COMSPHERE

3600 SERIES

DATA SERVICE UNITS

DIAL BACKUP MODULE

QUICK REFERENCE

Document No. 3610-A2-GL13-00

Printed in U.S.A.

Notice

This publication is protected by federal copyright law. No part of this publication may be

copied or distributed, transmitted, transcribed, stored in a retrieval system, or translated

into any human or computer language in any form or by any means, electronic,

mechanical, magnetic, manual or otherwise, or disclosed to third parties without the

express written permission of Paradyne Corporation, 8545 126th Ave. N., Largo,

FL 33773.

Paradyne Corporation makes no representation or warranties with respect to the

contents hereof and specifically disclaims any implied warranties of merchantability or

fitness for a particular purpose. Further, Paradyne Corporation reserves the right to

revise this publication and to make changes from time to time in the contents hereof

without obligation of Paradyne Corporation to notify any person of such revision or

changes.

Changes and enhancements to the product and to the information herein will be

documented and issued as a new release to this manual.

Warranty, Sales, and Service Information

Contact your local sales representative, service representative, or distributor directly for

any help needed. For additional information concerning warranty, sales, service, repair,

installation, documentation, training, distributor locations, or Paradyne worldwide office

locations, use one of the following methods:

Via the Internet: Visit the Paradyne World Wide Web site at

http://www.paradyne.com

Via Telephone: Call our automated call system to receive current information via

fax or to speak with a company representative.

— Within the U.S.A., call 1-800-870-2221

— Outside the U.S.A, call 1-727-530-2340

Document Feedback

We welcome your comments and suggestions about this document. Please mail them

to Technical Publications, Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773,

or send e-mail to [email protected]. Include the number and title of this

document in your correspondence. Please include your name and phone number if you

are willing to provide additional clarification.

Trademarks

All products and services mentioned herein are the trademarks, service marks,

registered trademarks or registered service marks of their respective owners.

COMSPHERE 3600 Series Data Service Units

Models 3610 and 3611

Dial Backup Module

Quick Reference

Document Number 3610-A2-GL13-00

November 1998

Product Documentation on the World Wide Web

We provide complete product documentation at www.paradyne.com. This lets you

search the documentation for specific topics and print only what you need, reducing the

waste of surplus printing. It also helps us maintain competitive prices for our products.

Select

Service & Support

→

Technical Manuals

→

Subrate Digital Access Devices

Then select the following documents:

3610-A2-GB46

COMSPHERE 3600 Series Data Service Units,

Models 3610 and 3611, User’s Guide

3610-A2-GB49

COMSPHERE 3600 Series Data Service Units,

Models 3610 and 3611, Dial Backup Module Options Supplement

To request a paper copy of a Paradyne document:

Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396)

Outside the U.S.A., call 1-727-530-8623

Read First

Follow these steps for a successful installation of your DBM.

1. If required, install new firmware. The

3600 Series DBM Option Installation

Instructions

, Document No. 3610-A2-GZ52, explains how to determine whether it is

required.

2. Verify the switch settings on the DSU.

3. Install the DBM according to the

Installation Instructions.

4. If you installed new firmware, use the Confg menu from the front panel to load the

factory default settings. The DSU will not function properly unless the factory

default settings are reloaded.

5. Enter and save directories, phone numbers, and SPIDs you will use. Make and

save any other configuration changes required for your network.

6. Power up the DSU and test the DBM.

Powering Up the DBM

When you apply power to the DSU, the DSU performs a

power-up routine and:

Determines what hardware options are installed, including a DBM.

Automatically runs a Device Test (Devic) on the DSU and each installed hardware

option.

Displays the following messages on the Diagnostic Control Panel (DCP):

DSU DBM

Pass Pass

F2 F3

The power-up routine can be:

Initiated using the Reset selection in the Control branch.

Disabled with the PowerOnTst General configuration option.

