Norac UC5 Topcon X30 Bedienungsanleitung
Spray Height
C
ontroller
Hagie
(STS 12 2000-2004)
Installation Manual
HG01
Printed in Canada
Copyright 2008 by NORAC Systems International Inc.
Reorder P/N UC5-BC-HG01-INST Rev D (STS 12 2000-2004)
NOTICE: NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and without
the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information contained in this
manual. The technical information in this manual was reviewed at the time of approval for publication.
Contents
1 Introduction.............................................................................................................. 1
2 General UC5 System Layout .................................................................................. 2
3 it Parts.................................................................................................................... 3
4 Pre-Install Checklist ................................................................................................ 9
5 Ultrasonic Sensor Installation............................................................................... 10
6 Roll Sensor Installation ......................................................................................... 15
7 Hydraulic Installation............................................................................................ 19
8 Module Installation................................................................................................ 23
9 Connecting the Sensors to the CANbus ............................................................... 27
10 Software Setup ....................................................................................................... 28
11 Cable Drawings ...................................................................................................... 29
1
1 Introduction
Congratulations on your purchase of the NORAC UC5 Spray Height Controller. This system is
manufactured with top quality components and is engineered using the latest technology to
provide operating reliability unmatched for years to come.
When properly used the system can provide protection from sprayer boom damage, improve
sprayer efficiency, and ensure chemicals are applied correctly.
Please take the time to read this manual completely before attempting to install the system. A
thorough understanding of this manual will ensure that you receive the maximum benefit from
the system.
Your input can help make us better! If you find issues or have suggestions regarding the parts
list or the installation procedure, please don’t hesitate to contact us.
Phone 1 800 667 3921 Canada (Toll Free)
1 866 306 6722 United States (Toll Free)
(+33) 06 03 87 80 78 Europe
(+1) 306 664 6711 All other regions
Web www.norac.ca
Every effort has been made to ensure the accuracy of the information contained in this
manual. All parts supplied are selected to specially fit the sprayer to facilitate a complete
installation. However, NORAC cannot guarantee all parts fit as intended due to the
variations of the sprayer by the manufacturer.
Please read this manual in its entirety before attempting installation.
2
2 General UC5 System Layout
Figure 1 illustrates the general layout of the UC5 system components
Figure 1: General UC5 System Layout
3
3 Kit Parts
The following diagrams illustrate the Hagie STS 2000-2004 (HG01) kit specific parts of the
NORAC UC5 system.
3.1 Kit Overview
Figure 2: HG01 System Parts
4
3.2 ydraulic Plumbing
NOTE Hoses are supplied by Hagie
Figure 3: HG01 Hydraulic Plumbing Parts
The use of dielectric grease is not recommended on any NORAC electrical connections.
To ensure all stainless steel hardware does not gall or seize apply a light coating of the
supplied Permatex Anti-seize grease to all threaded parts upon installation. Permatex Anti-
seize lubricant is preferred, but other similar anti-seize products may be used.
5
3.3 List of Parts
Item Part Number Name Quantity
B10 44728 MOUNTING BRACK T COMPL T UC4 BR AKAWAY XT ND D 2
B11 44743 MOUNTING BRACK T MAIN LIFT S NSOR UC4 PLUS 1
B13 44700-03 PLAT VALV MOUNT UC3 BOOM CONTROL HAGI 1
C01 43220-05 CABL UC5 N TWORK 14 AWG 5M 2
C03 43220-03 CABL UC5 N TWORK 14 AWG 3M 1
C04 43210-03 CABL UC5 N TWORK 18 AWG 3M 1
C05 43210-01 CABL UC5 N TWORK 18 AWG 1M 2
C06 43210-20 CABL UC5 N TWORK 18 AWG 20M 2
C10 43230-04 CABL UC5 VALV 2PIN DT TO 2PIN DT 4
C20 43240-07 CABL UC5 INT RFAC MAIN DT (WITH AUX 1 & 2) 1
C21 43240-01 CABL UC5 INT RFAC TILT DT 1
C30 43250-06 CABL UC5 BATT RY PIGTAIL 1
01 43710 UC5 CONTROLL R MODUL 1
02 43720 UC5 VALV MODUL 1
03 43732 UC5 INPUT MODUL PASS THRU 1
04 43740 UC5 ROLL S NSOR 2
05 43750 UC5 ULTRASONIC S NSOR 3
10 43760 UC5 N TWORK COUPL R 3-WAY 1
11* 43765 UC5 N TWORK COUPL R 8-WAY 1
12 43764 UC5 N TWORK COUPL R 2-WAY 1
20* 43764T UC5 N TWORK COUPL R 2-WAY WITH T RMINATOR 2
H10 44865-14 HYDRAULICS FITTING KIT - HG2 1
M02 UC5-BC-HG01-INST MANUAL INSTALLATION UC5 HAGI STS 12 2000-2004 1
P01 106034 UC5 N TWORK 2 PIN PLUG 4
P02 106035 UC5 N TWORK 12 PIN PLUG (A-K Y) 1
P03 105882 UC5 N TWORK 6 PIN PLUG 3
V01* 44963D VALV BLOCK ASS MBLY 2 STATION CC/LS PROP DT 4 BOLT 1
* See Substitution Parts
6
3.4 Substitution Parts
Substitution parts will in no way affect the operation of the system provided that they are
installed as directed.
Item E11 – 8-way coupler (43765) may be substituted with:
Item Part Number Name Quantity
11* 43762 UC5 N TWORK COUPL R 6-WAY 1
43765 43762
43765 Replaced with a 43762
Item E20 – 2-way coupler with terminator (43764T) may be substituted with:
Item Part Number Name Quantity
10 43760 UC5 N TWORK COUPL R 3-WAY 2
20* 43780 UC5 N TWORK T RMINATOR 2
Install the UC5 Network Terminator (E20*) into the third connector on the UC5 Network 3-way
Coupler (E10) (shown below). It is now a drop-in replacement for the 43764T (E20).
43764T Replaced with a 43760 and 43780
7
Item V01 – 2 Station Valve Block (44963D) may be substituted with:
Item Part Number Name Quantity
V01 44933D VALV BLOCK ASS M UC4-BC 2-STATION CC/LS VARIABL RAT 1
The 44933D is a direct replacement for the 44963D. Both valve blocks function the same. The
blocks are identifiable by the filter cap shape and by the part number stamped on the side.
The A and B ports are opposite on each valve block so verify that the hoses are being
connected to the correct port. The raise lines always go to the “B” port and the lower lines
go to the “A” port.
44933D Valve Block Shown Alongside 44963D Valve Block
Filter Cap Part
Number
Part
Number
Filter Cap
