Nibe VVM 500 Bedienungsanleitung

Service manual

APH

NIBE™ VVM 500

Indoor module

SEM GB 1411-1

M11495

Table of Contents

1 Important information 2

Document information 2

Safety information 2

2 Indoor module's design 4

3 System description 6

Principle of operation 6

System diagram 7

4 Current circuit 8

Load monitor 8

5 Component description 9

Components 9

Sensors 10

Electronics 11

External connection options 12

6 Troubleshooting 13

Alarm list 13

Troubleshooting guide 18

Function check, components 23

7 Component replacement 25

Basic 25

Main components 28

Circuit board and electronics 33

8 Technical data 36

Electrical circuit diagram, 3 x 400V 36

Dimensions and setting-out coordinates 41

Technical specifications 42

Hot water capacity 43

Item register 44

1Table of Contents |NIBE™ VVM 500

Document information

This technical manual is a complement to the Installer

handbook for VVM 500, containing:

႑Component description.

႑Information to facilitate fault-tracing.

႑Instructions for replacing components.

႑Wiring diagram.

႑Supplementary technical information.

The document applies to VVM500 with software ver-

sions up to and including week 3204.

The heat pump software version can be found in the

info menu (menu 3.1).

Safety information

This manual describes installation and service proced-

ures for implementation by specialists.

This appliance can be used by children

aged from 8 years and above and per-

sons with reduced physical, sensory or

mental capabilities or lack of experience

and knowledge if they have been given

supervision or instruction concerning

use of the appliance in a safe way and

understand the hazards involved. Chil-

dren shall not play with the appliance.

Cleaning and user maintenance shall

not be made by children without super-

vision.

Rights to make any design or technical

modifications are reserved.

©NIBE 2014.

Symbols

NOTE

This symbol indicates danger to machine or

person.

Caution

This symbol indicates important information

about what you should observe when main-

taining your installation.

TIP

This symbol indicates tips on how to facilitate

using the product.

Marking

The CE marking means that NIBE ensures that the

product meets all regulations that are placed on it

based on relevant EU directives. The CE mark is obligat-

ory for most products sold in the EU, regardless where

they are made.

Serial number

The serial number can be found at the bottom right of

the front cover and in the info menu (menu 3.1).

6HULDO QXPEHU

Caution

Always give the product's serial number (14

digits) when reporting a fault.

NIBE™ VVM 500Chapter 1 | Important information2

1 Important information

Contact information

KNV Energietechnik GmbH, Gahberggasse 11, 4861 SchörflingAT

Tel: +43 (0)7662 8963-0 Fax: +43 (0)7662 8963-44 E-mail: mail@knv.at www.knv.at

NIBE Wärmetechnik AG, Winterthurerstrasse 710, CH-8247 FlurlingenCH

Tel: (52) 647 00 30 Fax: (52) 647 00 31 E-mail: [email protected] www.nibe.ch

Druzstevni zavody Drazice s.r.o, Drazice 69, CZ - 294 71 Benatky nad JizerouCZ

Tel: +420 326 373 801 Fax: +420 326 373 803 E-mail: [email protected] www.nibe.cz

NIBE Systemtechnik GmbH, Am Reiherpfahl 3, 29223 CelleDE

Tel: 05141/7546-0 Fax: 05141/7546-99 E-mail: [email protected] www.nibe.de

Vølund Varmeteknik A/S, Member of the Nibe Group, Brogårdsvej 7, 6920 VidebækDK

Tel: 97 17 20 33 Fax: 97 17 29 33 E-mail: [email protected] www.volundvt.dk

NIBE Energy Systems OY, Juurakkotie 3, 01510 VantaaFI

Puh: 09-274 697 0 Fax: 09-274 697 40 E-mail: inf[email protected] www.nibe.fi

AIT France, 10 rue des Moines, 67000 HaguenauFR

Tel : 03 88 06 24 10 Fax : 03 88 06 90 15 E-mail: [email protected] www.nibe.fr

NIBE Energy Systems Ltd, 3C Broom Business Park, Bridge Way, Chesterfield S41 9QGGB

