain the microscope, regularly remove dust o it, then clean it with a special Levenhuk

cleaning cloth slightly moistened with Levenhuk cleaning spray, and afterwards wipe it with a dry

soft clean tissue or cloth.

• When dust is on the objective lens, which is deep in the casing, carefully wipe the lens with a clean

Q-tip slightly moistened with ether or spirits mixture.

• If you noticed dust inside the objective or lm on the inside of the lenses, you should send the

objective for repair.

• The noncontact Levenhuk compressed air duster for optics ensures the best cleaning results; it

removes dust and dirt with air blast.

• It is prohibited to disassemble objectives and eyepieces.

• Never look at the sources of bright light or laser through the microscope: it will cause DAMAGE

TO YOUR EYES!

• Do not disassemble the microscope or camera on your own.

• Keep the microscope and camera away from condensation; do not use them in rainy weather.

• Keep the microscope away from shock or excessive pressure.

• Do not overtighten the locking screws.

• Keep the microscope and camera away from hostile environment, home and car heaters, incan-

descent lamps or open ame.

• When cleaning any optical surfaces, rst blow dust or loose particles o the surface or wipe

them o with a soft brush. Then wipe the lens with a soft clean tissue slightly moistened with

spirits or ether.

• Never touch the optical surfaces with your ngers.

Levenhuk Biologické mikroskopy

Obecné informace

Při správném používání je mikroskop bezpečný z hlediska zdraví, života a majetku uživatele, životního

prostředí a splňuje požadavky mezinárodních standardů. Mikroskop je určen k pozorování průhled-

ných předmětů v procházejícím a odraženém světle (tzv. metoda světlého pole). Je určen k použití v

biologii a ve výuce.

Digitální kamera Levenhuk DEM 130 byla speciálně navržena pro použití spolu s tímto mikroskopem.

Umožňuje přenos přesného obrazu pozorovaného objektu na obrazovku počítače. Součástí balení je

software Levenhuk ToupView, který umožňuje prohlížení a úpravy takto získaných obrázků.

Technické parametry

Zvětšení 40x až 1280x

Zvětšení objektivu 4x, 10x, 40x

Zvětšení okuláru 10x, 16х

Barlowova čočka 2x

Velikost obrazu (obrazový prostor) 18 mm

Délka tubusu 160 mm

Rozměry pracovního stolku 95x95 mm

Rozsah pohybu pracovního stolku 0 až 15 mm

Napájení pro horní/dolní osvětlení baterie nebo AC adaptér

Typ osvětlení LED

Model kamery DEM130

Nejvyšší rozlišení 1280x1024

Megapixelů 1.3

Typ senzoru 1/4" CMOS

Velikost pixelu 2.8 μm X 2.8 μm

Citlivost, V/lux-sec při 550 nm 1

Snímací frekvence (záleží na

modelu PC)

15 fps

Záznam videa Ano

Aktivní rozsah 68 dB

Umístění tubus okuláru (nikoliv okulár)

Formát souboru BMP, TIFF, JPG, PICT, SFTL atd.

Průměr zorného pole 18 mm

Spektrální rozsah 400 až 650 nm

Nastavitelné parametry Velikost obrázku, jas, vyvážení bílé, expozice a další

Rozhraní USB 2.0, 480 Mb/s

Systémové požadavky Windows 2000 / XP(SP2) / 2003 / Vista; USB port

Software Ovladač pro USB 2.0, Levenhuk ToupView

Napájení prostřednictvím kabelu USB

Rozsah pracovních teplot -30 až +70 °C

1Barlowova čočka 2Objektivy 3Svorky k uchycení preparátu 4Pracovní stolek 5Dolní osvětlení

6Okulár 7Monokulární hlavice 8Revolverová hlavice 9Rameno 10 Ostřící šroub 11 Otočný disk se

clonami 12 Tlačítko ON/OFF 13 Podstavec 14 Port USB 15 Digitální kamera 16 Kabel USB 17 Adaptéry

18 CD se softwarem

Legenda

Obsah balení

Levenhuk 40L NG

Mikroskop s pracovním stolkem, revolverovou hlavicí pro tři ob-

jektivy, zaostřovacím mechanizmem, kondenzorem a osvětlením 1 kus

Monokulární hlavice 1 kus

Objektivy: 4x, 10x a 40x po 1 kuse

Okuláry: 10x; 16x po 1 kuse

Barlowova čočka 1 kus

Vyjímatelné osvětlení 1 kus

AC adaptér 1 kus

Kufřík na přenášení 1 kus

Uživatelská příručka a záruční list po 1 kuse

Levenhuk 50L NG

Příslušenství k Levenhuk 40L NG: experimentální sada Levenhuk K50:

