Netvox R311D Bedienungsanleitung

Model：R311D

Wireless Asset Sensor

User Manual

This document contains proprietary technical information which is the property of NETVOX Technology. It shall be maintained

in strict confidence and shall not be disclosed to other parties, in whole or in part, without written permission of NETVOX

Technology. The specifications are subject to change without prior notice.

Table of Content

1. Introduction.............................................................................................................................................................2

2. Appearance..............................................................................................................................................................3

3. Main Features..........................................................................................................................................................3

4.Set up Instruction .....................................................................................................................................................4

5. Data Report .............................................................................................................................................................5

6. Installation...............................................................................................................................................................8

7. Important Maintenance Instruction.........................................................................................................................8

1. Introduction

R311D is a simple positioning function, periodically reports RSSI and SNR information to the gateway for processing and can

locate the position status of the device according to the reported RSSI and SNR information

LoRa Wireless Technology:

LoRa is a wireless communication technology famous for its long-distance transmission and low power consumption. Compared

with other communication methods, LoRa spread spectrum modulation technique greatly extend the communication distance. It

can be widely used in any use case that requires long-distance and low-data wireless communications. For example, automatic

meter reading, building automation equipment, wireless security systems, industrial monitoring. It has features like small size,

low power consumption, long transmission distance, strong anti-interference ability and so on.

LoRaWAN:

LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure interoperability between devices and

gateways from different manufacturers.

2. Appearance

3. Main Features

Compatible with LoRaWAN

2 sections of 3V CR2450 button battery power supply

RSSI / SNR detection

Simple operation and setting

Compatible with LoRaWANTM Class A

Frequency hopping spread spectrum

Configuration parameters can be configured via a third-party software platform, data can be read and alerts can be set via

SMS text and email (optional)

Applicable to third-party platforms: Actility/ThingPark, TTN, MyDevices/Cayenne

Low power consumption and long battery life

Note:

Battery life is determined by the sensor reporting frequency and other variables, please refer to

http://www.netvox.com.tw/electric/electric_calc.html

On this website, users can find battery life time for varied models at different configurations.

Indicator

Function Key

4.Set up Instruction

On/Off

Power on Insert batteries. (users may need a screwdriver to open);

Insert two sections of 3V CR2450 button batteries and close the battery cover.)

Turn on Press any function key till the green and red indicator flash once.

Turn off (Restore to factory setting)

Press and hold the function key for 5 seconds till the green indicator flashes for 20 times.

Power off Remove Batteries.

Note:

1. Remove and insert the battery; the device memorizes previous on/off state by default.

2. On/off interval is suggested to be about 10 seconds to avoid the interference of capacitor

inductance and other energy storage components.

3. Press any function key and insert batteries at the same time; it will enter engineer testing

mode.

Network Joining

Never joined the network

Turn on the device to search the network to join.

The green indicator stays on for 5 seconds: success

The green indicator remains off: fail

Had joined the network

Turn on the device to search the previous network to join.

The green indicator stays on for 5 seconds: success

The green indicator remains off: fail

Fail to join the network

(when the device is on)

Suggest to check the device verification information on the gateway or consult your platform

server provider.

Function Key

Press and hold for 5 seconds

Restore to factory setting / Turn off

The green indicator flashes for 20 times: success

The green indicator remains off: fail

Press once The device is in the network: the green indicator flashes once and sends a report

The device is not in the network: the green indicator remains off

Sleeping Mode

The device is on and in the

network

Sleeping period: Min Interval.

When the reportchang

e exceeds setting value or the state changes: send a data report according

to Min Interval.

Low Voltage Warning

Low Voltage 2.4V

5. Data Report

Data report configuration and sending period are as following:

Example of ConfigureCmd

FPort：0x07

Bytes 1 1 Var (Fix =9 Bytes)

CmdID DeviceType NetvoxPayLoadData

CmdID– 1 byte

DeviceType– 1 byte – Device Type of Device

NetvoxPayLoadData– var bytes (Max=9bytes)

Min Interval

(Unit:second)

Max Interval

(Unit:second) Reportable Change Current Change≥

Reportable Change

Current Change＜

Reportable Change

Any number between

1~65535

Any number between

1~65535 Can not be 0. Report

per Min Interval

Report

per Max Interval

When the device is turned on, it will immediately send a version package.

Data will be reported by default setting before any configuration.

Default setting:

Maximum time: 3600s

Minimum time: 3600s

BatteryChange: 0x01 (0.1V)

The reported data is decoded by the Netvox LoRaWANApplication Command document and

http://www.netvox.com.cn:8888/page/index

Note:

The real data sending cycle is subject to the programming configuration before shipment.