Tel: 0845 095 1200 Fax: 0845 095 1201 E-mail: [email protected].uk www.nibe.co.uk

NIBE Energietechniek B.V., Postbus 634, NL 4900 AP OosterhoutNL

Tel: 0168 477722 Fax: 0168 476998 E-mail: [email protected] www.nibenl.nl

ABK AS, Brobekkveien 80, 0582 Oslo, Postadresse: Postboks 64 Vollebekk, 0516 OsloNO

Tel. sentralbord: +47 23 17 05 20 E-mail: [email protected] www.nibeenergysystems.no

NIBE-BIAWAR Sp. z o. o. Aleja Jana Pawła II 57, 15-703 BIAŁYSTOKPL

Tel: 085 662 84 90 Fax: 085 662 84 14 E-mail: sekretariat@biawar.com.pl www.biawar.com.pl

Tel./fax +7 831 419 57 06 E-mail: [email protected] www.nibe-evan.ru

NIBE AB Sweden, Box 14, Hannabadsvägen 5, SE-285 21 MarkarydSE

Tel: +46-(0)433-73 000 Fax: +46-(0)433-73 190 E-mail: [email protected] www.nibe.se

For countries not mention in this list, please contact Nibe Sweden or check www.nibe.eu for more information.

3Chapter 1 | Important informationNIBE™ VVM 500

VVM 500

APH

VVM 500

;/

$$

40

$$

(%

)'

)$

;/

41

3)3)

;/

*3

41

$$

6)

%7

8%

$$;-

$$

$$;-

*3

40

%7

%7

8%

;/

;/

;/

&0

;/

;/

;/

;/;/

;/;/

41

;/

%7

%7

40

%7

3)

3)

;/

;/

;/

;/

;/

$$

NIBE™ VVM 500Chapter 2 | Indoor module's design4

2 Indoor module's design

Pipe connections

Connection, heating medium flow lineXL1

Connection, heating medium return lineXL2

Connection, cold waterXL3

Connection, hot waterXL4

Connection, docking in heating mediumXL8

Connection, docking out heating mediumXL9

Connection, solar system flow lineXL13

Connection, solar system return lineXL14

Connection, docking in high tempXL18

Connection, docking out high tempXL19

Connection, docking poolXL39

HVAC components

Expansion tank (connection)CM1

Circulation pumpGP1

Charge pumpGP12

Drain valve, water heaterQM1

Venting, climate systemQM20

Shuttle valve, climate system/water heater, flow

line

QN10

Shunt valveQN11

Shuttle valve, climate system/water heater, re-

turn line

QN35

Sensors etc.

Temperature sensors, heating medium flowBT2

Temperature sensor, heating medium returnBT3

Temperature sensor, hot water, controlBT6

Temperature sensor, hot water, displayBT7

Temperature sensor, solar coilBT54

Temperature sensor, heating medium supply

after immersion heater

BT63

Electrical components

Immersion heater cardAA 1

Base cardAA 2

Input circuit boardAA 3

Display unitAA 4

AA4-XJ3 USB socket

AA4-XJ4 Service socket

Extra relay circuit boardAA 7

Immersion heaterEB 1

Miniature circuit-breakerFA 1

Temperature limiterFD 1

SwitchSF 1

Miscellaneous

Rating platePF 1

Serial number platePF 3

Cable glandUB1

Cable glandUB2

Designations in component locations according to

standard IEC 81346-1 and 81346-2.

