INSTALLATION INSTRUCTIONS FOR PART 99-8157B

APPLICATIONS

LEXUS SC SERIES

1992-2000

KIT FEATURES

•ISO Mount Radio Provision With Pocket

•Painted BlackToMatchFactoryDash

A) Radio Housing With Pocket • B) Housing Brackets • C) (4) #8 X 3/8” Phillips Screws

KIT COMPONENTS

Small Flat Blade Screwdriver/ Panel Removal Tool

•Phillips Screwdriver • Socket Set

1-800-221-0932

www.metraonline.com

99-8157B

TOOLS REQUIRED:

Dash Disassembly

Lexus SC Series 1992-2000 . . . . . . . . . . . . . . . . . . . . . . . . . .

1,2

Kit Assembly

-ISO Mount Radio Provision with Pocket . . . . . . . . . . . . . . . . . . . . . . . . 3

Final Assembly ...........................................4

TABLE OF CONTENTS

99-8157B

*Note:

Refer also to the instructions included with the aftermarket radio.

NOWLEDGE IS

OWER

Enhanceyour installation and fabrication skillsby

enrolling in the most recognizedandrespected

mobile electronics school in our industry.

Log onto www.installerinstitute.comor call

800-354-6782 for more informationandtake steps

toward abetter tomorrow.

99-8157B DASH DISASSEMBLY

LEXUS SC SERIES 1992-2000

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Push down on collar around base of

shift knob then remove (2) Phillips

screws then pull up on knob to

remove. (

Figure A)

Unclip and remove the shifter trim

panel. Tip: Start at the front with

ashtray open.

(Figure B)

Open cup holder lid then unclip and

remove the cup holder.

Continued on page 2.

99-8157B DASH DISASSEMBLY

LEXUS SC SERIES 1992-2000

Remove (6) Phillips screws securing

the upper console trim panel then

unclip and remove the panel. (

Figure C)

Remove (8) screws securing the radio

and climate control assembly.

Remove (4) screws securing the

climate controls to the bracket

assembly and remove the climate

controls. (Retain the screws and cli-

mate controls for reuse during kit

assembly) (

Figure D)

Continue to kit assembly.

99-8157B KIT ASSEMBLY

Attach the Housing Brackets to the

Radio Housing using the (4) #8 X3/8”

Phillips screws.

(Figure A)

Position the factory climate controls

into the bracket/radio housing

assembly and secure using the

factory hardware.

(Figure B)

Slide the aftermarket radio into the

bracket/radio housing assembly and

secure the radio to the assembly

using the screws supplied with the

radio.

(Figure C)

Continue to final assembly.

LEXUS GS SERIES 1992-2000

ISO MOUNT RADIO PROVISON WITH POCKET

Note: Refer also to the instructions included with the aftermarket radio.

99-8157B FINAL ASSEMBLY

FINAL ASSEMBLY

(A) Strip wire ends back 1/2"

B) Twist ends together

C) Solder

D) Tape

Locate the factory wiring harness in the dash. Metra recommends using the

proper mating adapter and making connections as shown. (Isolate and individ-

ually tape off the ends of any unused wires to prevent electrical short circuit.)

Re-connect the negative battery terminal and test the unit for proper operation.

Reassemble radio and dash assemblies in reverse order of disassembly.

FINAL WIRING CONNECTIONS

Make wiring connections using the EIA color code chart shown belowand the instructions included with the

head unit. Metra recommends making connections as shown below; Strip, Splice, Solder, Tape. Isolate and

individually tape off ends of any unused wires to prevent electrical short circuit.

METRA / EIA WIRING CODE

12V Ignition / Acc. . . . . . . . . . Red

12V Batt / Memory. . . . . . . . . Yellow

Ground. . . . . . . . . . . . . . . . . . Black*

Power Antenna. . . . . . . . . . . . Blue

Amp Turn-On . . . . . . . . . . . . . Blue / White

Amp Ground. . . . . . . . . . . . . . Black / White

Illumination . . . . . . . . . . . . . . Orange

Dimmer . . . . . . . . . . . . . . . . . Orange / White

Right Front (+) . . . . . . . . . . . . Gray

Right Front (-). . . . . . . . . . . . . Gray/ Black

Left Front (+) . . . . . . . . . . . . . White

Left Front (-). . . . . . . . . . . . . . White / Black

Right Rear (+) . . . . . . . . . . . . Violet

Right Rear (-) . . . . . . . . . . . . . Violet / Black

Left Rear (+) . . . . . . . . . . . . . Green

Left Rear (-) . . . . . . . . . . . . . . Green / Black

*NOTE: When a Black wire is not present, ground radio to vehicle chassis.

All colors may not be present on all leads due to manufacturer’sspecifictions.

Enjoy your newly installed radio!

NOTES

99-8157B

99-8157B INSTRUCTIONS

1-800-221-0932

www.metraonline.com
