INSTALLATION INSTRUCTIONS FOR PART 99-9103

86-9001 Head Unit Removal Keys • Flat Blade Screwdriver

1-800-221-0932 www.metraonline.com

KIT FEATURES

©COPYRIGHT 2004-2009 METRA ELECTRONICS CORPORATION

APPLICATIONS

Audi A4 2001-2007

•DIN Head Unit Provisions

A) Radio Housing

KIT COMPONENTS

TOOLS REQUIRED:

99-9103

A

WITH THE CONCERT RADIO

99-9103

•

Dash Disassembly

•Audi A4 - 2001-2007 ----------------------------------------- 1

•

Kit Assembly

-DIN Head Unit Provision -------------------------------------- 2

•

Final Assembly -------------------------------------------------- 3

TABLE OF CONTENTS

K

NOWLEDGE IS

P

OWER

Enhanceyour installation and fabrication skillsby

enrolling in the most recognizedandrespected

mobile electronics school in our industry.

Log onto www.installerinstitute.comor call

800-354-6782 for more informationandtake steps

toward abetter tomorrow.

99-9103

1

DASH DISASSEMBLY

AUDI A4 2001-2007

Disconnect the negative battery terminal

to prevent an accidental short circuit.

Insert Metra’s 86-9001 into the slots in

the factory head unit and pull the unit out.

Figure A

1

2

Disconnect the wiring.

3

A

99-9103

2

KIT ASSEMBLY

DIN Head Unit Provision

1Slide the DIN cage into the Radio

Housing and secure by bending

the metal locking tabs down.

2Slide the after-market head unit

into the cage until secure.

99-9103

3

FINAL ASSEMBLY

FINAL ASSEMBLY

A

Locate the factory wiring harness in the dash.

Metra recommends using the proper mating

adapter and making the connections as

shown. (Isolate and individually tape off the

ends of any unused wires to prevent electrical

short circuit) Figure A

Re-connect the negative battery terminal and test

the unit for proper operation.

A) Strip wire ends back 1/2"

B) Twist ends together

C) Solder

D) Tape

1

2

Snapradio housing assembly into factoryradio

opening.

3

B

C

D

99-9103

4

NOTES

99-9103

5

NOTES

1-800-221-0932 www.metraonline.com

©COPYRIGHT 2004-2009 METRA ELECTRONICS CORPORATION REV. 04-16-09
