Linksys EF3508 Bedienungsanleitung

EtherFast®8-Port

Gigabit Ethernet Switch

he EtherFast®8-Port Gigabit Ethernet Switch takes your

network to a whole new level of productivity—and does it

using your existing architecture. There’s no need to aban-

don your present equipment or radically change your way of

doing things.This switch from Linksys allows you to do what you

already do—only faster!

Apply this switching power to your current Ethernet network,and

your data traffic efficiency will improve several times over.

Connect your Gigabit-equipped workstations to the Switch's

10/100/1000 ports for full-duplex, dedicated bandwidth of up to

1000Mbps!

With the EtherFast 8-Port Gigabit Ethernet Switch, you can con-

nect your existing 10/100 Ethernet network to your Gigabit net-

work backbone without any additional equipment. All ports are

auto-negotiating, and have auto MDI/MDI-X. Address learning

and aging is supported,as well as 802.3x flow control with head-

of-line blocking prevention to keep your high-speed clients from

bogging down in low-speed traffic.

The EtherFast 8-Port Gigabit Ethernet Switch from Linksys is the

all-in-one solution for your Gigabit and 10/100 networking needs.

• 8 10/100/1000 Mbps Auto-Negotiating Half/Full Duplex

Switched Ports

• Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3x,

IEEE 802.3ab

• Fully wire speed reception and transmission

• Integrated address look-up engine supports 8K MAC

addresses

• Automatic address learning and address aging

• Embedded 512K data packet memory

• Head of Line (HOL) blocking prevention

• Auto MDI/MDI-X on each port

EtherFast®8-Port Gigabit Ethernet Switch

Model No.: EF3508

Wire-speed switching and Linksys reliability

in an 8-port Gigabit switch

Features

Benefits

• Eight 10/100/1000Mbps, half/full duplex,

switched ports

• Forwards and filters packets at non-blocking,

full wire speed

• All ports have auto speed negotiation and

MDI/MDI-X

• Supports address learning and aging, 802.3x

flow control and head-of-line blocking preven-

tion

Instant EtherFast®Series

Package ContentsSpecifications

Model Number EF3508

Standards IEEE 802.3, 802.3u, 802.3x, 802.3ab

Ports 8Auto Sensing,Auto MDI/MDI-X

10/100/1000

Cabling Type Category 5e Recommended

LEDs 10,100,1000 (Per Port), FDX/ACT, Fan,

TEMP, Power

Environmental

Dimensions 16.93" x 1.75" x 9.45"

(430 mm x 44.5 mm x 240 mm)

Unit Weight 7.94 lbs. (3.6 kg)

Power 100-240V AC, 50W

Certifications FCC Class A, CE

Operating Temp. 32ºF to 122ºF (0ºC to 50ºC)

Storage Temp. -40ºF to 158ºF (-40ºC to 70ºC)

Operating Humidity 20% to 95%, Non-Condensing

Storage Humidity 20% to 95%, Non-Condensing

• One EF3508 EtherFast 8-Port Gigabit Ethernet

Switch

• One AC Power Cable

• One Setup CD with User Guide included

• One Registration Card

• 200Mhz CPU or better

• 64MB RAM

• CD-ROM Drive

• Network Adapter

Minimum Requirements

DS-EF3508-122402NC KL

Linksys

World Headquarters:

17401 Armstrong Ave.

Irvine, CA 92614 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete

list of local Linksys Sales and Technical

Support contacts,visit ourWorldwideWeb Site

www.linksys.com