The front panel’s:

Red Alarm LED is lit if the DBM is a digital DBM and not connected to the network.

LCD displays health and status information with DBM F:No Signal to indicate a

facility alarm.

Continue if you receive successful messages. If a Fail message appears or a hardware

option does not appear:

Refer to your User’s Guide for power-up messages and basic procedures for

changing configuration options and troubleshooting.

Refer to your DBM Supplement for DBM troubleshooting and messages.

NOTE:

For a 4-wire Switched 56 DBM, if power is applied and a Device Test run while a

network loopback is in progress, the test is aborted and the LCD displays Abrt.

Rerun the Device Test.

Network Verification Testing

Perform verification testing after any installation. Refer to the

Network Verification

Testing

section of the User’s Guide for more information.

After confirming the network connection for a DSU equipped with a DBM:

Procedure

1. Use the →Dial command to establish a dialed call to the remote unit in order to:

— Enter remote phone numbers in dial backup directory for both ends.

— Verify the DBM can establish a call.

The DBM will be in Standby mode.

2. Verify that Auto Answer (AutoAnswer) is enabled and that the other end answers.

3. Use the →Dial command to switch the data to the DBM circuit by entering Dial

Backup mode. Ensure that both DSUs have been configured correctly.

4. Perform a Digital Test (DT) on both the DBM and the circuit from the Test branch.

After testing the network:

1. Drop the backup (DrBU).

2. To automatically initiate a call if there is a DDS network failure, enable Auto Backup

(AutoBckup) and the Backup Directory numbers.

3. Enable V.13 Signaling (V.13 Signl) for switched-carrier operation emulation. This

applies to a multipoint circuit.

Top-Level Menu

Access to all functions from the standalone or shared DCP begins at the top-level

menu, the head of the menu hierarchy. Press the key from anywhere in the menu

to return to the top-level menu.

495-12970b

TOP-LEVEL MENU

Local Remot

Bckup Test Ctrl

Msgs

Address

Confg

Stat

Status Branch

The Status (Stat) branch includes reports on the:

Health and status of the DSU, DBM, TDM, and MCMP

DTE interface

496-12970-02

TOP-LEVEL MENU

Local Remot

Bckup Test Ctrl

Msgs

Address

Confg

Stat

H/S DTE CircQ ID TPwr

Port

Select

Devic Expan Subn

Backup Branch

The Backup (Bckup) branch controls operation of the dial backup feature for DBMs.

The Bckup selection is used to control DBM dialing from the front panel. References to

a DBM also apply to a DBM-D, DBM-I, DBM-S, or DBM-V where the Primary Core

configuration option is set to Yes and the DSU is disabled.

496-12971-06

TOP-LEVEL MENU

Local Remot

Test Ctrl

Stat

Msgs

Address

Confg

Bckup

Abort Bkup Dial DrBU Disc →Dial →DDS AggSw →NetI

Test Branch

The Test branch provides extensive testing capabilities for the DSU, DDS circuit, DBM,

and backup circuit. When the tributary receives a test request from the control, any

locally initiated test in progress on that core is aborted. The Abort selection allows you

to abort a test that is running. The DSU is not allowed to run any other test until the test

in progress is aborted or completed.

496-12972-03

TOP-LEVEL MENU

Local Remot

Bckup Ctrl

Stat

Msgs

Address

Confg

Test

DSU DBM

Abort Devic Lpbk Lamp

LL DTE DL RL

Start Start Start

Port

Select Port

Select

Port

Select

Address

Address Address

Run

Tim # Blocks

Displ Clr

EEDT BERT

Port

Select

Subn Selective

DTone

Configuration Branch

The Configuration (Confg) branch allows you to configure or customize the DSU and

the DBM options. Change configurations options from either:

A front panel

A 6700 or 6800 Series NMS

An asynchronous terminal (3610 standalone only)