5Chapter 2 | Indoor module's designNIBE™ VVM 500

Principle of operation

XL8 XL9 CM1 XL3 XL2

XL1XL4BT7XL39

BT2

GP1

BT3

GP12

QN10

QN35

QN11

BT6

BT54

;/

;/

41

;/

*3

41

%7

*3

%7

;/

;/

&0

41

;/

%7

%7

%7

;/

List of components

Pipe connections

Connection, heating medium flow lineXL1

Connection, heating medium return lineXL2

Connection, cold waterXL3

Connection, hot waterXL4

Connection, docking in heating mediumXL8

Connection, docking out heating mediumXL9

Connection, docking poolXL39

HVAC components

Expansion tank (connection)CM1

Circulation pumpGP1

Charge pumpGP12

Shuttle valve, climate system/water heater, flow

line

QN10

Shunt valveQN11

Shuttle valve, climate system/water heater, re-

turn line

QN35

Sensors

Temperature sensors, heating medium flowBT2

Temperature sensors, heating medium returnBT3

Temperature sensor, hot water, controlBT6

Temperature sensor, hot water, displayBT7

Temperature sensor, solar coilBT54

NIBE™ VVM 500Chapter 3 | System description6

3 System description

System diagram

-FL2

-CM1

-EB15

-EP30

-EP30-BT53

-EP8

-AA25

-CM5

-GP4

-QM45

-RM3

-QM43

-QM44

T P

-FL4

-RM4 T

-GP30

-FL1

-QM40-RM1

-GP20

-BT3

-BT2

-QN25

-EP21

-AA25

-GP9

-BT52

-EM1

-AA25

-EM1

-GP15

-EB101

-GP9 -BT51 -HQ4

-EP5

-AA25

-CL11

-CL11-QN19

Climate systemEP 21Accessory cardAA 5

Solar kit SCA 30EP 30Control unitAA 25

Safety valve, climate systemFL 2Temperature sensors, heating medium flowBT 2

Safety valve, solarFL 4Temperature sensors, heating medium returnBT 3

Circulation pump, solarGP 4Temperature sensor, poolBT 51

Circulation pump, poolGP 9Temperature sensor, boilerBT 52

Circulation pump, external heat sourceGP 15Temperature sensor, solar panelBT 53

Circulation pumpGP 20Pool kit POOL 500CL 11

Pump station SPS 10, SPS 20GP 30Expansion vessel, heating mediumCM 1

Particle filterHQ 4Expansion vessel, solarCM 5

Shut-off valveQM 4XVVM 500EB 15

Shunt valveQN 11F20XX/F2300EB 100

Three way valve, poolQN 19Oil, gas, or electric boilerEM 1

Non-return valveRM XExchanger, poolEP 5

Solar panelEP 8

7Chapter 3 | System descriptionNIBE™ VVM 500

Load monitor

Currents sensors are connected on AA3-X4:1-4.

Function:

႑If any of the internal phases exceed the set value and

the phase sequence is not detected, the power step

disconnects from one of the internal phases. Because

the phase sequence is not detected this can mean

that the incorrect phase sequence is disconnected,

so that the output is still too high. The heat pump

continues by disconnecting another phase, until the

current does not exceed the set value. If the current

still exceeds the set value when all internal phases

are disconnected, the same process is performed for

the external additional heat, if such exists and is set

to step controlled additional heat

NOTE

Do not disconnect the external additional

heat if it is set to give additional heat in

one step.

႑If the phase sequence is detected the electrical out-

put is disconnected in the phase that exceeds the set

value. This will also handle any external additional

heat.

႑If disconnecting the phases does not work, the heat

pump will finally disengage.

႑Reconnection occurs when the current has fallen to

a value low enough to permit reconnection.

NOTE

VVM 500 must be filled with water before the

phase sequence is detected.

For the heat pump to disconnect the electrical output

in the correct phase, the phase sequence must have

been detected in the installation. In the menu 5.1.12

the phase sequence must be detected afterwards. An

unsuccessful detection may be due to the current

sensors not being correctly connected or that other

electrical equipment started or stopped during detec-

tion.

Factory settingNameMenu

16Afuse size5.1.12

detect phase order

NIBE™ VVM 500Chapter 4 | Current circuit8

4 Current circuit

Andere Handbücher für VVM 500

Inhaltsverzeichnis

Andere Nibe Steuereinheit Handbücher

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
