INSTALLATION INSTRUCTIONS FOR PART 95-8903B

APPLICATIONS

SUBARU

LEGACY & OUTBACK

2010

(NON-NAVIGATION RADIOS ONLY)

KIT FEATURES

•DDIN radio provision

•Stacked ISO radio provision

•Painted scratch resistant matte black

A) DDIN Trim plate B) DDIN Brackets

KIT COMPONENTS

TOOLS REQUIRED:

•Small Flat Blade Screwdriver • Phillips Screwdriver

•Panel Removal Tool • Socket Wrench

1-800-221-0932

www.metraonline.com

95-8903B

METRA. THE WORLD’S BEST KITS.™

WIRING AND ANTENNA CONNECTIONS (Sold Separately)

Wiring Harness:

•70-8901 Subaru Harness 1990-Up

•70-7552 Nissan Harness 2007-Up

Antenna Adapter:

•40-SB10 Subaru Antenna Adapter 2005-Up

Dash Disassembly

-2010 Subaru Legacy . . . . . . . . . . .

..........................

-2010 Subaru Outback . . . . . . . . . .

..........................

Kit Assembly

-Double DIN / Stacked ISO DIN Head Unit Provision. . . . . . . . . . . . . . . . 2

TABLE OF CONTENTS

95-8903B

*Note:

Refer also to the instructions included with the aftermarket radio.

Metra recommends MECP certified

technicians.

95-8903B DASH DISASSEMBLY

2010 SUBARU LEGACY / OUTBACK

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Unclip and remove the radio trim

panel including the a/c vents.

(

Figure A)

Remove (4) Phillips screws securing

the factory radio.

95-8903B KIT ASSEMBLY

Locate the factory wiring harness in

the dash. Metra recommends using

the proper mating adapter from Metra

or AXXESS. Re-connect the negative

battery terminal and test the unit for

proper operation.

Attach the Double DIN brackets to the

Double DIN trim plate.(FigureA)

Slide the Double DIN head unit or

stacked ISO head units into the

bracket/radio housing assembly and

securethe Double DIN head unit or

stacked ISO head units to the assem-

bly using the screws supplied with

the radio. (Figure B)

Reassemble dash in reverse order of

disassembly.

2010 SUBARU LEGACY / OUTBACK

DOUBLE DIN / STACKED ISO DIN HEAD UNIT

PROVISIONS

NOTES

95-8903B

NOTES

95-8903B

NOTES

95-8903B

306

INSTRUCTIONS

1-800-221-0932

www.metraonline.com

95-8903B INSTRUCTIONS

METRA. THE WORLD’S BEST KITS.™