496-12973a-02

TOP-LEVEL MENU

Local Remot

Bckup Test Ctrl

Stat

Confg

Msgs

Opts PList Dir Phone

Addr

ChgMd

Displ Chang

Add

Acq

Activ Delet

Chang Clr

Save

DPII

ADp

Remt

Address

Activ Usr1 Usr2 Usr3

Activ Usr1

Usr2

Usr3

FacC

FacT

FacB

Load

SAVE DSU DBM Gen Bkup MUX PrtSp LPDA

Remt Usr1 Usr2 Usr3

Address

Activ Usr1 Usr2 Usr3

DSU DBM Chan

Skip

Clr

Diag

Activ

Address

DSU DBM Gen

Term

Enab Pswrd CIDDisab

Pswrd

SPID

FB1

Chang Clr

SaveEnabDisab

MPTC

MPTT

Chang Clr

Configuration Option Tables

In the tables that follow, FacT (Factory Tributary) defaults are shown in boldface. If

different from the FacT defaults, FacC (Factory Control) defaults are shown in

italics

Key to symbols:

AConfiguration options that do not appear when Full mode is disabled using

Menu from the Configuration branch.

HISDN and Switched 56 Digital DBMs

LISDN DBM only

LL V.32 Analog DBM only

FWhen the Async→Sync configuration option is enabled using the MUX Port

branch, the following DBM PrtSp settings do not appear: 32, 18.0, 8.4, 4.0,

and 2.0 kbps.

FF F ISDN and 2-wire Switched 56 DBMs only

}Not available for Switched 56 DBMs; defaults to 56 kbps.

}} Ports 3–6 are not available for 2-port Flex MUX models.

zNot available for a DBM-

or a DSU with Primary core set to Yes; the DSU is

Disabled

zz 4-wire Switched 56 DBM only

:: Appears when non-Flex MCMP/TDM is installed or 6-port MCMP/TDM Flex is

installed with firmware version less than 6.33

DSU Configuration Options

DSU

Configuration Options Value

Rate(Kbps) Auto, 64CC, 64L, 56, 38.4, 19.2, 9.6, 4.8, 2.4

TxClkSource Int, RXC, Ext, DDS, Prt1, Prt2, Prt3, Prt4, Prt5, Prt6

Msg Clamp AEnab, Disab

TxElasStor Enab, Disab

RxElasStor AEnab, Disab

19.2 PowrLvl DD A+6, 0, –10

64KScramblng AOn, Off

64KLatchLpbk AOn, Off

NetIntf AAggSw, Forc, Disab

Net ITiming AInt, NetI, Prt1, Prt2, Prt3, Prt4, Prt5, Prt6

V.54 Lpbk AEnab, Disab

Diagnostic DSU

Configuration Options Value

Diag Type NonD, Disr, Mixed, None

2nd Ch(bps) A100, 400, 800, 1200, 1600

Disr Type 2500, 2600, 3600s, 3600e, Br56

Diagnostic General

Configuration Options Value

Position

Cntrl

, Trib, G2Trb

LinkConfg Pt-Pt, M-Pt

Resp Period A1, 2, 10

TribTimOut A0:10 (5 sec to 10 min)

