INSTALLATION INSTR CTIONS FOR PART 99-6511

99-6511

APPLICATIONS

Chrysler : Aspen 2008-09/Sebring 2007-10

Town and Country 2008-10/300/300c 2008-10

Dodge: Avenger 2007-10/Caliber 2009-10/Challenger 2009-10

Charger 2008-10/Dakota 2008-10/Durango 2008-09

Grand Caravan 2008-10/Journey 2009-10

Magnum 2008-09/ Nitro 2007-10/Ram 1500 2009-11/

Ram2500/3500 2010-11

KIT FEATURES

• DIN Mount Radio Provision with Pocket

• ISO Mount Radio Provision with Pocket

A) Radio Housing with Pocket • B) ISO Brackets • C) ISO Trim Plate

KIT COMPONENTS

TOOLS RE UIRED:

Small Flat Blade Screwdriver/ Panel Removal Tool

• Phillips Screwdriver • Socket Set

1-800-221-0932

www.metraonline.com

Jeep : Compass 2009/Commander 2008-10/Grand Cherokee2008-10/Patriot 2009-10

Liberty 2008-10/ rangler 2007-10

Mitsubishi: Raider 2008-10

WIRING AND ANTENNA CONNECTIONS (Sold Separatel )

Harness:

• XSVI-6522-NAV - Chrysler CAN R.A.P. with NAV outputs 07-up

• CHTO-03 - Chrysler CAN amp turn on interface 07-up

Antenna Adapter:

• 40-EU10 - European antenna adapter 02-up

Da h Di a embly

Chrysler Aspen 2008-2009/Dodge Durango 2008-2009 . . . . . .

. . . . ... . . . . . . . .1

Chrysler Sebring 2007-2010 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . ... . . . . . . .2

Chrysler Town and Country 2008-2010 . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . .3,4

Chrysler 300/300C 2008-2010 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . .5

Dodge Avenger 2007-2010 . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . .

. . . . .. . . . . . . . 6

Dodge Caliber 2009-10 . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . .

. . . . ... . . . . . .12

Dodge Challenger 2009-10 . . . . . . . . .. . . . . . . . . . . . . . . . . . . . .

. . . . ... . . . . . .12

Dodge Dakota 2008-2010 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . .. . . . . . . .7

Dodge Grand Caravan 2008-2010 . . . . .. . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . .3,4

Dodge Magnum 2008-09/Charger 2008 -10 . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . 5

Dodge Nitro 2007-2010/Liberty 2008-2010 . . . . . . . . . . . . . . . . .

. . . . .. . . . . . . . . .8

Dodge Journey 2010 (Modifications to radio cavity required

) . . . . . . . . . . . . . . . . . 9

Dodge Ram 1500 2009-11/Ram 2500/3500 2010-11. . . . . . . . . .

. . . . . . . . . . .13,14

Jeep Commander/Grand Cherokee 2008-2010 . . . . . . . . . . . . . . . . . . . . . . . . . .

..10

Jeep Compass 2009 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

.. . . . . . .12

Jeep Patriot 2009-10.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . .12

Jeep rangler 2007-2010 (Modifications to radio cavity required) . . . . . . . . . . . . . 11

Mitsubishi Raider 2008-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Kit A embly

- DIN Mount Radio Provision with Pocket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

- ISO Mount Radio Provision with Pocket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Final A embly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

TABLE OF CONTENTS

99-6511

*Note:

Refer also to the instructions included with the aftermarket radio.

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

99-6511 DASH DISASSEMBLY

CHRYSLER ASPEN 2008-2009

DODGE D RANGO 2008-2009

POWER

OUTLET

123456

POWER

OUTLET

123456

Remove (2) screws from bottom edge

of center dash trim panel. Unsnap

and remove the panel. (

Figure B)

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Remove (4) screws securing the

radio. Unplug and remove radio.

(

Figure C)

Unsnap and remove storage cup

holder assembly. (

Figure A)

Continue to kit assembly.

99-6511 DASH DISASSEMBLY

CHRYSLER SEBRING 2007-2010

Remove (4) 7MM screws securing

radio. Unplug and remove radio.

(

Figure B)

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Unclip entire panel surrounding radio

including a/c vents and clock. Unplug

and remove panel. (

Figure A)

Continue to kit assembly.

99-6511 DASH DISASSEMBLY

CHRYSLER TOWN AND CO NTRY 2008-2010

DODGE GRAND CARAVAN 2008-2010

Lift up on panel above radio then

remove (2) Phillips screws exposed at

front edge of radio trim panel.

(

Figure B)

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Remove (3) plastic push pins per side

of bottom trim panel then slide panel

toward rear of van to access (2)

screws on bottom of radio trim panel.

(

Figure C)

Remove (2) screw covers facing up

above radio then remove the (2)

Phillips screws exposed. (

Figure A)

Continued on page 3.

99-6511 DASH DISASSEMBLY

123456AUX

AUX

SET

VOLUME

PUSH ON PUSH AUDIO/SELECT

DISC

LIST

MUSIC

T YPE

SEL;ECT

TUNE/SCROLL

SEEKSEEK SCAN TIME INFO R W FF

Remove (2) Phillips screws exposed

at bottom edge radio trim panel.

(

Figure D)

Remove (4) Phillips screws securing

radio. (

Figure F)

Unclip and remove entire panel sur-

rounding radio including climate con-

trols, vents and clock. (

Figure E)

Continue to kit assembly.

CHRYSLER TOWN AND CO NTRY 2008-2010

DODGE GRAND CARAVAN 2008-2010

99-6511 DASH DISASSEMBLY

CHRYSLER 300/300C 2008-2010

DODGE MAGN M2008-09/CHARGER 2008-10

123456

123 4 56

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Remove (4) screws securing the

radio. Disconnect and remove the

radio. (

Figure B)

Unsnap and remove center dash trim

panel. (

Figure A)

Continue to kit assembly.

99-6511 DASH DISASSEMBLY

DODGE AVENGER 2007-2010

1 2 3456AUX

AUX

SET

VOLUME

PUSH ON PUSH AUDIO/SELECT

DISC

LIST

MUSIC

TYPE

SEL;ECT

TUNE/SCROLL

SEEKSEEK SCAN TIME INFO RW FF

Unclip the center dash trim panel.

(

Figure B)

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Remove (4) screws securing the

radio. Disconnect and remove the

radio. (

Figure C)

Remove (3) screws securing the radio

rear support bracket and remove the

bracket. (

Figure D)

Unclip and remove the center console

trim panel. (

Figure A)

Continue to kit assembly.

99-6511 DASH DISASSEMBLY

DODGE DAKOTA 2008-2010

MITS BISHI RAIDER 2008-10

123456AUX

AUX

SET

VOLUME

PUSH ON PUSH AUDIO/SELECT

DISC

LIST

MUSIC

TYPE

SEL;ECT

TUNE/SCROLL

SEEKSEEK SCAN TIME INFO RW FF

Remove (4) Phillips screws securing

the radio. (

Figure B)

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Unclip and remove the trim panel

surrounding the radio. (

Figure A)

Continue to kit assembly.

Remove (4) 7mm screws securing

the radio. Unplug and remove radio.

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Unsnap and remove center dash

panel. (

Figure A)

Continue to kit assembly.

99-6511 DASH DISASSEMBLY

DODGE NITRO 2007-2010

JEEP LIBERTY 2008-2010

12345

23456

Remove (4) 7MM screws securing

radio. Unplug and remove radio.

(

Figure B)

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Unclip entire panel surrounding radio

and climate controls, including a/c

vents. Unplug and remove panel.

(

Figure A)

Continue to kit assembly.
