INSTALLATION INSTRUCTIONS FOR PART 99-5819

99-5819

KIT FEATURES

•DIN Radio Provision With Pocket

•ISO Mount Radio Provision With Pocket

•A) Radio Housing •B) Radio Housing Brackets • C) ISO Brackets • D) Trim Plate

KIT COMPONENTS

1-800-221-0932

www.metraonline.com

APPLICATIONS

FORD

F-150 (XL Models Only) 2009-10

Cutting Tool • Phillips Screwdriver • Socket Wrench

TOOLS REQUIRED:

WIRING AND ANTENNA CONNECTIONS (Sold Separately)

Wireharness:

•70-5520 Ford harness 2003-up

Antenna adapter:

•40-CR10 Chrysler antenna 2002-up

Dash Disassembly

FORD F-150 (XL Models Only) 2009-10 . . . . . . . . . . . . . . .

. . .1

Kit Assembly

-DIN Radio Provision With Pocket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

-ISO Mount Radio Provision With Pocket. . . . . . . . . . . . . . . . . . . . . . . . 3

Final Assembly . . .........................................4

TABLE OF CONTENTS

99-5819

*Note:

Refer also to the instructions included with the aftermarket radio.

99-5819 DASH DISASSEMBLY

FORD F-150

(

XL Models Only

)

2009-10

Remove the rubber pad at the top of

the radio trim panel then remove the

(2) 9/32” screws exposed. (

Figure B)

Disconnect the negative battery

terminal to prevent an accidental

short circuit.

Unclip and remove the switch panel

to the right of the cigarette lighter

then remove the (1) 9/32” screw

exposed. (

Figure A)

Unclip and pull the side panels con-

taining the a/c vents away from the

radio trim panel. Note: It is not nec-

essary to remove the panels com-

pletely. (

Figure C)

Unclip and remove the radio trim

panel. (

Figure D)

Remove (4) 9/32” screws to remove

the factory radio.

Continue to kit assembly.

99-5819 KIT ASSEMBLY

DIN RADIO PROVISION WITH POCKET

Cut and remove the top (2) mounting

holes off of the radio housing.

Note: The notch in the housing

should be on top.

(Figure A)

Slide the included brackets onto the

sides of the radio housings pocket

from the back of the housing

forward.

(Figure B)

Slide the DIN cage into the Radio

Housing and secure by bending the

metal locking tabs down.

(Figure C)

Slide the aftermarket head unit into

the cage and secure.

(Figure D)

Continue to final assembly.

*Note: Refer also to the instructions included with the aftermarket radio.

CUT HERE -TOP LEG ONLY

CUT

99-5819 KIT ASSEMBLY

ISO MOUNT RADIO PROVISION WITH POCKET

Cut and remove the top (2) mounting

holes off of the radio housing.

Note: The notch in the housing

should be on top.

(Figure A)

Slide the included brackets onto the

sides of the radio housings pocket

from the backof the housing

forward.

(Figure B)

Mount the ISO Brackets to the head

unit with the screws supplied with

the unit.

(Figure C)

Slide the head unit into the radio

opening until the side clips engage.

(Figure D)

Snap the trim plate into the Radio

Housing.

(Figure D)

Continue to final assembly.

*Note: Refer also to the instructions included with the aftermarket radio.

CUT HERE -TOP LEG ONLY

CUT

99-5819 FINAL ASSEMBLY

FINAL ASSEMBLY

(A) Strip wire ends back 1/2"

B) Twist ends together

C) Solder

D) Tape

Locate the factory wiring harness in the dash. Metra recommends using the proper mating

adapter and making the connections as shown. (Isolate and individually tape off the ends of

any unused wires to prevent electrical short circuit).

Re-connect the negative battery terminal and test the unit for proper operation.

Position the factory bracket/aftermarket radio assembly into the dash and secure using

the factory hardware.

Secure the Double DIN radio housing to the sub dash using the factory hardware.

Reassemble the rest of the dash in reverse order of disassembly.

Make wiring connections using the EIA color code chart shown below and the instructions

included with the head unit. Metra recommends making connections shown below; Strip, Splice,

Solder, Tape. Isolate and individually tape off ends of any unused wires to prevent electrical short

circuit.

FINAL WIRING CONNECTIONS

METRA / EIA WIRING CODE

12V Ignition / Acc. . . . . . . . . . Red

12V Batt / Memory. . . . . . . . . Yellow

Ground..................Black*

Power Antenna. . . . . . . . . . . . Blue

Amp Turn-On . . . . . . . . . . . . . Blue / White

Amp Ground. . . . . . . . . . . . . . Black / White

Illumination . . . . . . . . . . . . . . Orange

Dimmer . . . . . . . . . . . . . . . . . Orange / White

Right Front (+) . . . . . . . . . . . . Gray

Right Front (-). . . . . . . . . . . . . Gray/ Black

Left Front (+) . . . . . . . . . . . . . White

Left Front (-). . . . . . . . . . . . . . White / Black

Right Rear (+) . . . . . . . . . . . . Violet

Right Rear (-) . . . . . . . . . . . . . Violet / Black

Left Rear (+) . . . . . . . . . . . . . Green

Left Rear (-) . . . . . . . . . . . . . . Green / Black

*NOTE:

When a Blackwireis not present, ground radio to vehicle chassis. All colors may not be

present on all leads due to manufacturer’sspecifications.

NOTES

99-5819

99-5819 INSTRUCTIONS

1-800-221-0932

www.metraonline.com