Diag Conn CC, DC

Link Delay A0s, 1s, 2s, 5s, 10s, 20s, 50s

Network Delay A0s, 1s, 2s, 5s, 10s, 20s, 50s

Packet Delay A0s, 1s,2s, 5s

Extend Chan AYes, No

Upstream Port }} A Prt1, Prt2, Prt3, Prt4, Prt5, Prt6

M-Pt SymPrt AEnab, Disab

Fast Sel AEnab, Disab

General

Configuration Options Value

DTE Port :: EIA232, V.35

RTS Cntrl

FrcOn

, DTE

CTS Cntrl Std, =RTS

Antistream AEnab, Disab

LSD Lead AStd, Delay, FrcOn

CTS Lead AStd, Delay, FrcOn

SystemStat AEnab, Disab

DSR on Tst AEnab, Disab

Circ Assur AEnab, Disab

Tst Pattern AAT&T, Std

RespondRDL AEnab,

Disab

LL by DTE AEnab, Disab

RL by DTE AEnab, Disab

Bilat Lpbk AEnab, Disab

Ext Leads AExtLd, Rate, RPowr

CCN by EL AEnab, Disab

SW Vers A3.24, 4.43, 6.66, Normal

RLSD in MCMP HAYes, No

Async→Sync Enab, Disab

AsyncBit/Char 6, 7, 8, 9, 10

Stop Bits 1, 2

Overspeed 1.0, 2.3

Andere Handbücher für COMSPHERE 3610

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Paradyne Netzwerk-Hardware Handbücher

Paradyne

Paradyne Hotwire 5216 Bedienungsanleitung

Paradyne

Paradyne SMD2000-24E Bedienungsanleitung

Paradyne

Paradyne Hotwire 7995 Bedienungsanleitung

Paradyne

Paradyne 7510-A2-GB20-00 727 Bedienungsanleitung

Paradyne

Paradyne 8310 MVLt Bedienungsanleitung

Paradyne

Paradyne 3172 Handbuch

Paradyne

Paradyne ACCULIN 3364 Handbuch

Paradyne

Paradyne COMSPHERE 3610 Bedienungsanleitung

Paradyne

Paradyne ACCULINK 3163 DSU Bedienungsanleitung

Paradyne

Paradyne COMSPHERE 6700 Series Bedienungsanleitung

Paradyne

Paradyne Hotwire 7996 Bedienungsanleitung

Paradyne

Paradyne BitStorm IP DSLAM 1900 Produkthandbuch

Paradyne

Paradyne Application Module 9109 OCU-DP Bedienungsanleitung

Paradyne

Paradyne 7610 SNMP DSU Bedienungsanleitung

Paradyne

Paradyne MIM-4000F Bedienungsanleitung

Paradyne

Paradyne COMSPHERE 3610 Benutzerhandbuch

Paradyne

Paradyne M/HDSL Standalone Termination Unit HOTWIRE... Bedienungsanleitung

Paradyne

Paradyne Hotwire 8785 Bedienungsanleitung

Paradyne

Paradyne COMSPHERE 3810 Bedienungsanleitung

Paradyne

Paradyne BitStorm 4800 Express Bedienungsanleitung

Paradyne

Paradyne DC Power Entry Module 8820-S1-906 Bedienungsanleitung

Paradyne

Paradyne HotWire 8800 DSLAM Bedienungsanleitung

Paradyne

Paradyne HotWire 7924 Bedienungsanleitung

Paradyne

Paradyne Jetstream CPX-1000 Bedienungsanleitung

Beliebte Netzwerk-Hardware Handbücher anderer Marken

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Bedienungsanleitung

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Bedienungsanleitung

Yudor

Yudor YDS-16 Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-320L Bedienungsanleitung

Samsung

Samsung ES1642dc Gebrauchsanweisung

Honeywell Home

Honeywell Home LTEM-PV Montageanleitung

evertz

evertz 7700 Series Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-343 Bedienungsanleitung

Asante

Asante AsanteBridge 1012 Bedienungsanleitung

FireBrick

FireBrick FB2700 Bedienungsanleitung

Audiovox Electronics

Audiovox Electronics ARWH2T Bedienungsanleitung

ADC

ADC DSX-1 Handbuch

NetComm

NetComm NF2 Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 5620 Bedienungsanleitung

Dell EMC

Dell EMC XC6420 Series Bedienungsanleitung

Lanner

Lanner NCA-1020A Bedienungsanleitung

Allied Telesis

Allied Telesis AT-TN121-A Bedienungsanleitung

Arista

Arista CCA-ETM-Q12 Bedienungsanleitung