Pevné preparáty 5 kusů

Podložní sklíčka 5 kusů

Lahvičky: se smolou, mořskou solí, kvasnicemi, žábronožkami po 1 kuse

Nádobka pro ředění žábronožek 1 kus

Mikrotom 1 kus

Kleštičky 1 kus

Uživatelská příručka „Attractive microscope. Scrutinizing the

microcosm.“ („Krásy mikroskopie. Zkoumáme mikrokosmos.“) 1 kus

Levenhuk D50L NG

Příslušenství k Levenhuk 50L NG: digitální kamera Levenhuk DEM 130

Digitální kamera 1 Pc

Kabel USB 1 Pc

2 adaptéry pro různé mikroskopy 1 Pc

CD se softwarem Levenhuk ToupView (automatický instalační

průvodce, ovladače, software pro vizualizaci, uchovávání a zpra-

cování obrazu)

1 Pc

Zaostřovací mechanizmus, který se nachází na rameni, umožňuje vertikální pohyb pracovním stolkem.

Stolkem se pohybuje pomocí ostřícího šroubu. Celkový rozsah pohybu je nejméně 15 mm.

Na horní straně pracovního stolku jsou svorky k uchycení preparátu, zespodu je k němu připevněn

otočný disk se clonami.

Objektivy jsou umístěny v revolverové hlavici. Pro změnu objektivu otáčejte hlavicí tak dlouho, až se

zaxuje v nové poloze.

Součástí balení jsou objektivy určené pro použití s tubusem délky 160 mm.

Objektivy:

Lineární zvětšení Numerická apertura

40,1

10 0,25

40 0,65

Popis částí a jejich použití

Andere Handbücher für 40L

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Levenhuk Mikroskop Handbücher

Levenhuk

Levenhuk Cassegrain OTA Bedienungsanleitung

Levenhuk

Levenhuk 900 Series Bedienungsanleitung

Levenhuk

Levenhuk 40L Bedienungsanleitung

Levenhuk

Levenhuk DTX 300 LCD Bedienungsanleitung

Levenhuk

Levenhuk DTX RC Bedienungsanleitung

Levenhuk

Levenhuk LabZZ MT2 Bedienungsanleitung

Levenhuk

Levenhuk DTX 700 LCD Bedienungsanleitung

Levenhuk

Levenhuk ZOOM Series Bedienungsanleitung

Levenhuk

Levenhuk DTX 350 LCD Bedienungsanleitung

Levenhuk

Levenhuk 2s Bedienungsanleitung

Levenhuk

Levenhuk LabZZ MTB3 Bedienungsanleitung

Levenhuk

Levenhuk Discovery Artisan 64 Bedienungsanleitung

Levenhuk

Levenhuk DTX 500 Mobi Bedienungsanleitung

Levenhuk

Levenhuk 74246 Bedienungsanleitung

Levenhuk

Levenhuk LabZZ M101 Bedienungsanleitung

Levenhuk

Levenhuk DTX 90 Bedienungsanleitung

Levenhuk

Levenhuk MED PRO 600 Fluo Bedienungsanleitung

Levenhuk

Levenhuk DTX 50 Bedienungsanleitung

Levenhuk

Levenhuk DTX 90 Bedienungsanleitung

Levenhuk

Levenhuk 40L NG Bedienungsanleitung

Levenhuk

Levenhuk LabZZ M4 Bedienungsanleitung

Levenhuk

Levenhuk MED 45 Series Bedienungsanleitung

Levenhuk

Levenhuk DTX TV LCD Bedienungsanleitung

Levenhuk

Levenhuk D80L Bedienungsanleitung

Beliebte Mikroskop Handbücher anderer Marken

Thermo Scientific

Thermo Scientific Nicolet iN10 Leitfaden

National

National DC3-163 Bedienungsanleitung

KERN Optics

KERN Optics OPE-1 Bedienungsanleitung

OPTIKA MICROSCOPES

OPTIKA MICROSCOPES B-150D Bedienungsanleitung

Prior

Prior Lux POL Bedienungsanleitung

Opitec

Opitec Smartscoop 115615 Bedienungsanleitung

KERN

KERN OPO-1 Bedienungsanleitung

Topcon

Topcon SP-1P Bedienungsanleitung

Motic

Motic PA43 Bedienungsanleitung

Leica

Leica DVM5000 Benutzerhandbuch

MshOt

MshOt MZ62 Bedienungsanleitung

KERN Optics

KERN Optics OZR-5 Bedienungsanleitung

VWR

VWR VisiScope 384 Series Bedienungsanleitung

Nikon

Nikon ECLIPSE E200 POL Bedienungsanleitung

Leica

Leica DI C800 Handbuch

ThermoFisher Scientific

ThermoFisher Scientific Continuµm Bedienungsanleitung

ThermoFisher Scientific

ThermoFisher Scientific Continuµm Bedienungsanleitung

Olympus

Olympus SZ61 Bedienungsanleitung