Description Device Cmd

Device

Type NetvoxPayLoadData

ConfigReport

Req

R311D

0x01

0x4E

MinTime

(2bytes Unit:s)

MaxTime

(2bytes Unit:s)

BatteryChange

(1byte Unit:0.1v)

Reserved

(4Bytes,Fixed 0x00)

ConfigReport

Rsp 0x81 Status

(0x00_success)

Reserved

(8Bytes,Fixed 0x00)

ReadConfig

ReportReq 0x02 Reserved

(9Bytes,Fixed 0x00)

ReadConfig

ReportRsp 0x82 MinTime

(2bytes Unit:s)

MaxTime

(2bytes Unit:s)

BatteryChange

(1byte Unit:0.1v)

Reserved

(4Bytes,Fixed 0x00)

(1) Command Configuration:

MinTime = 1min、MaxTime = 1min、BatteryChange = 0.1v

Downlink：014E003C003C0100000000 // 003C(Hex) = 60(Dec)

Response：

814E000000000000000000（Configuration success）

814E010000000000000000（Configuration failure）

(2) Read Configuration:

Downlink：024E000000000000000000

Response：824E003C003C0100000000（Current configuration）

Example for MinTime/MaxTime logic:

Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange=0.1V

Max Time Max Time

Sleeping (Min Time) Sleeping (Min Time)

1H 2H 3H

Note:

MaxTime=MinTime. Data will only be report according to MaxTime (MinTime) duration regardless BatteryVoltageChange

value.

Wake up and

collects data

REPORTS 2.8V

Wakes up and

collects data

REPORTS 2.8V

Wakes up and

collects data

REPORTS 2.8V

Example#2 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.

MaxTime

Sleeping (MinTime) sleeping sleeping sleeping

0H 15th M 30th M 45th M 1H 2H

Example#3 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.

MaxTime

sleeping sleeping ...

0H 15th M 30th M 45th M 1H 1H 10th M 1H 25th M 1H 40th M 1H 55th M 2H 10th M

Note:

1) The device only wakes up and performs data sampling according to MinTime Interval. When it is sleeping, it does not collect

data.

2) The data collected is compared with the last data reported. If the data change value is greater than the ReportableChange value,

the device reports according to MinTime interval. If the data variation is not greater than the last data reported, the device

reports according to MaxTime interval.

3)We do not recommend to set the MinTime Interval value too low. If the MinTime Interval is too low, the device wakes up

frequently and the battery will be drained soon.

4) Whenever the device sends a report, no matter resulting from data variation, button pushed or MaxTime interval, another cycle

of MinTime / MaxTime calculation is started.

Wakes up and

collects data

2.8V

Does not report

Wakes up and

collects data

REPORTS 2.8V

Wakes up and

collects data

REPORT 2.8V

Wakes up and

collects data

REPORTS

2.8V

Wakes up and

collects data

2.7V |2.7-2.8|=0.1

REPORTS 2.7V

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data 2.7V

Does not report

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data

REPORTS

2.7V

Wakes up and

collects data

2.8V

Does not report

Users push the button,

REPORTS 2.7V.

Recalculate MaxTime.

Wakes up and

collects data

2.8V

Does not report

Wakes up and

collects data

2.8V

Does not report

6. Installation

This product does not have a waterproof function. After the screening is completed, please place it indoors.

Note: To install the battery, use a screwdriver or similar tool to assist in opening the battery cover.

7. Important Maintenance Instruction

Kindly pay attention to the following in order to achieve the best maintenance of the product:

•Keep the device dry. Rain, moisture, or any liquid, might contain minerals and thus corrode electronic circuits. If the device

gets wet, please dry it completely.

•Do not use or store the device in dusty or dirty environment. It might damage its detachable parts and electronic components.

•Do not store the device under excessive heat condition. High temperature can shorten the life of electronic devices, destroy

batteries, and deform or melt some plastic parts.

•Do not store the device in places that are too cold. Otherwise, when the temperature rises to normal temperature, moisture will

form inside, which will destroy the board.

•Do not throw, knock or shake the device. Rough handling of equipment can destroy internal circuit boards and delicate

structures.

•Do not clean the device with strong chemicals, detergents or strong detergents.

•Do not apply the device with paint. Smudges might block in the device and affect the operation.

•Do not throw the battery into the fire, or the battery will explode. Damaged batteries may also explode.

All of the above applies to your device, battery and accessories.

If any device is not working properly, please take it to the nearest authorized service facility for repair.
